Summary of Contents for CROWN LINE IM-263
- Page 1 INSTRUCTION MANUAL ICE MAKER Model: IM-263 THANK YOU FOR CHOOSING OUR ICE MAKER PLEASE READ THE MANUAL CAREFULLY BEFORE OPERATING...
-
Page 2: Important Notices
IMPORTANT NOTICES When using an electrical appliance, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury, including the following: 1. Read all instructions before using. 2. Remove all packing material and carefully check your ice maker to ensure it is in good condition and that there is no damage to the ice maker or power cord and plug. - Page 3 supervised to ensure that they do not play with the appliance. 13. Do not use the appliance close by flames, hot plates or stoves. 14. Do not switch on the power button frequently (ensure 5min. interval at least) to avoid the damage of compressor. 15.
- Page 4 Warning; Risk of fire / flammable materials. WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged. WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.
-
Page 5: Specifications
SPECIFICATIONS Model number：IM-263 Daily ice output：12kg / 24 hours Ice storage capacity：1.6L/850g Refrigerant：R600a Compression-type refrigeration:220V/60Hz Water tank capacity：1.5 L Voltage: 220V Frequency: 50 Hz Power consumption: 120 W Max overall dimensions(W×D×H)：224X 308X283mm Packing dimensions(L×W×H)： 360*274*340mm N.W.：7.9Kg G.W.：9.1Kg... - Page 6 DESCRIPTION Buttons Upper cover Transperent upper cover Bullet evaporator Water Tray Ice shovel board Ice basket Rear housing Front housing Ice shovel...
- Page 7 FEATURE Quick ice making Prompt when the ice is full and water is insufficient Bullet ice 9 pcs ice can be made in eight minutes Cleaning function 1. During transportation, do not tilt the machine more than 45 degrees, do not reverse the machine.
-
Page 8: Control Panel Operation
CONTROL PANEL OPERATION ON/OFF: ON-OFF switch button Clean: Cleaning function button ICE FULL: Ice full alarm ADD WATER: Water shortage alarm ICE MAKING: Ice making 1). Plug in the power, the "ICE MAKING " indicator flashes, and the machine will start the deicing function. Press the ON/OFF button, the "ICE MAKING"... - Page 9 When the ice reaches the maximum capacity of the ice storage container, the "ICE FULL" light flashes, and the machine stops. At this time, the ice needs to be poured out. When the ice position is lower than the full sensor position, the machine will restart automatically.
- Page 10 not let the ice overflow the ice basket. 1. When the indoor temperature is lower than 15 degrees, please choose small ice. When the indoor temperature is higher than 30 degrees, it is recommended to choose big ice. 2. The three cycles used for the first time, the ice produced is small and irregular.
-
Page 11: Troubleshooting
5. If the compressor takes a strike action for shortage water, fully water or interruption of power supply, it will delay for 3mins to start up after restarted. 6. Always use fresh water before starting ice production either at initial installation or after a long shut-off period. TROUBLESHOOTING Please note, if a power failure occurs due to disconnection of the power cord, or the power button has been pushed off during an ice... - Page 12 The Ice made is too large Ice of previous cycles left in Take out the ice under the standby and with pieces sticking the water tray state together. The compressor has The ice making process no refrigerant was correct, but no ice Compressor damaged Call the service hotline came out?
- Page 13 temperatures between 70°C and 90°C during operation and surrounding areas may be very hot. 4. Due to fast freezing, ice cubes may appear “Cloudy”. This is air trapped in the water and will not affect quality or taste of ice. 5.
