Technical Specifications - SynScan V2 Instruction Manual

SynScan SPECIFICATIONS
TM
Power Supply:
Motor type and resolution:
Slew speeds:
Gear Ratio:
Tracking Rates:
Tracking Modes:
Alignment Method:
Database:
Pointing Accuracy:
11 to 15 V DC 2Amp (Tip positive)
Microstep driven 1.8° stepper motors.
Resolution: 0.144 arc sec (or 9,024,000 steps/rev.)
Rate 0 = 0.5X
Rate 1 = 1X
Rate 2 = 8X
Rate 3 = 16X
Rate 4 = 32X
Rate 5 = 64X
Rate 6 = 400X
Rate 7 = 500X
Rate 8 = 600X
Rate 9 = 800X
705
Sidereal, Lunar, Solar
R.A. tracking
One-Star Alignment, Two-Star Alignment, Three-Star Alignment
25 user defined objects. Complete M, NGC, and IC catalogues,
Total 13,436 objects
Up to 1 arc min
16
