Summary of Contents for SOMLOS G1
- Page 2 TABLE OF CONTENTS 03-06 Connec�ng to Wi-Fi How to Properly Handle your Sømløs Maintenance 10-11 Know Your Sømløs Mower 12-14 Func�ons of your Mower Search Method 15-21 Charging the Ba�ery 21-22 How to Use your Sømløs 23-24 Control Panel 24-31 Full Menu Diagram Mowing and Startpoints Cleaning and Maintaining your mower...
- Page 3 This product can be remotely controlled via the mobile phone APP. Please scan to download and install APP. APP Download QR Code APP Icon Please ensure your garden strong Wi-Fi signal. Turn ON your mower - press and hold for 2s. LED light will be steady for 2 mins then will automa�cally turn OFF Step1...
- Page 4 Open APP and select the "Add device". See images below. Open APP, Find "Small Home, Ensure the Wi-Fi Enter your wifi sign up and login; then select "Mower" indicator light is password according Then choose to add under this category; now rapidly blinking;...
- Page 5 Sømløs has a schedule func�on which enables you to enjoy a hassle-fee mowing! Your mower can be programmed to automa�cally start mowing and goes back to the dock sta�on once done at your own �me. From the main page of your Sømløs app, go to TIMER >>...
- Page 6 Go to SETTING to Set the Recharge Set your Mowing Select Spiral Pa�ern setup your Mode to "Auto" so Pa�ern to: slide the ON/OFF 1)charging op�on the mower will return Random bu�on to enable 2) mowing pa�ern to the charging dock Zig-zag 3) Spiral Mode automa�cally.
-
Page 7: Safety Precautions
Congratula�ons for choosing an excep�onally high-end device and your best buddy for your lawn care! To get the best out of your SØMLØS G1, you must know your device. Before opera�ng this product, please read the instruc�ons carefully and make sure to keep the packaging for warranty purposes. - Page 8 2. When carrying, use the handle located at the rear under the mower. Carry the mower with the blades facing away from your body. Correct way Incorrect way Watch out for your hands and feet Read the manual carefully Do not ride and sit on the mower. Clear your lawn on any obstacles.
-
Page 9: Parts Identification
1. Turn OFF your mower when working on the mower's underframe (cleaning, replacing the baldes) 2. Inspect your mower at least once a week. See if there are damages or worn parts (specially the baldes) that may need replacement PARTS IDENTIFICATION An automa�c mower that cuts your lawn moving in an irregular or Zig-zag pa�ern. - Page 11 16. Keyboard 2. The control panel cover 17. Charging electrodes 18. Signal indicator light 3. Height of cut cover 19. Power connector 4. Rain sensor 20. Boundary connector 5. Charging socket 6. Front wheel 22. Operator’s manual 7. Blade plate 23.
- Page 12 A. Capacity SØMLØS G is recommended for lawns up to 1000/2000m. The size of the area that the mower mows are dependent on the condi�on of the blades, type of grass, grass growth rate (this affects the sharpness of the baldes. The more you use your mower, the faster the blade sharpness decipates), humidity and shape of your garden.
- Page 13 Mower can not pass Mower can pass Mower can pass , but need pick away. When the rain is too heavy, the ower stop work and go to the l l i motor will stop in one sencond. Mower will stop The STOP bu�on at the back of the mower is used to stop the mowing.
- Page 14 Under the there is a knob rotate clockwise to increase height and counter-clockwise to reduce The cover must be close at all �mes when the mower is turned on otherwise, it will not start cu�ng. If the cover is open while the mower is turned ON, it will turn OFF automa�cally a�er 6 mins.
- Page 15 Read and understand this chapter before installing your mower. proper installa�on affects the performance of your mower. It is also important plan it carefully. Before installa�on, create a sketch of your mower's working area including all probable obstacles. This gives you a be�er picture on where to place your Dock sta�on as well as placing your boundary wires.
- Page 16 The dock sta�on must be posi�oned on a More than 2m rela�vely level ground. The front end of the dock sta�on CANNOT be posi�oned higher than the lower back end. The height difference must NOT be more than 2cm. c. It is highly recommended to place the dock sta�on on a shaded area or away from direct sunlight as the ba�ery can charged faster in ambient temperatures.
- Page 17 Place the dock sta�on at a level ground or flat part of your lawn. d. Connect the adapter power cord to a 1 0 2 0V wall socket. ower is supplied with one or two unfullcharged As soon as the dock is connected, you can charge the a.
- Page 18 When there are several working areas for your mower to work on, the width of the passage connec�ng these areas must be over 1.2m. Otherwise, it'll be difficult for the mower to move into the other areas. the corners, don’t lay the boundary wire at a sharp or right angle; make sure it has 35cm space to the wall or other obstacles;...
- Page 19 a. ig trees, poles beds and those can be an obstacle for the mower and burying the boundary wire. b. Use boundary wire to protect your flowers c. A big tree with roots can be an obstacle for the mower. It should be protected by burying boundary wire.
- Page 20 e. Use a hammer to knock the pegs in the ground. care when pegs and make sure the wire is on the lawn; the distance between pegs should be approximately 100cm. The distance between pegs should be 30~50cm f. Don’t let the boundary wire 100cm g.
- Page 21 Open the control panel cover by pressing the STOP Place When your mower is new or has been stored for a long �me,thw ba�ery needs to be charged before using aiagn. Charging for 1 ba�ery takes up to 2hrs, total of 4 hrs for 2 ba�eries.
- Page 22 Pressing the STOP bu�on will make the mower stop if it's mowing; the blade motor stops in a couple of seconds and the control panel cover opens. Switching OFF your Mower 1. Press the STOP 2. Press and hold the POWER bu�on. The Display should be blank.
- Page 23 Use the control panel for all commands. All func�ons are accessible through the number menus. The control panel consists of a display and a the display and all input is done on the keypad. The main menu is the uppermost level of the menu structure. pressed.
- Page 24 Use this bu�on to set the "Work Mode" on your mower. This will display Home, Auto, Man -- use the arrow bu�ons to select and press the MENU/OK bu�on to confirm. convenie nt and smart use. Home Auto The numbers in brackets refer to the menu rows on the display number of submenus used to access all Work Timer A...
- Page 25 Startpoint startpoint length and angle. startpoint startpoint length and a o n. Set Startpoint Startpoint 1 Angle Length Angle Length Startpoint 1 090' 120m 090' 120m 150' 080m Startpoint 2 120' 150m Startpoint 3 >Random, Zig-zag, Mixed is also available.
- Page 26 Lawn Setup Mowing pattern Auto mode setting Auto mode setting Mowing pattern Random Manual mode setting Zigzag Edge cutting Mixed Spiral cutting from Monday to Sunday. Edge Cutting Spirl Cutting which day is work 5 where the lawn is not completely mown or where the grass is too thick. In MANU mode, you can manually move your mower to other zones which has buried boundary wire for mowing.
- Page 27 Auto Home Auto Man 08 July 16:20 Startpoint mowing. Once the setup is complete, you can now use your mower. If your lawn mower is si�ng at the charging dock while you do the setup, it'll start mowing at the �me you had scheduled it to do so.
- Page 28 , press MENE/OK to check press the system. startpoint Check signal shows if mower inside the boundary wire shows if mower inside the boundary wire Rain Sensor: To Check if the rain sensor OK or working. Means the signal sensor is broken ; Tes�ng your Mower's motor or not.
- Page 29 滚滚长江东逝水 format using the Day and time Password setting Sensitivity setting Factory reset Language setting password Password others.
-
Page 30: Sensitivity Setting
Sensitivity Setting Middle High Rain Factory reset 2. Input password Are you sure to reset? 3. Tick “Yes” Password: ____ Language Setting System Setting English Day and time Spanish Password setting German Sensitivity setting French Factory reset Language setting Danish Step1 Step2... - Page 32 You can set the mowing startpoints for each day of week. For example, if you set the following 3 startpoints on your lawn, the lawn mower reach other areas through narrow passages and mow your lawn Set Startpoint Point 1 Angle Length Startpoint 1 045'...
- Page 33 1. Check and clean mower regularly once a week. start using the m blades should be checked once a month. 3. It is important that the blades rotate easily. 4. Check if the blade's edges are damaged or not. The blade life depend on the type of grass, temperature, and longevity of usage.
- Page 34 3. Turn mower upside down. 4. Rotate the skid plate so that its hole aligns with the blade 5. Unscrew the blade. Use a 6. Pry the protection plate and blade plate a and remove the blade and screw. crew on new blade. Change the blade to another side if current side is broken, worn, damaged or dulled.
- Page 35 ZONE 2 ZONE 1 The picture above is for your reference. When your garden with different zones, and 2 zones all need to be cutted, pls check the set up process as below: 1.Between the passage of the 2 lawns, the width of 2 cables should be within 5cm; 2.When robot have finished the work in zone1, you need to choose the manual mode and then put the robot on the cable inside zone2, then the robot will work ;...
- Page 36 Length x Width x Height 50cmx35.5cmx24cm Weight 16Kg / 5200 mAH Adapter 29.4 V / 2.0A @ 100~240 V/ Boundary Wire Length 100m Blade Motor BLDC Blade Motor Speed 3200~3500rpm Wheel Motor BLDC Bump Sensor Rain Sensor Emergency Switch Measured Noise Level Guaranteed Noise Level Mowing Mowing System...
