A packet with complete set of hardware can be found by pulling the red ribbon that's easily visible upon opening the box.
Thank you for purchasing Leick Furniture products.
Contact customer service for comments or concerns.
800-558-8700
cs@todaysdesignhouse.com
Assembly Instructions, #9500
Leah Mini Bar
---1/4---
todaysdesignhouse.com
Top Panel
A
B
Left Side Panel
Right Side Panel
C
D
Drawer box
X-rack panels
E
F
Bottom Panel
G
Back Panel
H
Allen Wrench
Long Bolts
I
J
Lock Washers
Flat Washers
K
L
Drawer Pull
M
N
Screws
O Wood Dowels
1
1
1
1
2
1
1
1
12
12
12
1
2
16
12
