Rentquip patron GI-3500 Operation Manual

Inverter generator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GI-3500
INVERTER
GENERATOR
operation manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the patron GI-3500 and is the answer not in the manual?

Questions and answers

Related Manuals for Rentquip patron GI-3500

Summary of Contents for Rentquip patron GI-3500

  • Page 1 GI-3500 INVERTER GENERATOR operation manual...

  • Page 2: Safety Warnings

    safety Save these Instructions SAFETy WARNINGS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING), a pictorial and/or a safety message to alert you to hazards.

  • Page 3: Safety Information

    safety SAFETy INFORMATION Read and understand this owner’s manual before operating your generator. It will help you avoid accidents if you get familiar with your generator’s safe operation procedures. DANGER Do not use indoors. DANGER Keep the machine clean and avoid spilling combustibles including gasoline on it.
  • Page 4 safety CONNECTION TO A HOME POWER SUPPly If the generator is to be used as standby home power supply the connection is to be performed by a qualified electrician. When loads are connected to the generator, carefully check whether electrical connections are safe and reliable.
  • Page 5 safety UNIT SAFETy SyMbOlS There is the warning label on the machine to remind you of the safety regulations. SyMbOlS Read the safety instructions before using the generator. Only fill the generator in well-ventilated areas and keep it away from open flames sparks and cigarettes Spilled fuel should be soaked up immediately.

  • Page 6: Control Panel

    control function Control Function DESCRIPTION 1. Fuel tank cap 2. Handle 3. Control panel 4. Inverter parts 5. Battery 6. Brake 7. Recoil starter grip 8. Shutter 9. Muffler 10. Oil drain bolt 11. Oil filler cap 12. Air cleaner 13.
  • Page 7 control function 3 IN 1 SWITCH kNOb 1. Engine/fuel valve OFF”; Ignition circuit is switched off. Fuel is switched off. The engine will not run. 2. Engine switch\fuel valve choke. “ON” Ignition circuit is switched on. Fuel is switched on. Choke is switched on. The engine will run.

  • Page 8: Oil Warning Light

    control function DIGITAl DISPlAy METER liquid crystal display Normal Operation: During the normal operation, the operation key (3) for switching the display cycle showing: voltage current power- accumulative time current time. 1. Multimeter 2. Liquid crystal display In case of failed operation: 3.

  • Page 9: Overload Indicator Light (Red)

    control function OvERlOAD INDICATOR lIGHT (RED) The overload indicator light comes on when an overload of a connected electrical device is detected, the inverter control unit overheats, or the AC output voltage rises. Then, the AC protector will trip, stopping power generation in order to protect the generator and any connected electric devices.

  • Page 10: Ground (Earth) Terminal

    control function DC PROTECTOR The DC protector turns to “OFF” automatically when electric device being connected to the generator is operating and current above the rated flows. To use this equipment again, turn on DC protector by pressing its button to “ON”. 1.
  • Page 11 operation Pre-Operation NOTICE • Pre-operation checks should be made each time operation. WARNING • The engine and muffler will be very hot after the engine has been run. Avoid touching the engine and muffler while they are still hot with any part of your body or clothing during inspection or repair.
  • Page 12 operation ENGINE OIl The generator has been shipped without engine oil. Do not start the engine until filled with the sufficient engine oil. Do not tilt the generator when adding engine oil. This could result in overfilling and damage to the engine. Recommended engine oil: SAE 10W -30 Recommended engine oil grade: API Service SE type or higher...
  • Page 13 operation Operation NOTICE • Never operate the engine in a closed area or it may cause uncon- sciousness and death within a short time. Operate the engine in a well ventilated area. The generator has been shipped without engine oil. Do not start the engine until filled with the sufficient engine oil.

  • Page 14: Stop The Engine

    operation Electric Start Turn the engine switch on the control panel to ON Or press it to START if it is electrical start state then generator unit can be started In order to extend the service life of the storage battery do not press on the switch for more than 3 seconds and the interval between two pressings should be longer than 10 seconds.
  • Page 15 operation TIP: Turn off any electric devices. 1. Disconnect any electric devices. 2. Turn the ESC to “OFF” (1). 3. Turn the 3 in 1 switch to “OFF” (2). a. Ignition circuit is switched off. b. Fuel valve is switched off. AlTERNATING CURRENT (AC) CONNECTION WARNING •...

  • Page 16: Battery Charging

    operation • If the generator is overloaded, or if there is a short circuit in a connected appliance, the overload indicator (red) will go ON. The overload indicator (red) will stay ON, and after about 4 seconds, the connected appliance(s) will shut off, and the output indicator (green) will go OFF. Stop both engines and investigate the problem.

  • Page 17: Ac Parallel Operation

    operation TIP: • Follow instructions in the owners manual for the battery to determine the end of battery charging. • Measure the specific gravity of electrolyte to determine if the battery is fully charged. At full charge, the electrolyte specific gravity is between 1.26 and 1.28.

  • Page 18: Ac Parallel Operation Applications

    operation AC PARAllEl OPERATION APPlICATIONS TIP: • Make sure that it is in good working order. A faulty appliance or power cord can create a potential for electrical shock. • If an appliance begins to operate abnormally, becomes sluggish, or stops suddenly, turn it off immediately.

  • Page 19: Application Range

    operation APPlICATION RANGE When using the generator, make sure the total load is within rated output of a generator. Otherwise, generator damage may occur. Power 0.8-0.95 0.4-0.75 Factor (Efficiency 0.85) GI-3500 ~3,000W ~2,400W ~1,200W Rated voltage 12V Rated current 8A TIP: •...
  • Page 20 operation NOTICE • Do not overload. The total load of all electrical appliances must not exceed the supply range of the generator. Overloading will damage the generator. • When supplying precision equipment, electronic controllers, PCs, electronic computers, microcomputer based equipment or battery chargers, keep the generator a sufficient distance away to prevent electrical interference from the engine.
