- Page 1 Operating manual CABINETS | LOCKERS | BOXES The easy lock in every aspect...
-
Page 2: Table Of Contents
Index Operating manual Introduction Description Password Types Operating Modes Locker Mode (Multiple User Mode) Personal Mode Opening With User Password Changing User Password What If Forget The Passwords Service Password Opening With Service Password Changing Service Password Master Password Opening With Master Password Changing Master Password Programming The miniK10 Accessing The Program Menu... -
Page 3: Introduction
Introduction 1. Red LED Emergency 10. Lock Body 2. Green LED Battery 11. Battery Cover 3. Keypad Back Up 12. Battery Cover Screw 4. Lock Body 13. ID Label 5. Closing Position 14. Hand Knob Frame 6. Handle Indicator 15. Cam 7. -
Page 4: Description
Description: miniK10 electronic cabinet lock with master/manager code, personal use function- ality, and up to 10 years battery life. miniK10 can be installed for both right and left hand installations - anywhere that needs fl exibility of master/ manager codes. The eco-friendly miniK10 off ers both convenience of far lessfrequent battery changes and a more environmentally friendly solution. -
Page 5: Personal Mode
Attention: By default, the miniK10 is set to Locker Mode. The miniK10 can easily be set to Personal Mode with either of the two below steps: 1. Before battery tab is removed, hold down key, pull the tab and key the key pressed 3 seconds 2. -
Page 6: What If Forget The Passwords
NOTE: WHAT HAPPENS IF USER FORGETS THEIR PASSWORD? Locker Mode (Multiple User): Use Master code to unlock and turn handle to open position. Lock is now ready for next user to enter in their unique code.. Personal User Mode: 1) Use master code to reset the lock to factory defaults. MasterCode 2) Default user code is now <... -
Page 7: Master Password
You will get a confi rmation beep from lock. OLD PASSWORD NEW MASTER programming the miniK 10 The miniK10 can be customized from factory default settings tailored to your needs. accessing the program menu: Press the button and then enter the 6-digit master password. - Page 8 Explanation: 0-1 Restores factory default settings: Prog. No 1-1: Locker mode operation (Multiple user operation) Prog. No 2-1: Audible beeps and confirmations Prog. No 3-0: Penalty operation is not active Prog. No 4-0: Sets user password to factory default Prog. No 5-0: Service password is not activee Prog.
-
Page 9: Program Table
Programming option definitions: Restoring factory settings: All factory default settings are restored (see program menu). User password becomes <1-0-1-0> and master password becomes <1-0-1-0-1-0>. Usage options: Factory default is Personal mode allows one 4-digit code to be entered that would remain the same code for one user. Locker mode is for multiple users whereby each user walks up to an open miniK10 and enters in their own unique code to close the lock and then to open it again. -
Page 10: Maintenance
Maintenance: Clean front of lock with a mild damp cloth with detergent if needed. Use only Ethanol (Ethyl Alcohol) for disinfecting. Do not use any hard or scratching cleanser. Do not clean with chemical materials that melt plastic (thinner, acetone, etc.) Be careful not to spill water on lock. -
Page 11: Other
Other: Battery failure override- The miniK10 has 2 external nodes surrounding the red and green indicator lights where an external battery can be connected long enough to enter in the correct code to open the lock allowing new batteries to be installed. ATTENTION: In case of any failure, inform the vendor in writing of the detailed description of the failure. -
Page 12: Light And Audio Notification
Light and audio notification: Password is accepted Green LED blinks with 2 repeated audio warnings. Wrong password Red LED blinks with 4 repeated audio warnings. Low batterty Red LED blinks 5 times after each operation. 1 min after door is opened, lock gives audible warning Lock is open 8 times every 5 sec. -
Page 13: Quick Info
ATTENTION: Opening direction depends on which to MASTER PASSWORD type of door miniK10 is installed. All opening illustrations depict right handed door installation. MASTER PASSWORD setro s.r.o. can make changes about the qualifications of the product without informing in advance. -
Page 14: Installation
Installation CABINETS | LOCKERS | BOXES The easy lock in every aspect... -
Page 15: Installation Overview
Installation Overview 1. miniK10 2. M16x1,5mm Cylinder Nut 3. Stop Cam 4. Cam 22mm Axle 5. Cam 38mm Axle 6. M4x10mm Cam Screw 7-9. Mounting Screws Locking Position (Be sure before mounting). Hinge at the right side 90° Cover thickness Screw size Rotate Right 0 - 5 mm covers... -
Page 16: Mounting On Left & Right Door
Mounting on Left & Right Door RIGHT LEFT Hinges on Hinges on outside of outside of door are on door are on the Right the Left Peg on stop cam Peg on stop cam is on the right side for is on the left side for right doors left doors... - Page 17 Surface Mounting Semi-Flush Mounting...
- Page 18 70,4 g Assembly set is not. 18mm 18mm 18mm 18mm 24mm 27mm 12mm 27mm 24mm 27mm 12mm 27mm...
-
Page 19: Mounting Template
Ø 0,16” (4 mm) Mounting Template Upper Mounting Screw Hole Ø 0,63” (16 mm) Cylinder Hole... -
Page 20: Joint Erect Lock Assembly Measurements
Joint erect lock assembly measurements 22 mm axle cam 38 mm axle cam... -
Page 21: Recessed Cover Assembly Measurements
Recessed cover assembly measurements... -
Page 22: Overlapping / External Cover Assembly Measurements
Overlapping / external cover assembly measurements right cover on the body 4 mm hole 3 mm 27 mm 62 mm 42 mm 16 mm hole 22 mm cam... -
Page 23: Replacing Existing Lock
NOTE: Read instructions, set combination and test lock BEFORE installing!! Replacing existing lock: 1. Place mounting template centered on existing hole and mark upper mounting screw hole. 2. Drill mounting screw hole. 3. Install lock using adaptor if necessary. 4. Thread nut on cylinder. 5. -
Page 24: Warnings For Mounting
Warnings for mounting: Pull the transparent “Remove to Start” tag coming out of battery cap at the back of the lock and activate the lock. Read the user manual and apply password change and opening/closing operations several times before the mounting of the lock. Before mounting of the lock, switch lock handle to closing position. - Page 25 Spa and Baths Schools Staff Lockers Sports Halls In Mailboxes Hospitals setro s.r.o. | Majerská cesta 30/A 974 01 Banská Bystrica | Slovakia +421 48 414 45 19...
