NORTHERN LIGHTS HYPER EXTENSION BENCH
NORTHERN LIGHTS HYPER EXTENSION BENCH
NLHYP
OVERALL DIMENSIONS: 51"L X 30"W X 36"H
05 APRIL 2011
ASSEMBLY INSTRUCTIONS
Keep This For Warranty
NLHYP
LOT:
1-866-420-4560
Northern Lights Fitness
Products Inc.
MADE IN CANADA
Specification
Weight=63.5 lbs
Packed in 1 Box
:44.5"x33"x5.25"
Box 1
:4.46 ft³
Advertisement
Related Manuals for Northern Lights Fitness NLHYP
Summary of Contents for Northern Lights Fitness NLHYP
- Page 1 NORTHERN LIGHTS HYPER EXTENSION BENCH ASSEMBLY INSTRUCTIONS Keep This For Warranty NLHYP LOT: 1-866-420-4560 Northern Lights Fitness Products Inc. NORTHERN LIGHTS HYPER EXTENSION BENCH MADE IN CANADA Specification NLHYP Weight=63.5 lbs Packed in 1 Box OVERALL DIMENSIONS: 51"L X 30"W X 36"H 05 APRIL 2011 :44.5"x33"x5.25"...
- Page 2 Parts List BOLT SIZE Item Item Part QTY. Part QTY. 1 Hip Pad A Bolt 3/8" x 1-1/2" 2 Hip Pad Support B Bolt 3/8" x 3" 3 Adjustment Post C Bolt 3/8" x 3-1/2" 4 Rear Leg D Washer 3/8" 5 Base E Locknut 3/8"...
- Page 3 6 PLACES Typical Bolt Rear Leg (4) and Front Leg (6) to the Base (5) using the bolting shown. Bolt the Hip Pads (1) to the Hip Pad Support (2) using the bolting shown. Bolt the Hip Pad Support (2) to the Base (5) using the bolting shown. See Page 2 for the assembly of the Adjustment Post (3) to the Base (5).
- Page 4 WARRANTY Garantie à Vie Limitée du Fabricant Manufacturer’s Limited Lifetime Warranty Northern Lights Fitness Products Inc. offre à ses Northern Lights Fitness Products Inc. offers its clients une garantie à vie contre toutes soudures customers a lifetime warranty against broken casées et contre tout défaut de matériau et de...
