  • Page 1 Nabb021_FR_EN AA1-097 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY USING INSTRUCTION...
  • Page 3 1. Guidon 2. Levier de serrage rapide du guidon 3. Bouton à ressort de la colonne de direction 4. Freins/garde-boue 5. Poignée du mécanisme de pliage 6. Mécanisme de pliage 7. Tige du guidon 8. Levier de serrage rapide de la colonne de direction 9.
  • Page 4 Assemblage de la trottinette A- Retirer le bouchon en plastique Débloquez le mécanisme de verrouillage du guidon (11) et retirez le bouchon en plastique (13), afin de pouvoir y insérer le guidon (1). B- Déplier la colonne de direction Tirez la poignée (5) du mécanisme de pliage et libérez le mécanisme de pliage (6).
  • Page 5 Plier la trottinette E-Pliage du guidon Déverrouiller le levier de serrage rapide de la colonne de direction (8), appuyez sur les boutons à ressort de la colonne de direction (3), abaissez le guidon (7), puis resserrez le levier de serrage rapide de la colonne de direction (8). F - Rangement du guidon Débloquer le mécanisme de verrouillage du guidon (11), appuyer sur le bouton à...
  • Page 7 1.Handlebar 2.Rapid tightening lever for handlebars 3.Steering column spring button 4.Brakes/ mudguard 5.Handle of folding mechanism 6.Folding mechanism 7.Handlebar stem 8.Rapid tightening lever for steering column 9.Steering column 10.Bell 11.Handlebar locking mechanism 12.Handlebar spring button 13.Plastic stopper...

  • Page 8: Scooter Assembly

    Scooter assembly A- Take out the plastic stopper Open the handlebar locking mechanism (11) and remove the plastic plug (13), So that the handlebar (1) can be inserted therein. B- Unfold the steering column Pull the handle (5) of the folding mechanism and open the folding mechanism (6).

  • Page 9: Folding The Scooter

    Folding the scooter E-Folding down the handlebars Open the rapid tightening lever for the steering column (8), press the steering column Spring buttons (3), lower the handlebar (7), and then fasten the rapid tightening lever For the steering column (8) F - Packing away the handlebars Open the handlebar locking mechanism (11), press the spring button (12) on each Handlebar, take out the handlebar from both sides of the handlebar stem...
