Page 1 Service Manual Ver. 2 INTEGRATED NETWORK AV RECEIVER Click here! AVR-X4300H On-line service parts list We are getting ready. On-line owner's manual http://manuals.denon.com/AVRX4300H/NA/EN/index.php http://manuals.denon.com/AVRX4300H/EU/EN/index.php CAUTION IN SERVICING ELECTRICAL MECHANICAL REPAIR INFORMATION UPDATING • For purposes of improvement, specifications and design are subject to change without notice. Please refer to the MODIFICATION NOTICE. • Please use this service manual with referring to the operating instructions without fail.
Page 2 CAUTION IN SERVICING SAFETY PRECAUTIONS NOTE FOR SCHEMATIC DIAGRAM NOTE FOR PARTS LIST INSTRUCTIONS FOR HANDLING SEMICONDUCTORS AND OPTICAL UNIT CAUTION IN SERVICING. Initializing This Unit JIG FOR SERVICING...
Page 3 SAFETY PRECAUTIONS ◎ Make a safety check after servicing! The following items should be checked for continued protection of the customer and the service Check that all screws, parts and wires removed or disconnected when servicing have been put back technician.
Page 4 NOTE FOR SCHEMATIC DIAGRAM WARNING: Parts indicated by the z mark have critical characteristics. Use ONLY replacement parts recommended by the manufacturer. CAUTION: Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis resistance check.
Page 5 CAUTION IN SERVICING. Initializing This Unit Make sure to initialize this unit after replacing the microcomputer or any peripheral equipment, or the digital PCB. 1. Press the power button to turn off the power. 2. While holding down buttons "CURSOR d " and "CURSOR f " simultaneously, press the power button to turn on the power.
Page 6 ELECTRICAL SCHEMATIC DIAGRAMS BLOCK DIAGRAM SCH35_FRONT SCH36_SMPS SCH01_DIGITAL CONNECT ANALOG AUDIO DIAGRAM SCH02_DIGITAL POWER DIGITAL AUDIO DIAGRAM PRINTED CIRCUIT BOARDS SCH03_MAIN CPU ANALOG VIDEO DIAGRAM SCH04_EXPANDER HDMI DIAGRAM DIGITAL, F HDMI SCH05_CPU LEVEL CHG INPUT, USB POWER DIAGRAM SCH06_DIR VIDEO, SIDE CNT, GUIDE, FRONT CONT FFC SCH07_AUDIO PLD SPK, SPK H2L, GUIDE TRANS, GUIDE TOP, GUIDE SIDE SCH08_DSP1...
Page 7 SCHEMATIC DIAGRAMS SCH01_DIGITAL CONNECT TO 0A TO DIGITAL SUPPLY (PAGE 2_B1) DAC input BN27A L1001 CH1: DATAF R1021 OPEN CPUPOWER R1022 OPEN M3.3V R1023 OPEN DGND CH2: DACLRCK BN24A RC_IN KILLIR_MZ A-7V RC_OUT_MZ A+7V FRONT_IRIN CH3: DACBCK A+5V A+5V FLASHER_IN_MZ A+5V TO 3A AGND...
Page 8 SCH02_DIGITAL POWER CN903 PJ02 PJ01 L1221 BLM21PG221SN1 L1222 DGND D5.2V BLM21PG221SN1 L1223 D5.2V BLM21PG221SN1 M_RESET TO BN901 DGND R1111 DV_POWER2 DGND DV1.8V IC111 L1113 L1111 TPS563200DDCR L1224 MAINPOWER 1.34A CB03YTYH600 CB03YTYH600 BLM21AG121SN1 L1112 L1115 L1114 OPEN (5040) 3.6uH CB03YTYH600 CN903 L1225 CJP06GA353ZJ B6B-EH-A...
Page 9 SCH03_MAIN CPU TO 2D TO 1D TO A5 TO B9 TO B1 TO B5 TO B7 TO B8 TO LEVEL CHG. (PAGE 5) TO DIGITAL CNT (PAGE 1) R1577 4.7K DA_MS DA_CK R1578 OPEN R1579 OPEN DA_MD R1581 OPEN TO B6 DSP_ICS DSP_ICS DSP_MOSI...
Page 10 SCH04_EXPANDER TO 4E TO 5E TO 6E TO 7E TO A8 TO B4 VIDEO PLD DIGITAL CNT HDMI SW1 (PAGE 16_C6) HDMI SW2 PAGE 1 (PAGE 13_A4) (PAGE 14_A3) TO B0 R1702 4.7K SWM3.3V M3.3V AEXP_OE AEXP_CLK AEXP_DATAIN AEXP_STB DGND IC176 IC171 IC172...
Page 11 SCH05_CPU LEVEL CHG TO D2 TO B2 TO C2 (PAGE 3_D5) FROM MAIN CPU TO DIGITAL CONNECT (PAGE 1_A4) TO DIGITAL SUPPLY POWER (PAGE 2_B1) T206 T186 T185 3.3K R1967 2SC3052 2SC3052 2SC3052 Q1907 Q1910 Q1913 T246 T247 T187 T188 Q1922 Q1923 Q1902...
Page 12 DIRAUXMCK Z2DIRLRCK LRCKO DIRSLRCK C2011 R2024 DIRSLRCK Z2DIRBCK DIRSBCK COAX OUT 1/10V Z2DIRMCK DIRSBCK DEMZ2 BCKO DIRPERR Q2002 DIRPERR (DENON LINK HD) DIRNPCM DIRNPCM MCKO IC203 RT1N144C LC89091JA-H HDMISPDIF HDMISPDIF DENONLINKHD DENONLINKHD ZONE3 IC204 LC89091JA-H Z2DIRPERR Z2DIRPERR DEMZ2 DEMZ2 Z2DIRNPCM...
Page 13 SCH07_AUDIO PLD MCU_VL_MUTE MCU_VL_MUTE VOLUME_MUTE VOLUME_MUTE TO E2 JTAG_TMS PLDAERR1 TO MAIN CPU PLDAERR1 (PAGE 3_C1) JTAG_TDI Z2PLDAERR Z2PLDAERR JTAG_TCK Z3PLDAERR Z3PLDAERR R2249 AP_DA IC222 TDO1_TDI2 SPDIF_OUT PLD_WRITE SPDIF_OUT OPEN C2201 C2203 AP_CK AP_CS MCLK_I2S_0 MCLK_I2S_0 LRCK_I2S_0 LRCK_I2S_0 APLD_CS TO LEVEL CHG TO E8 SDIN_I2S_0 AVRX4300H...
Page 14 SCH08_DSP1 TO F6 TO 0H TO F7 TO 9G TO 8G TO 7G TO 6G TO E3 FROM A.PLD PART TO DSP2 PART FROM MAIN CPU PART FROM AUDIO PLD TO DSP2 PART TO DSP4 PART TO DSP3 PART TO DSP2 PART (PAGE 7_A5) (PAGE 8-2_D5) (PAGE 7_A5)
Page 15 SCH09_DSP2 TO H0 TO G9 TO 1H TO G6 TO F8 TO DSP3 PART FROM DSP1 PART TO A.PLD FROM DSP1 PART FROM DSP1 PART (PAGE 8-3_D3) (PAGE 8-1_D2) (PAGE 7_A4) (PAGE 8-1_D4) (PAGE 8-1_D3) D3I_FW D3I_CSW D3I_FH D3I_SB D3I_RSV D3I_F D3I_S C2645...
Page 16 SCH10_DSP3 TO F5 TO 4H TO F9 TO H1 TO G7 FROM DSP2 PART ADUDIO PLD PART FROM DSP1 PART TO DSP4 PART FROM AUDIO PLD (PAGE 8-2_D3) (PAGE 8-4_D5) (PAGE 7_A4) (PAGE 8-1_D2) (PAGE 7_A5) IC272 C2745 1000P A3V56S40GTP-60 256M BIT SDRAM C2737 C2746 0.1...
Page 17 SCH11_DSP4 TO H4 TO G0 TO G8 FROM DSP3 PART ADUDIO PLD PART FROM DSP1 PART (PAGE 8-3_D4) (PAGE 7_A3) (PAGE 8-1_D2) IC282 C2855 1000P A3V56S40GTP-60 256M BIT SDRAM C2847 C2856 0.1 VDD_INT DAI_P09 R2845 DSP4_FLAG0 FLAG0 DAI_P05 R2846 4.7K DQ15 DSP4D0 C2857 0.1...
Page 18 SCH12_ADC TO G1 TO D5 (PAGE 7_A3) (PAGE 3_C6) (PAGE 6_C5) TO AUDIO PLD TO MAIN CPU TO DIR A+5V AD_VDCOM ADINL ADINR DAGND TO A3 C3055 C3056 C3057 1000P C3058 1000P C3061 1000P C3062 1000P C3063 1000P C3064 1000P C3066 1000P C3067 1000P C3068 1000P...
Page 19 SCH13_ZONE DAC TO G2 (PAGE 7_A2) TO AUDIO PLD IC323 BU33TD3WG VIN VOUT ZONE_DAC STBY ZONE2 DAC IC321 PCM5100PWR DVDD CPVDD C3201 C3203 DGND CAPP C3202 2.2/6.3V LDOO CPGND XSMT CAPM Z2DACMUTE VNEG LRCK OUTL R3203 Z2DACLRCK DAZONE2L OUTR R3204 TO DIGITAL CONNECT Z2DACDATA DAZONE2R...
Page 20 SCH14_LEGO FROM LEGO MODULE 80 Pin CONNECTOR 42 Pin CONNECTOR CN502 CN501 CJP80GA370ZU CJP42GA370ZU R5032 LEGO5V AVRX4300H DGND BK106 BK107 BK108 BK109 VMD1A960 VMD1A960 VMD1A960 VMD1A960 NET3.3V C5011 OPEN VOUT_D22 VOUT_D23 TO C3 IC521 VOUT_D20 OPEN VOUT_D21 VOUT_D18 VOUT_D19 VOUT_D16 VOUT_D17 C5012 VOUT_D14...
Page 21 SCH15_VIDEO DECODER TO C5 (PAGE 2_B3) FROM DIGITAL SUPPLY POWER L3501 L3506 L3509 BLM21PG221SN1 BLM21PG221SN1 BLM21PG221SN1 L3502 L3510 L3507 BLM21PG221SN1 BLM21PG221SN1 BLM21PG221SN1 L3503 L3511 BLM21PG221SN1 BLM21PG221SN1 L3508 BLM21PG221SN1 L3504 BLM21PG221SN1 L3512 BLM21PG221SN1 L3513 L3505 BLM21PG221SN1 BLM21PG221SN1 C3502 OPEN C3503 OPEN C3504 REFP REFN...
Page 22 SCH16_HDMI SW2 CEC5V CEC3.3V L3801 BLM21PG221SN1 VDD33 Q3841 CEC1.1V-2 HDMI_SW2 DGND Q3842 TO C9 RT1N141C HPD1 L3802 HPD1 AVDD33TX BLM21PG221SN1 R3845 RX1_C- RT1N141C RX1_5V RX1_C+ +5V_1 RX1_0- 19.HP DET 18.+5V RX1_0+ 17.GND RX1_1- C3860 L3809 R3847 16.DDC DATA RX1_1+ RX1_DDCDA AVDD33RX CLZBLM21PG300SN1D 15.DDC CLK...
Page 23 SCH17_HDMI SW1 Z2_CEC5V CEC5V HDMI_SW2 P2_C- CEC3.3V L3901 P2_C+ VDD33 BLM21PG221SN1 P2_D0- CEC1.1V-1 P2_D0+ DGND P2_D1- P2_C- P2_D1+ P2_C- P2_C+ P2_D2- L3902 P2_C+ AVDD33TX BLM21PG221SN1 P2_D0- P2_D0- P2_D2+ TO C8 P2_D0+ P2_D0+ P2_D1- P2_D1- RX5_C- P2_D1+ RX5_C+ P2_D1+ P2_D2- RX5_0- P2_D2- L3910 AVDD33RX...
Page 24 SCH18_VSP & IP & OSD FROM DIGITAL POWER SUPPLY (PAGE 2_B3) TO C6 L4001 CB03YTYH600 L4002 CB03YTYH600 L4003 L4008 L4013 CB03YTYH600 CB03YTYH600 CB03YTYH600 L4004 L4010 CB03YTYH600 CB03YTYH600 L4016 CB03YTYH600 L4012 L4005 CB03YTYH600 L4014 CB03YTYH600 CB03YTYH600 IC403 IC402 A3R12E40DBF-8E L4006 A3R12E40DBF-8E 512Mbit DDR2 SDRAM L4015 512Mbit DDR2 SDRAM...
Page 25 SCH19_VIDEO PLD TO C7 TO G4 FROM DIGITAL POWER TO AUDIO PLD (PAGE 2_B3) (PAGE 7_D1) MCU&CY920 ADV8003 RN429 33x4 VPLD_TRANS2 VPLD_TRANS2 VPLD_TRANS1 PO8KI_C9/G1_PLD PO8KI_C9/G1 FROM EXPANDER VPLD_TRANS1 VPLD_TRANS0 PO8KI_Y0/G4_PLD PO8KI_Y0/G4 VPLD_TRANS0 PO8KI_Y11/R7_PLD PO8KI_Y11/R7 (PAGE 4_C4) RGB/YC RGB/YC PO8KI_Y3/G7_PLD IO-001 IO-081 8KOPI_HSYNC NET/HDMI...
Page 26 SCH20_HDMI TX & SCALER CEC5V CEC3.3V L4308 AVDD11TX CEC1.1V-3 VDD33 BLM21PG221SN1 C4403 OPEN L4305 DGND BLM21PG221SN1 L4301 C4402 OPEN VDD11 BLM21PG221SN1 C4401 OPEN JK432 C4400 OPEN HDMI_OUT A0D7ABAR1990 TO D0 L4321 PTX0_2+ 1.D2+ L4310 AVDD11RX L4309 AVDD33RX C4409 OPEN PTX0_2- 2.D2 SHIELD CLZBLM21PG300SN1D C4408...
Page 27 SCH21_INPUT BN64C BN24C BN23C TO CN64C TO CN24C TO CN23C FROM SIDE CONNECT PART FROM SIDE CONNECT PART FROM FRONT CONNECT PART (PAEG 27_B2) (PAEG 24_B2) (PAEG 27_B4) BN23C BN64C BN24C C125Z2-11 C125Z2-27 C125Z2-19 BN322A R4779 TO BN322B R4778 R4843 100K R4761 R4772...
Page 28 SCH22_PREOUT PREOUT PART DPP -> LPP C8992 0.1uF R8849 C8849 10/50V use EMI C8993 0.1uF D8845 1N4007 C8996 BN26C 0.1uF C8913 C8917 D8846 1N4007 R8846 R8913 R8915 R8921 P_PREZ2L C8994 0.01uF C8991 D8847 C8995 0.01uF 1N4007 22/50V 22/50V P_PRESW1MUTE R8925 R8927 C8997 0.01uF...
Page 29 SCH23_F-HDMI Q1001 Q1002 RT1P141C R1002 RT1N241C JK101 A0D7ABAR19N0 C1001 R1003 T103 19.HP DET 18.+5V T102 CEC5V 17.GND L1001 16.DDC DATA CN101 T104 60R/3A 15.DDC CLK T105 CN101 14.NC 13.CEC CJP23GA333ZR 12.CK- 11.D1 SHIELD CEC3.3V L1002 DDCD_SDA 10.CK+ DDCD_SCL 9.D0- 60R/3A TXEN 8.D1 SHIELD HPA_D...
Page 30 SCH24_A-VIDEO VIDEO+5V VGND VIDEO-5V ANALOG VDIEO PART TO 7J IC513 NJM2845DL133 +3.3V LEGO_FAN_POWER LEGO_FAN_GND LEGO_FAN_ON CVBS IN/OUT JK511 TO 8J C5107 CBL/SAT SAT_CVBS_IN 50V/10uF C5108 DVD_CVBS_IN 50V/10uF R5183 DEC_CVBS_IN C5109 GAME R5184 DEC_Y_IN GAME_CVBS_IN 50V/10uF R5185 DEC_PB_IN R5186 MONITOR DEC_PR_IN R5187 75(1%) R5111...
Page 31 SCH25_RC-5 RC-5 OPEN R5311 BN27B R5312 Q5313 BN27B RT1P141C Q5311 L5311 60R/3A(BEAD) RT1P141C M3.3V 60R/3A(BEAD) Q5312 L5312 DGND RT1N141C L5313 60R/3A(BEAD) RC_IN L5314 60R/3A(BEAD) KILLIR RC_OUT FRONT_IRIN 60R/3A(BEAD) L5315 FLASHER_IN Q5314 REMOTE3.3V RT1P141C 232O_MI 232I_MO TRIGGER_1 TRIGGER_2 JK531 B/P_IRIN_AVR R5314 D5311 OPEN Q5315...
Page 32 SCH26_RS232C_TRIGGER IR / FLASHER RS232C/TRIGGER IC521 C5237 C5236 ILX3232DT 50V/0.1uF 50V/10uF C5231 C5235 C5245 50V/0.01uF 50V/0.1uF 50V/0.1uF C5246 50V/0.1uF C5247 OPEN D5231 JK525 OPEN T1_O R5234 Q5251 RS-232C RT1P141C R1_I R5233 D5232 C5233 R1_O OPEN 50V/0.1uF Q5252 2SC3052 C5234 T1_I C5241 50V/0.1uF JK521...
Page 33 SCH27_SIDE CNT CN23A CN27A SIDE CNT_CUP12857Z(CONNECT A) TO BN23A TO BN27A FROM DIGITAL CON.PART FROM DIGITAL CON.PART PAGE 1_D1 PAGE 1_C1 CN23A CN27A C125Z1-25 C125Z1-15 CN961 TUNER_R TU_GND TUNER_L TU_+5V TU_+5V TU_GND TU_GND TU_CE TU_CE TU_RST TU_RST TU_INT TU_INT TU_RXMO/SCL TU_RXMO/SCL TU_TXMI/SDA TU_TXMI/SDA...
Page 34 SCH28_FRT CNT CN21A CN25A CN26A CN24A TO BN21A TO BN25A TO BN26A TO BN24A FROM/TO DIGITAL CON. PART FROM/TO DIGITAL CON. PART PAGE 1_B3 FROM/TO DIGITAL CON. PART FROM/TO DIGITAL CON. PART PAGE 1_D3 PAGE 1_D5 PAGE 1_B5 FRT CNT CONNECT B CN26A CN21A CN25A...
Page 35 SCH29_MAIN DAC1 A+5V C3055 0.1uF TO K3 A-7V C3056 0.1uF A+7V C3057 1000pF C3058 1000pF DAGND C3059 OPEN C3060 OPEN C3061 1000pF C3062 1000pF C3063 1000pF R3017 C3064 0.1uF R3021 4.7K C3065 0.1uF C3066 0.1uF R3013 C3017 R3027 R3025 C3067 1000pF 680pF 3.9K...
Page 36 SCH30_MAIN DAC2 A+5V C3147 0.1uF A-7V C3148 0.1uF C3149 1000pF A+7V C3150 1000pF DAGND C3151 OPEN C3152 OPEN TO K9 C3153 0.1uF C3154 0.1uF R3125 C3155 1000pF R3123 4.7K C3156 1000pF ASSIGNR1 C3125 R3127 R3113 3.9K R3121 680pF 3.9K R3119 R3111 (GRM21) C3130...
Page 37 SCH31_SPK R9211 BN701 JK921 2W/10 C9211 BN701 0.047uF(M) L9201 C9531 0.01uF(M) C9511 OPEN +HIGHB 0.5uH R9201 JK922 JW934A JW931A 1W/10 R9212 JW929A JW927A JW927B JW926A HIGH_GND R9202 2W/10 0.01uF(M) OPEN C9532 C9512 JW933A JW932A TO CN701 1W/10 C9212 F_RLY L9202 0.5uH 0.047uF(M) JK923...
Page 38 SCH32_REGULATOR CN711 20010WS-03 Q9402 CJP03GI352ZY 2SA2166 MAX 130mA R9400 FAN1_OUT 0(3216) R9401 FAN PART OPEN FAN1_GND Q9406 KTC3964 Q9404 FAN2_OUT Q9403 RT1P144C RT1N237C FAN2_GND FANCONT_ON1 CN712 20010WS-03 CJP03GI352ZY Q9405 FANCONT_L_ON1 RT1N237C TO K7 Q9412 MAX 130mA 2SA2166 R9410 0(3216) R9411 OPEN Q9416 KTC3964...
Page 39 SCH33_5CH AMP Point C1 D7102 R7116 R7117 63.7V OPEN R7118 R7138 R7115 1.2K(1608) 1.2K(1608) 1W/270 R7119 PTC 115'C 470 ohm D7101 OPEN CN715 1W/270 62.9V OPEN Q7114 R7137 Q7138 MMBT5401 D7118 58.5V MMBT5401 1SS133M 1.1V 680K(1608) 0.6V C7111 C7108 Q7118 R7129 R7143 OPEN...
Page 40 SCH34_4CH AMP D7602 R7616 R7617 OPEN R7615 R7618 R7638 1.2K(1608) 1.2K(1608) R7619 D7601 OPEN 1W/270 CN765 PTC 115'C 470 ohm 1W/270 OPEN Q7614 R7637 Q7638 D7618 MMBT5401 MMBT5401 680K(1608) C7611 1SS133M C7608 Q7618 R7629 R7643 D7639 R7639 OPEN KTA1024Y OPEN 1W/22 Q7631 C7604...
Page 41 SCH35_FRONT CN69A FROM DIGITAL CONNECT (PAGE 1_B1) TO CN69B LUG61 OPEN FIL1 R6003 VOLUME ENCODER PART FIL1 R6004 OPEN SWM3.3V FIL2 SWM3.3V FIP POWER PART OPEN VSELA VSELA R6352 R6354 DGND 4.7K C6904 OPEN VSELB OPEN FIL2 R6005 C6905 OPEN FRONT_IRIN AC37V C6906...
Page 42 SCH36_SMPS OPTION AC100 ~ 120V CCQF2E104KZE-T AC220 ~ 240V OPEN BK901 OPTION CMD1A834 AC100 ~ 120V : T 2A L 250V C9002 OPTION OPTION OPTION AC220 ~ 240V : T 1.6A L 250V 0.01uF/250V CHGND J9008 F9001 1N4007 D9001 JK901 C3A206 CJJ8A023Y 1N4007...
Page 43 PRINTED CIRCUIT BOARDS DIGITAL, F HDMI Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu). DIGITAL (A SIDE) F_HDMI(A SIDE) BK101 D4332 D4312 D3804 R3844 CUP12867Z_MP T114 JK201 M2_DA M1_DA R3848 Z2_DA C2007 JK432 R3847 D4336 R3843 R4353 R3979 D3803 T192 T117 C1027...
Page 44 INPUT, USB INPUT (A SIDE) INPUT (B SIDE) USB (A SIDE) USB (B SIDE)
Page 45 J9632 LEGO_FAN ON J9631 VGND VGND C5234 CN28B C5328 D5321 C5233 R5233 AVR-X4300 C5231 CN27B 232O_MI CN27B R5326 J9661 J9632 AVR-X4300H 232I_MO R5327 R5234 CN28B R5325 REMOTE_+3.3V J9662 C5163 C5232 C5247 C5237 C5246 Q5251 Q5252 C5245 D5325 R5253 CN961 C5161...
Page 46 SPK, SPK H2L, GUIDE TRANS, GUIDE TOP, GUIDE SIDE SPK (A SIDE) SPK H2L (A SIDE) SPK H2L (A SIDE) CN951 JK930 CUP12852Z_A-2 MP J9252 J9253 C9539 JK924 C9534 JK929 JK923 JW930A JK928 JK931 C9541 JK926 C9536 J9254 C9537 JK925 C9535 C9533 JK921...
Page 47 5CH AMP, 4CH AMP 5CH AMP (A SIDE) 5CH AMP (B SIDE) 4CH AMP (A SIDE) 4CH AMP (B SIDE) J7128 D7402 D7401 C7423 R7415 R7417 R7416 R7435 Q7439 C7419 D7419 R7735 D7702 R7715 R7135 C7723 R7136 D7102 R7115 R7717 R7716 C7123 C7719...
Page 48 FRONT, HDMI FFC TOP, HP FRONT (A SIDE) HDMI FFC TOP (A SIDE) JW605 C6082 C6035 BK606 C6027 C6008 BK603 JW604 LUG61 FRONT HDMI FRONT HDMI FL601 CN69A JW603 CN602 CN602 7.VKK 7.VKK C6025 FFC CABLE B'D FFC CABLE B'D J6012 6.NC 6.NC...
Page 49 FRONT CNT, TUNER, BKT, SMPS FRONT CNT (A SIDE) FRONT CNT (B SIDE) SMPS (A SIDE) SMPS (B SIDE) Sec. Sec. Sec. Sec. Pri. Pri. Pri. Pri. Pri. Pri. Sec. Sec. Pri. Pri. Sec. Sec. C9008 C9007 Q9003 D9010 R9037 C9006 R9043 R9035...
Page 50 LEVEL DIAGRAM FRONT ch AVR-X4300H LEVEL DIAGRAM FRONT ch NJU72343 NJU72750 ANALOG H/POUT NJU72751 NJU72750 SPEAKER LINE ＋ GAIN ADJ. － AK4458 MIC IN ＋＋＋ AK5358 －－ MUTE PRE OUT TO ZONE2 x4pcs TO ZONE3 +30dB 4.24Vrms/8Ω...
Page 51 CENTER and SURROUND ch AVR-X4300H LEVEL DIAGRAM CENTER/SURROUND ch NJU72343 SPEAKER ＋ GAIN ADJ. AK4458 ＋＋－－ MUTE PRE OUT x4pcs +30dB 4.24Vrms/8Ω Volume IC: NJU72343 NON CLIP MAX SIGNAL LEVEL 4.2Vrms SPK OUT DAC:AK4458 1.98Vrms=0dBFS FULL SCALE LEVEL = 2.0Vrms...
Page 52 SUBWOOFER ch AVR-X4300H LEVEL DIAGRAM SUB WOOFER ch NJU72343 GAIN ADJ. AK4458 ＋＋－－ MUTE PRE OUT x4pcs +30dB +30dB FULL SCALE LEVEL Volume IC: NJU72343 NON CLIP MAX SIGNAL LEVEL 4.2Vrms DOLBY LIMIT LEVEL (ALL ch -3dBFS)
Page 53 ASSIGN1/2 ch (SURROUND BACK/HEIGHT1/HEIGHT2) AVR-X4300H LEVEL DIAGRAM ASSIGN1/2 (SURROUND BACK/HEIGHT1/HEIGHT2) ch NJU72343 NJU72750 SPEAKER ＋ GAIN ADJ. AK4458 ＋＋－－ MUTE PRE OUT x4pcs +30dB 4.24Vrms/8Ω Volume IC: NJU72343 NON CLIP MAX SIGNAL LEVEL 4.2Vrms SPK OUT DAC:AK4458 1.98Vrms=0dBFS...
Page 54 ZONE2/ZONE3 ch AVR-X4300H LEVEL DIAGRAM ZONE2/ZONE3 NJU72750 LINE To MAIN MUTE PRE OUT MONO PCM5100 NJW1194V MONO Z2 DAC NJU72750 MONO NJW1194V ＋ SPEAKER PCM5100 Z3 DAC MONO MUTE PRE OUT +30dB NJW1194V MAX. OUTPUT 4.2Vrms SP OUT 4.24Vrms/8Ω PCM5100 MAX.
Page 55 BLOCK DIAGRAM ANALOG AUDIO DIAGRAM AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR...
Page 56 DIGITAL AUDIO DIAGRAM AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK Z2DIRSPDIF #145 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 ADCLRCK DIRSLRCK OPT1(TV) OPT.0 DIRSBCK ADCSBCK OPT.1 OPT.1 ADINR AK5358BET (To MAIN DIR) BCOSPDIF...
Page 57 ANALOG VIDEO DIAGRAM AVRX4300H ANALOG VIDEO BLOCK AVDM2000 CBL/SAT CBL/SAT_V VOUT5 DVD_V CVBS IN GAME GAME_V VOUT4 DEC_CVBS_IN Z1 MONITOR Z1 CVBS V.AUX(FRONT) V.AUX_V DVD_V CBL/SAT_V Z2 MONITOR Z2 CVBS GAME_V VOUT3 Z2 MONITOR V.AUX_V MONITOR VOUT2 COMPONENT OUT Y COMPONENT OUT PB VOUT1 COMPONENT OUT PR...
Page 58 HDMI DIAGRAM AVRX4300H HDMI BLOCK HDMI SW2(MN864788) HDMI ZONE2 P3 RX HDMI IN1 (CBL/SAT) MAIN P0 TX P2 RX HDMI IN2 HDMI TX(MN864787) (DVD) P1 RX P1 RX P1 TX HDMI IN3 (BLU-RAY) P0 RX P0 RX HDMI Rx 600MHz 4K/2K 600MHz HDMI IN4...
Page 59 POWER DIAGRAM AVRX4300H POWER BLOCK DIAGRAM HI+B LOW+B 428mA RY931 +12V(RELAY) (389mA) S1(AMP+B,-B) SPK Relay(5EA)+ Small Relay(0EA)+H/L Relay(1EA)+Fan(2EA) 222.5 + 12.5 + 33 + 160 = 428mA LOW-B HI-B 66mA +3.3V (Z2, Z3 DAC) BU33TD3WG 33+33=66mA (55mA) (191.5mA) IC323 228mA 178mA 112mA 435.2mA...
Page 60 WIRING DIAGRAM WIRING DIAGRAM (AVRX4300H) WiFi Antenna WiFi Antenna HEIGHT PCB PCB CUP12852Z-2 DIGITAL PCB WiFi Antenna WiFi Antenna CN951 BN951 CUP12847Z WAFER/3P/2.5mm WIRE/3P/2.5mm CJP03GI289ZY CWB1E0030503D CN321 CON1 CON2 WAFER/5P/2mm CJP05GI288ZY LEGO MODULE INLET CN781 CN704 (CNVLEGOAIOS4025) WAFER/6P/2mm WAFER/7P/2mm (PROT.LINE) (PROT.LINE) CN431 CJP06GA208ZY...
Page 61 SEMICONDUCTORS Only major semiconductors are shown, general semiconductors etc. are omitted to list. The semiconductor which described a detailed drawing in a schematic diagram are omitted to list. 1. IC's R5F564MJCDFC (DIGITAL : IC151) Pin Name Symbol Pu/Pd STBY STOP Function STBY E20 Emulator control pin (On chip Emulator is used,this...
Page 62 Pin Name Symbol Pu/Pd STBY STOP Function Pin Name Symbol Pu/Pd STBY STOP Function STBY STBY HDRADIO P83/SCK10 IP_RST Scaler w/ GUI (ADV8003) Reset control pin MOHI(SR7011/ Power supply pin AV7703(NA))/ P26/TXD1 HDRADIO/TUNER control UB/PC7/TXD8/ Pins for setting the boot mode(select the Boot Mode or TU SCLK(X4300H/ IRQ14 User Boot Mode)
Page 63 Pin Name Symbol Pu/Pd STBY STOP Function Pin Name Symbol Pu/Pd STBY STOP Function STBY STBY PA2/RXD5 NC/(USB_EN) NC/(for X7500H/AV8804) PD3/IRQ3/AN111 787_HINT HDMI Tx (MN864787) interrupt signal input pin TRDATA2/PG6 ZVOL DATA ZONE2 volume control pin (NJW1194) Ground pin PA1/SCK5/IRQ11 ZVOL CLK ZONE2 volume control pin (NJW1194) 787_RST...
Page 64 PCM9211 www.ti.com SBAS495 – JUNE 2010 AD8195 PIN CONFIGURATIONS AD8195ACPZ (F-HDMI : IC101) PCM9211 (DIGITAL : IC202) PT PACKAGE LQFP-48 PIN CONFIGURATION AND FUNCTION DESCRIPTIONS (TOP VIEW) ERROR/INT0 VDDRX 30 AVCC PIN 1 30 AVCC NPCM/INT1 RXIN1 29 PE_EN INDICATOR PIN 1 29 PE_EN INDICATOR...
Page 65 PCM9211 PCM9211 BLOCK DIAGRAM www.ti.com SBAS495 – JUNE 2010 BLOCK DIAGRAM DESCRIPTION NAME FILT TOLERANT AUXIN 0 24 MDI/SDA Software control I/F, SPI data input / I2C data input/output(2) AUTO RXIN7 RXIN 0 RXIN0 SCKO DOUT RXIN 1 RXIN1 MAIN OUTPUT RXIN 2 RXIN2...
Page 66 A3V56S30GTP A3V56S40GTP 256M Single Data Rate Synchronous DRAM ADSP21487KSWZ4B (DIGITAL : IC251, IC261, IC271, IC281) A3V56S40GTP-60 (DIGITAL : IC252, IC262, IC272, IC282) Pin Configuration (Top View) PIN 1 PIN CONFIGURATION (TOP VIEW) GND PAD DQ15 (PIN 177) DQ14 DQ13 at BOTTOM DQ12 DQ11 DQ10...
Page 67 5. Pin Configurations and Functions Ordering Guide AK4458VN 40 +105 C (Exposed pad is connected to ground) 40 +85 C (Exposed pad is open) 48-pin QFN (0.5mm pitch) AKD4458 Evaluation Board for AK4458 AK4458VN (FRONT CNT : IC301, IC311) No. Pin Name I/O Function PD State Control Data Clock Pin in I2C Bus serial control mode...
Page 68 PCM5100, PCM5101, PCM5102 SLAS764 – MAY 2011 www.ti.com [AK4458] DEVICE INFORMATION TERMINAL FUNCTIONS, PCM510x PCM5100 (DIGITAL IC321, IC322) FUNCTIONAL BLOCK DIAGRAM 4. Block Diagram and Functions PCM510X (top view) LDOE TVDD VDD18 DVSS AVDD AVSS Bias BICK/DCLK DATT AOUTL1P LRCK/DSDL1 Soft Mute Interpolator AOUTL1N...
Page 69 NJU72343 (INPUT : IC471, IC491) NJU72751 (INPUT : IC475) No. Symbol Function No. Symbol Function No. Symbol Function No. Symbol Function AREF Analog reference potential DATA IC control data input Power supply(+) CLOCK IC control clock input Address selection CLOCK IC control clock input ADR0 Address selection pin 0...
Page 70 PATTERN DETAIL ANODE CONNECTION 2. FL DISPLAY 1G-16G 1G-16G 1G-16G FLD (17-BT-40GINK) (FRONT : FL601) 1-1A 1-1B 2-1A 2-1B 3-1A 3-1B 4-1A 4-1B 5-1A 5-1B 1-2A 1-2B 2-2A 2-2B 3-2A 3-2B 4-2A 4-2B 5-2A 5-2B D10A 1-3A D10B 1-3B D11A 2-3A D11B 2-3B...
Page 71 MECHANICAL DISASSEMBLY Flowchart 1. FRONT ASSY 2. RADIATOR ASSY 3. REAR PANEL 4. DIGITAL PCB 5. VIDEO PCB 6. INPUT PCB 7. TUNER PCB 8. SPK PCB 9. SMPS PCB 10. TRANS EXPLODED VIEW PACKING VIEW...
Page 72 DISASSEMBLY Flowchart • Remove each part following the flow below. • Reassemble the removed parts in the reverse order. • Read "SAFETY PRECAUTIONS" before reassembling the removed parts. • If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the work. Failure to shape the wires correctly may cause problems such as noise. •...
Page 73 • The photographs with no shooting direction indicated were taken from the top of the unit. (1) Remove the screws. • Photos of AVR-X4300H E3 are used in this manual. The viewpoint of each photograph (Shooting direction : X) [View from the top] ↑Front side↑...
Page 74 (3) Remove the connector. 2. RADIATOR ASSY Proceeding : TOP COVER → FRONT ASSY → RADIATOR ASSY (1) Remove the screws. View from the bottom (2) Remove the screws. Cut the wire clamp, then remove the connector. CN704 CN781 CN462 CUT x1 CN708 CN707...
Page 75 4. DIGITAL PCB 5. VIDEO PCB Proceeding : TOP COVER → REAR PANEL → DIGITAL PCB Proceeding : TOP COVER → REAR PANEL → DIGITAL PCB → VIDEO PCB (1) Remove the screws. Remove the STYLE PIN. Cut the wire clamp, then remove the connector. (1) Remove the connector.
Page 76 7. TUNER PCB Proceeding : TOP COVER → REAR PANEL → DIGITAL PCB → VIDEO PCB → INPUT PCB → TUNER PCB "EXPLODED VIEW" for instructions on removing the TUNER PCB. 8. SPK PCB Proceeding : TOP COVER → FRONT ASSY → RADIATOR ASSY →...
Page 77 EXPLODED VIEW Please see the last chapter for the part list. S10 x10 S8 x4 S9 x4 S9 x3 S2 x5 S4 x5 M12 x5 S4 x4 S5 X15 S5 X12 S4 x4 M12 x5 S4 x5 S4 x2 S2 x5 S12 x4 S2 x2 C49 X11...
Page 78 PACKING VIEW Please see the last chapter for the part list. UK plug (UK Only) 'H' TAPPING 'I' TAPPING 18-2 18-1 [CONTROL LABEL]...
Page 79 REPAIR INFORMATION TROUBLE SHOOTING SPECIAL MODE 1. POWER Special mode setting button 2. Analog video 1. Version Display Mode 3. HDMI/DVI 2. PANEL / REMOTE LOCK Selection Mode 4. AUDIO 3-1. Selecting the Mode for Service-related 5. Network / Bluetooth / USB 3-2.
Page 80 TROUBLE SHOOTING 1. POWER 1.1. The unit does not power on 1.2. Fuse is blown The unit does not power on Blown fuse Does the power indicator on the front panel Does the power shut down after several Check the rectifier diode in the Check for short circuits between flash in green or white when the power is turned Check for leaks and short...
Page 81 2. Analog video Perform the operation below beforehand. b Check it whether connection cable and Monitor are normal. b VIDEO Convert is set to ON. Input b Setting as follows. CVBS / COMPONENT V : SAT COMPONENT : SAT Is the power voltage being output correctly? MONITOR OUT (CVBS / COMPONENT / HDMI OUT NG SIDE CNT PCB ·...
Page 82 DIGITAL test point D4332 D4312 D3804 R3844 JK201 M2_DA M1_DA Z2_DA R3848 C2007 JK432 R3847 D4336 R3843 R4353 R3979 D3803 T192 T191 T190 M2_HPD JK431 JK394 D3945 JK392 +5V_5 +5V_4 +5V_3 +5V_2 HPD1 D3802 C2003 D4319 D4318 +5V_7 +5V_6 HPD5 HPD4 D3852 HPD3...
Page 83 3. HDMI/DVI 3.1. No picture or sound is output (HDMI to HDMI) (8) When using a DENON Blu-ray/DVD player, is the "HDMI" indicator of the fluorescent display lit? Proceed to YES when using a Blu-ray/DVD player produced by other manufactures.
Page 84 (15) Are a picture and sound output when a dif- The TV is faulty. ferent TV is used? Check the unit. Check the Firmware. Check the circuits around the IP SCALER (IC401, Is "IP SCALER ERR" displayed? DIGITAL PCB) and DDR2 (IC402/IC403). If there appear to be no problems, IC401 or IC402/IC403 is faulty.
Page 85 4. AUDIO 4.1. AUDIO CHECK No audio output "AUDIO CHECK PASS" CHECK 1 INPUT SURROUND MODE SOURCE Check the ANALOG AUDIO BLOCK Audio output OK? ANALOG 2CH DIRECT ANALOG CHECK 2 INPUT SURROUND MODE SOURCE Check the DIGITAL AUDIO BLOCK Legacy Audio output OK? COAX or OPT...
Page 86 4.2. Power AMP (AMP PCB) 4.3. Analog audio No audio output. No audio output. Protection is activated. Is the power transistor open or short circuited? Are the CN64C 4-7 pins in the SIDE CNT circuit Replace the power transistor. Repair the ± 7 V power supply. 2SB1647 / 2SD2560 board receiving ±...
Page 87 5. Network / Bluetooth / USB 5.1. Cannot connect to the network Check the connection environment Can the output voltage (5 V) NET5V POWER circuit is faulty Insert the LAN cable correctly and then turn on Is NET5V POWER (IC151 uCOM Is the LAN cable correctly inserted? to Q1101 (FET-SW) be con- between IC115-Q1101 (FET-...
Page 88 5.2. Cannot establish a Bluetooth connection Are the versions of the HEOS Version displayed The Network Module software is faulty. in Version Check Mode? Check the Bluetooth device being used Is the Bluetooth device compatible with the Use a device that is A2DP profile compatible. A2DP profile? The circuit of Network Module is faulty.
Page 89 5.3. Cannot recognize the connected USB device 5.4. No picture or sound is output Check the USB device being used Checking the unit (If no picture is output) Is the digital video signal (VOUT_PCLK, VOUT_ Is a USB hub being used? Do not use a USB hub.
Page 90 DIGITAL test point USB test point JK608 D4332 D4312 D3804 R3844 M2_DA M1_DA JK201 R3848 C2007 Z2_DA JK608 JK432 R3847 D6836 D4336 R3843 D6835 R4353 R3979 D3803 T192 C6835 T191 C6836 M2_HPD JK431 JK394 D3945 JK392 +5V_5 +5V_4 +5V_3 +5V_2 HPD1 D3802 T190...
Page 91 6. SMPS Operation waveform for each part DC 5V is not output. Primary drain After primary side rectiﬁcation AC100 ~ 120V CCQF2E104KZE-T (Caution: High voltage, electric shock) (Caution: High voltage, electric shock) AC220 ~ 240V OPEN C9002 OPTION OPTION Replace the IC901(TOP268EG) 0.01uF/250V Is IC901 (TOP268EG) dam- J9008...
Page 92 AUDIO CHECK PASS HDMI BLOCK CHECK6 HDMI HDMI OUTPUT INPUT CHECK5 HDMI INPUT CHECK4 HDMI Tranceiver HDMI Tranceiver MN864788 MN864787 FRONT TMDS BUFFER HDMI AD8195 INPUT Digital audio BLOCK SPDIF COAXIAL PCM9211PTR DIGITAL INPUT OPTICAL AK4458 CHECK2 ADSP21487KSWZ4B x4 　DIGITAL AUDIO INTERFACE RECEIVER NETWORK ETHERNET...
Page 93 HDMI "Rx/Tx" Failure Detection 1. Prior checking Check item (0) : Checking the HDMI connector Checking the condition of the HDMI pin (rear/front). There are deformed pins. Replace the HDMI connector. Check for deformed pins. None of the pins are deformed. 3.
Page 94 Port: Select COM port of PC Baud rate: 19200bps Data bits: 8 Stop bits: 1 Parity: none Transmitted text Flow control: none Select Append CR-LF Forward: (none) Check the Local Echo check box. Figure 1-1 Device Connection Method (AVR-X4300H) Figure 3 Serial Port Setup Screen...
Page 95 After exiting "Setup Assistant” execute the above. 1. Input a command in the 2.Click on the transmission button. transmission command input. Press Figure 6-1. AVR settings (AVR-X4300H) Figure 8 Method for Sending Termite Commands All the indicatorLights Figure 6 FLD Display When Set...
Page 96 3. Starting detecting the point of failure 3-1 Check the "HDMI/DVI" item in troubleshooting. Check item(5). Does a video signal come from HDMI OUT1 to Check item(1). Is the GUI version readable correctly? TV correctly? Check that the version of the AVR can be read Go to check item (68) correctly.
Page 97 3-2 Switcher1 failure detection procedure Checking device. (HDMI Switcher1) When the results of check item (7) are "the communication results are not OK" Check communication between CPU and the HDMI Switcher1 device. Checking device. (HDMI Switcher1) Check item (7). Check communication between CPU and the HDMI Example : Check the power supply voltage.
Page 98 Checking the reset waveform. (HDMI Switcher1) Check item(10). Checking the reset waveform : Check the waveform. Check the HDMI Tx. Is the "TP17" waveform of the TP near the HDMI Switcher1 (IC391) Check the HDMI Switcher1 Check the HDMI Switcher2 Remove the damping resistor correct (like the one shown in the diagram) when the power is Remove the damping resistor...
Page 99 When the results of check item (7) are "the communication results are OK" Check item(14). Checking the DDC status register : Example ZONE2 OUT HDMI IN Send the following command from Termite.exe. Case of IN5 Send the command "i 002B 0084 0001".
Page 100 When the results of check item (13) are "NO" When the results of check item (14) are "00 or 04" (Detection of 5V is not OK) (Detection of DDC is not OK.) Check the +5V voltage. (HDMI IN5 - 7) Check the DDC line.
Page 101 When the results of check item (14) are "22 or 11" (Detection of DDC is OK.) Checking the TMDS status register (HDMI Switcher1) 3.3V TMDS Signal TMDS Check item(17). Checking register of the TMDS CLK detection status Example register : Send the following command from Termite.exe.
Page 102 When the results of check item (19) are "33 or 23 or 13 or 03" Example (Detection of HPD is OK / Detection of RXSENSE is OK ) Checking the EDID register. (HDMI ZONE2 OUT) Check item(20). Check the Monitor EDID : ①...
Page 103 When the results of check item (19) are "31 or 21 or 11 or 01" When the results of check item (19) are "32 or 22 or 12 or 02" (Detection of HPD is OK / Detection of RXSENSE is not OK ) (Detection of HPD is not OK / Detection of RXSENSE is OK ) Check the TMDS.
Page 104 When the results of check item (19) are "30 or 20 or 10 or 00" (Detection of HPD is not OK / Detection of RXSENSE is not OK ) Check the TMDS/HPD. (HDMI ZONE2 OUT) Check item(25). Checking the HPD and RXSENSE. : Does the test point near HDMI output terminal (JK394) indicate (3.3V)? Does the test point (HPD) near HDMI output terminal (JK394) indi-...
Page 105 3-3 Switcher2 failure detection procedure Checking device. (HDMI Switcher2) When the results of check item (26) are "the communication results are not OK" Check communication between CPU and the HDMI Switcher2 device. Checking device. (HDMI Switcher2) Check item (26). Check communication between CPU and the HDMI Example : Check the power supply voltage.
Page 106 Checking the reset waveform. (HDMI Switcher2) Check item(29). Checking the reset waveform : Check the waveform. Is the "TP19" waveform of the TP near the HDMI Switcher2 (IC381) correct (like the one shown in the diagram) when the power is turned on? Examples of confirmation waveform TP19...
Page 107 When the results of check item (26) are "the communication results are OK" Check item(31). Checking the DDC status register : Example ZONE2 OUT HDMI IN Send the following command from Termite.exe. Case of IN1 Send the command "i 0053 00B4 0001".
Page 108 When the results of check item (30) are "NO" When the results of check item (31) are "00 or 04" (Detection of 5V is not OK) (Detection of DDC is not OK.) Check the +5V voltage. (HDMI IN1 - 4) Check the DDC line.
Page 109 When the results of check item (31) are "22 or 11" (Detection of DDC is OK.) Check item (35). Checking the TMDS input waveform. : Checking the TMDS status register (HDMI Switcher2) Check the TMDS waveform at the following test point. 3.3V Is the waveform like the sample? TMDS Signal...
Page 110 3-4 Tx failure detection procedure Check the output terminal. No video signal is output from both Monitor 1 and Monitor 2. Check item(38). Check the video output port for failure. : Checking device. HDMI (Tx) Check the Monitor 1 output video signal is correct. After checking the Monitor 1, change the HDMI cable connection from OUT1 to OUT2.
Page 111 When the results of check item (39) are "the communication results are not OK" Check item(42). Check the reset of HDMI Tx. Check the waveform . Is the waveform at the test point TP (TP91) correct when power is Checking device. (HDMI Tx) turned on? Check the power supply voltage.
Page 112 Checking between Monitor1 and the TV. When the results of check item (39) are "the communication results are OK" Connect Monitor1 to the TV and check the following items with the TV turned on. Checking operation between the HDMI (SW) device and the HDMI device (Tx). Checking the HPD/RXSENSE status register.
Page 113 Example When the results of check item (45) are "30" (Detection of HPD is OK / Detection of RXSENSE is OK ) Checking the EDID register. (Monitor1) Check item(46). Check the Monitor EDID : ① Unplug the AC cord. Plug the AC cord into a power outlet. The first eight bytes are nor- ②...
Page 114 When the results of check item (45) are "10" When the results of check item (45) are "20" (Detection of HPD is OK / Detection of RXSENSE is not OK ) (Detection of HPD is not OK / Detection of RXSENSE is OK ) Check the RXSENSE.
Page 115 When the results of check item (45) are "00" Checking between Monitor 2 and the TV. (Detection of HPD is not OK / Detection of RXSENSE is not OK ) Connect Monitor 2 to the TV and check the following items with the TV turned on. Check the RXSENSE/HPD.
Page 116 When the results of check item (52) are "03" (Detection of HPD is OK / Detection of RXSENSE is OK ) Example Checking the EDID register. (Monitor2) Check item(53). Check the Monitor EDID : ① Unplug the AC cord. Plug the AC cord into a power outlet. ②...
Page 117 When the results of check item (52) are "01" When the results of check item (52) are "02" (Detection of HPD is OK / Detection of RXSENSE is not OK ) (Detection of HPD is not OK / Detection of RXSENSE is OK ) Check the RXSENSE.
Page 118 When the results of check item (52) are "00" (Detection of HPD is not OK / Detection of RXSENSE is not OK ) Checking the HPD/RXSENSE status register. (Monitor2) Check item(58). Checking the HPD and RXSENSE. : Does the test point of RXSENSE close to the HDMI output terminal (JK432) indicate the (3.3V)? Does the voltage of HPD test point close to the HDMI output terminal (JK432) indicate "Hi"...
Page 119 3-5 Front HDMI Buffer (AD8195) failure detection procedure Checking operation between the HDMI (Front HDMI Buffer) and the player Checking the +5V/DDC status register (Front HDMI Buffer) Check item(61). Checking the 5V status register : Example Send the following command from Termite.exe. b In order to check, connect the player to the HDMI terminal and configure the player as AVR source.
Page 120 When the results of check item (61) are "78 or 70" When the results of check item (62) are "00 or 04" (Detection of 5V is not OK.) (Detection of DDC is not OK.) Check the +5V voltage. (Front HDMI Buffer) Check the DDC Line.
Page 121 When the results of check item (62) are "22" (Detection of DDC is OK) Checking the TMDS status register (Front HDMI Buffer) Check item(65). Check the TMDS CLK detection status of the regis- Check item (66). Checking the TMDS input waveform. : Example ter.
Page 122 3-6 GUI (ADV8003) failure detection procedure Check item(68). When the results of check item (69) are "the communication results are not OK" Rewrite to the GUI ROM. Go to check item (3) After writing, is the GUI version readable cor- rectly? Checking device.
Page 123 Checking the reset waveform. Check the I2C communication line. Check item(74). Checking the reset : Check item(75). Check the I2C communication line : Check the CPU. Check the CPU. 10ms Is the waveform of the TP"TP113"near the GUI(IC401) correct (like Is the waveform of the TP"TP110/111"near the GUI(IC401) correct the one shown in the diagram) when the power is turned on? (like the one shown in the diagram) when the power is turned on?
Page 124 3-7 GUI and PLD failure detection procedure Check item(77). Does a video signal come from HDMI OUT1 to TV correctly? : Check item(79). Check the PLD video signal line from the GUI : HDMI OUT1 Check the video signal waveform at the following test point. Is the waveform like the sample? 3.3V Turn Video Conversion "ON"...
Page 125 When the results of check item (77) are "YES" (When the menu display is OK) Check item(81). Check the HDMI Tx video signal line from the HDMI Tx : HDMI HDMI OUT1 Check the video signal waveform at the following test point. Is the waveform like the sample? 3.3V TP(HO_DE)
Page 126 4.Device implementation location F HDMI (A SIDE) DIGITAL (A SIDE) BK101 CUP12867Z_MP JK432 D4332 JK431 JK394 JK393 JK392 JK391 JK384 JK383 JK382 JK381 D4312 D3804 T114 R3844 M2_DA M1_DA JK201 R3848 C2007 Z2_DA JK432 R3847 D4336 R4353 R3843 R3979 D3803 T192 M2_HPD JK431...
Page 127 CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK WAVE FORM MCKO Z2DIRMCK Z2DACMCK IC203 IC321 BCKO Z2DIRBCK Z2DACBCKO RXIN LC89091JA PCM5100 LRCKO Z2DIRLRCK Z2DACLRCKO LRCK ZONE2 DIR ZONE2 DAC DATAO Z2DIRDATA Z2DACDATAO MCKO Z3DIRMCK Z3DACMCK IC204 IC322 BCKO Z3DIRBCK Z3DACBCKO RXIN LC89091JA PCM5100...
Page 128 (E3 and E2 model only) (See 3-5. TUNER STEP mode (E3 / E2 only)) If there are multiple DENON AV receivers in the same area, this mode prevents other AV receivers from being operated concur- 3-6 Remote ID Setup Mode ↑ ↑...
Page 129 ZONE3 SOURCE STATUS CURSOR d OPTION DIMMER CURSOR 0 CURSOR f CURSOR 1 BACK SETUP...
Page 130 ******-****** → Q4 BT Mac Address → Q5 Audyssey App Interface Version Q3 WiFi Mac Address : q Model destination information, Serial Number： t Audio, Video PLD : *Wi-Fi MAC AVR-X4300H \\\ Audio PLD:**.** ******-****** S/N. ********** Video PLD:**.** \ ： Region (E3, E2, JP)
Page 131 1.4. Error display See the table below for descriptions of the displayed errors and countermeasures for these. If multiple errors occur, only one item is displayed. The priority order is w, e, r, t, y, q. Condition States Display TROUBLE SHOOTING FIRM ERROR The model name, brand name and region information Main...
Page 132 1.5. Version Display in the Setup Menu Follow the steps below to display the firmware information. (1) Press the "SETUP" button on the remote control. (2) Select "General - Information - Firmware". The version information is displayed as a 16-digit number as shown in the screenshot below. General/Firmware Version XXXX-XXXX-XXXX-XXXX...
Page 133 2. PANEL / REMOTE LOCK Selection Mode 2.1. Actions Switch the PANEL LOCK and REMOTE LOCK modes between on and off. 2.2. Starting up While holding down buttons "STATUS" and "INFO" simultaneously, press the power button to turn on the power. Select the desired mode using the "CURSOR f / d "...
Page 134 3-1. Selecting the Mode for Service-related 3-1.1. Actions Select diagnostic mode (service path check mode), protection history display mode, or 232C standby 3.RS232C RESET clear mode. –4.OP INFO 3-1.2. Starting up Operation Info for the unit can be checked. While holding down buttons "ZONE3 SOURCE" and "STATUS" simultaneously, press the power button to turn on the power.
Page 135 3-2. Protection History Display Mode 3-2.1. Actions (c) DC (if the last protection is DC) This mode enables the unit to record and display the event when the THERMAL, ASO or DC protection is activated. Cause : DC output of the power amplifier is abnormal. If protections have been activated multiple times, the latest protection operation is recorded.
Page 136 3-3. 232C Standby Clear Mode 3-2.4. Clearing the Protection History 3-3.1. Actions There are two ways to clear the protection history. Switches from 232C standby mode to normal standby mode. 3-3.2. Starting up (a) Activate Protection History Display Mode. Press the "STATUS" button to display the protection his- tory.
Page 137 3-4. Operation Info Mode 3-4.1. Actions (c) DC / ASO Protection count This mode enables the unit to display the accumulated operating time, power On count and each pro- Protection Time tection count. DC:___/ASO:___ 3-4.2. Starting up "STATUS" While holding down buttons "ZONE3 SOURCE" and "STATUS" simultaneously, press the power button to turn on the power.
Page 138 3-6.1. Actions This is a special mode for enabling reception STEP of the ANALOG TUNER to be changed. This function allows only the desired AV receiver to be operated if multiple DENON AV receivers are used in the same room.
Page 139 4. Protection Pass Mode 5. Network Initialization Mode 4.1. Actions 5.1. Actions • This mode allows the power to be turned on without activating protections. The following items are initialized. • This mode functions in the same way as normal power-on, except that protections are not activated. Network setup Friendly Name 4.2.
Page 140 6. Clearing the Operation Info 6.1. Actions • Displays the accumulated operating time of the unit, the number of times the power was switched on, and the number of occurrences of each protection. 6.2. Operations Remove all input/output terminals and the AC plug. Connect the AC plug again and place the product in standby mode.
Page 141 Protection Diagram 5CH AMP PCB DIGITAL PCB TR_THERMAL uCOM DC/ASO PROT 125pin/AN105 PROTECTION LOGIC ⇒ L_activeshutdown ⇒ L_activeshutdown THER_PROT_F 163pin/P90 THER PROTA ⇒ Chenge Power AMP Power Supply Voltege TR_THERMAL THER PROTE ⇒ L_activeshutdown THER_PROT_E 161pin/P91 F ⇒ FAN operation THER_PROT_A 159pin/P93 TR_THERMAL CURRENT (After 90sec )
Page 142 DIAGNOSTIC MODE Service Path Check Mode 1.1. Actions This function is convenient for confirming problem paths in the product and checking the paths after repairing. The Video and Audio paths can be checked. The backup data is not rewritten. 1.2. Starting up While holding down buttons "ZONE3 SOURCE"...
Page 143 Paths to be confirmed Display Settings What to confirm ・ Digital(PCM) input ⇒ Speaker output (Height2 (ZONE2) L/R) Input Source : Online Music Input Mode : Auto ・ Digital(PCM) input ⇒ Pre OUT output (ZONE2 L/R) Sound mode : STEREO ( b The input source can be switched to any source except Online Music.) Amp assign : 7.1ch + ZONE2 fig.03a...
Page 144 Paths to be confirmed Display Settings What to confirm ・ Analog input ⇒ Speaker output (Height2 (ZONE3) L/R) Input Source : CBL/SAT Input Mode : Auto ・ Analog input ⇒ Pre OUT output (ZONE3 L/R) Sound mode : STEREO ( b The input source can be switched to any source except CBL/SAT.) Z3 Source : Source ( b Volume 60 is the value when Absolute settings are used.
Page 145 Paths to be confirmed Display Settings What to confirm Input Source : Online Music ・ Analog input ⇒ Speaker output (Front L/R) Input Mode : Auto ・ Analog input ⇒ Pre OUT output (Front L/R) Sound mode : DIRECT ( b The input source can be switched to any source except Online Music.) Z2 Source : CBL/SAT Amp assign : 9.1ch fig.13a...
Page 146 DIAGNOSTIC PATH DIAGRAM fig.01 AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR...
Page 147 fig.02a AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 148 fig.02b AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 149 fig.03a AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 150 fig.03b AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 151 fig.03c AVRX4300H HDMI BLOCK HDMI SW2(MN864788) HDMI ZONE2 P3 RX HDMI IN1 (CBL/SAT) MAIN P0 TX P2 RX HDMI IN2 HDMI TX(MN864787) (DVD) P1 RX P1 RX P1 TX HDMI IN3 (BLU-RAY) P0 RX P0 RX HDMI Rx 600MHz 600MHz 4K/2K HDMI IN4 HDMI SW1(MN864788)
Page 152 fig.04a AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 153 fig.04b AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 154 fig.05a AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 155 fig.05b AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 156 fig.05c AVRX4300H HDMI BLOCK HDMI SW2(MN864788) HDMI ZONE2 P3 RX HDMI IN1 (CBL/SAT) MAIN P0 TX P2 RX HDMI IN2 HDMI TX(MN864787) (DVD) P1 RX P1 RX P1 TX HDMI IN3 (BLU-RAY) P0 RX P0 RX HDMI Rx 600MHz 600MHz 4K/2K HDMI IN4 HDMI SW1(MN864788)
Page 157 fig.06a AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 158 fig.06b AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 159 fig.07 AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 160 fig.08 AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 161 fig.09 AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 162 fig.10a AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 163 fig.10b AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 164 fig.11a AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 165 fig.11b AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 166 fig.12a AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 167 fig.12b AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 168 fig.13a AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 169 fig.13b AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 170 fig.14 AVRX4300H ANALOG VIDEO BLOCK AVDM2000 CBL/SAT CBL/SAT_V VOUT5 DVD_V CVBS IN GAME GAME_V DEC_CVBS_IN VOUT4 Z1 MONITOR Z1 CVBS V.AUX(FRONT) V.AUX_V DVD_V CBL/SAT_V Z2 MONITOR Z2 CVBS GAME_V VOUT3 Z2 MONITOR V.AUX_V VOUT2 MONITOR COMPONENT OUT Y COMPONENT OUT PB VOUT1 COMPONENT OUT PR Blu-ray_Y...
Page 171 fig.15a AVRX4300H ANALOG VIDEO BLOCK AVDM2000 CBL/SAT CBL/SAT_V VOUT5 DVD_V CVBS IN GAME GAME_V DEC_CVBS_IN VOUT4 Z1 MONITOR Z1 CVBS V.AUX(FRONT) V.AUX_V DVD_V CBL/SAT_V Z2 MONITOR Z2 CVBS GAME_V VOUT3 Z2 MONITOR V.AUX_V VOUT2 MONITOR COMPONENT OUT Y COMPONENT OUT PB VOUT1 COMPONENT OUT PR Blu-ray_Y...
Page 172 fig.15b AVRX4300H HDMI BLOCK HDMI SW2(MN864788) HDMI ZONE2 P3 RX HDMI IN1 (CBL/SAT) MAIN P0 TX P2 RX HDMI IN2 HDMI TX(MN864787) (DVD) P1 RX P1 RX P1 TX HDMI IN3 (BLU-RAY) P0 RX P0 RX HDMI Rx 600MHz 600MHz 4K/2K HDMI IN4 HDMI SW1(MN864788)
Page 173 fig.16 AVRX4300H HDMI BLOCK HDMI SW2(MN864788) HDMI ZONE2 P3 RX HDMI IN1 (CBL/SAT) MAIN P0 TX P2 RX HDMI IN2 HDMI TX(MN864787) (DVD) P1 RX P1 RX P1 TX HDMI IN3 (BLU-RAY) P0 RX P0 RX HDMI Rx 600MHz 600MHz 4K/2K HDMI IN4 HDMI SW1(MN864788)
Page 174 fig.17 AVRX4300H HDMI BLOCK HDMI SW2(MN864788) HDMI ZONE2 P3 RX HDMI IN1 (CBL/SAT) MAIN P0 TX P2 RX HDMI IN2 HDMI TX(MN864787) (DVD) P1 RX P1 RX P1 TX HDMI IN3 (BLU-RAY) uCOM P0 RX P0 RX HDMI Rx 600MHz 600MHz 4K/2K HDMI IN4...
Page 175 fig.18a AVRX4300H ANALOG AUDIO BLOCK 11.2ch Processing PRE FL NJU72751V PRE FR Main L PRE CEN DAFL ADC L EXT_FL PRE SW1 SW A x 4 EXT_C PRE SL NJU72343V Main R DAFR ADC R PRE SR PRE FL EXT_C EXT_FR PRE ASS1L PRE FR...
Page 176 fig.18b AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 177 fig.18c AVRX4300H HDMI BLOCK HDMI SW2(MN864788) HDMI ZONE2 P3 RX HDMI IN1 (CBL/SAT) MAIN P0 TX P2 RX HDMI IN2 HDMI TX(MN864787) (DVD) P1 RX P1 RX P1 TX HDMI IN3 (BLU-RAY) P0 RX P0 RX HDMI Rx 600MHz 600MHz 4K/2K HDMI IN4 HDMI SW1(MN864788)
Page 178 fig.19a AVRX4300H DIGITAL AUDIO BLOCK(ADI) DIRRST #146 DIRCE #143 DIRDIN #141 DIRDOUT #144 Z3DIRSPDIF DIGTAL IN DIRCLK #145 Z2DIRSPDIF 24.576MHz COAX.0 DATAAD ADCDATA ADINL MAIN ZONE3 ZONE2 COAX.1 OPT.0 DIRSLRCK ADCLRCK OPT1(TV) OPT.0 ADCSBCK DIRSBCK ADINR OPT.1 OPT.1 AK5358BET (To MAIN DIR) BCOSPDIF DIRSMCK ADCSMCK...
Page 179 fig.19b AVRX4300H HDMI BLOCK HDMI SW2(MN864788) HDMI ZONE2 P3 RX HDMI IN1 (CBL/SAT) MAIN P0 TX P2 RX HDMI IN2 HDMI TX(MN864787) (DVD) P1 RX P1 RX P1 TX HDMI IN3 (BLU-RAY) P0 RX P0 RX HDMI Rx 600MHz 600MHz 4K/2K HDMI IN4 HDMI SW1(MN864788)
Page 180 fig.20 AVRX4300H HDMI BLOCK HDMI SW2(MN864788) HDMI ZONE2 P3 RX HDMI IN1 (CBL/SAT) MAIN P0 TX P2 RX HDMI IN2 HDMI TX(MN864787) (DVD) P1 RX P1 RX P1 TX HDMI IN3 (BLU-RAY) P0 RX P0 RX HDMI Rx 600MHz 600MHz 4K/2K HDMI IN4 HDMI SW1(MN864788)
Page 181 fig.21 AVRX4300H HDMI BLOCK HDMI SW2(MN864788) HDMI ZONE2 P3 RX HDMI IN1 (CBL/SAT) MAIN P0 TX P2 RX HDMI IN2 HDMI TX(MN864787) (DVD) P1 RX P1 RX P1 TX HDMI IN3 (BLU-RAY) P0 RX P0 RX HDMI Rx 600MHz 600MHz 4K/2K HDMI IN4 HDMI SW1(MN864788)
Page 182 JIG FOR SERVICING Use the following jigs (extension cable kit) when repairing the PCBs. Order with your dealer for the jigs your dealer if necessary. BN21B CAUTION : Incorrect connections may cause malfunction. BN28B Connection of Jig for DIGITAL PCB ---Items to Be Prepared--- 8U-110084S : EXTENSION UNIT KIT 1Set...
Page 183 (4) Connect the expansion cables. FRONT CNT FRONT CNT FRONT CNT DIGITAL VIDEO INPUT SIDE CNT SIDE CNT SIDE CNT Board-to-Board Connections Ref. No. Ref. No. 15pin CN27A SIDE CNT BN27A DIGITAL 25pin CN23A SIDE CNT BN23A DIGITAL 27pin CN24A FRONT CNT BN24A DIGITAL...
Page 184 ADJUSTMENT Adjusting Idling Current 1. Preparation AMP UNIT (1) Prepare a DC voltmeter. (2) Place the unit under normal usage conditions, away from highly ventilated areas such as next to an air conditioning machine or electric fan. The set requires an ambient temperature of 15℃ to 30℃ and standard humidity. (3) Settings of This Unit 5CH AMP PCB SL-CH...
Page 185 UPDATING PROCEDURE AFTER REPLACING THE DIGITAL PCB. PROCEDURE AFTER REPLACING THE U-COM, ETC. FIRMWARE UPDATE PROCEDURE 1. Items necessary for update 2. Update preparation with a USB flash drive 3. Update method when the DIGITAL PCB or network module is replaced (Using a USB flash drive) 4.
Page 186 PROCEDURE AFTER REPLACING THE DIGITAL PCB. PROCEDURE AFTER REPLACING THE U-COM, ETC. The procedure after replacing the DIGITAL PCB is as follows. The procedure after replacing the u-COM (microprocessor), flash ROM, etc. is as follows. (1) Change the resistor for setting the region. Implement the update method when the DIGITAL PCB or network module is replaced.
Page 187 Update download file when the DIGITAL PCB or network module is replaced Model Name Model Area Download from SDI AVR-X4300H avr_40.prod.update.factory.xxxx.zip Table 2 Update download file when the firmware is updated (Two files, "HW component" and "LEGO component") Download from SDI...
Page 188 2. Update preparation with a USB flash drive You can update the firmware by downloading the latest version with USB flash drive. 2.1. Connecting to the USB flash drive (1) Preparation ・ Windows PC ・ USB flash drive format : Prepare a USB flash drive formatted in FAT16 or FAT32. b We recommend a USB flash drive that has an LED installed.
Page 189 3. Update method when the DIGITAL PCB or network module is replaced (Using a USB flash drive) 3.1. File structure on USB flash drive (5) USB Update starts automatically. The Standby LED lights red. DIGITAL PCB or network module is replaced onto the USB flash drive in the following structure. Display during USB update After unzipping the files, store them in the root of the same USB flash drive.
Page 190 (4) Insert the USB flash drive into the USB port. NOTE : Enter the file name in double quotation marks. (The file extension is not required.) Service Region File name North America "denon-config-locale-set-1" Download ﬁrmware Europe "denon-config-locale-set-2" in USB ﬂash drive.
Page 191 5. Normal Firmware Update Method from USB Flash Drive 5.1. File structure on USB flash drive (5) USB Update starts automatically. The Standby LED lights red. Copy the normal update files onto the USB flash drive in the following structure. Display during USB update After unzipping the HW component USB update files for the target model and LEGO USB update files, Please wait–––––...
Page 192 6. Normal Firmware Update Method from OTA 6.2. Check and update the firmware Download the latest firmware from our website and update the firmware. 6.1. Network Connection Check if there is a firmware update available. It is also possible to check approximately how long the (1) System Requirements update will take.
Page 193 7. About the error codes See the table below for details on error codes and solutions when updating the firmware. Device ID table Error codes are displayed in 4 digits, YYXX ( YY : DeviceID, XX : ErrorCode). Device ID ( YY ) Device Name General Main CPU...
Page 195 FRONT FRONT PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
Page 196 FRONT REF No. Part No. Part Name Remarks Q'ty New Ver R6605 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R6607 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R6613 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R6614 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R6632 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R6701 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R6703 RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T R6704 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R6705...
Page 197 FRONT REF No. Part No. Part Name Remarks Q'ty New Ver SW631 00D9430004402 SW , TACT CST1A012ZT VR601 943671010330S ENCODER(16MM, 24PULSES),W/CLICK CSR2A055Z VR604 943671101000D ENCODER(16MM, 12PULSES) CSR2A060Z...
Page 198 DIGITAL DIGITAL PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
Page 199 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver Q1902 943214500020S T.R,2SC3052 CVT2SC3052 Q1903 943214500020S T.R,2SC3052 CVT2SC3052 Q1906 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 Q1907 943214500020S T.R,2SC3052 CVT2SC3052 Q1908 943214500020S T.R,2SC3052 CVT2SC3052 Q1909 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 Q1910 943214500020S T.R,2SC3052 CVT2SC3052 Q1911 943214500020S...
Page 200 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver R1364 90M-NN000640R RES, CHIP(1608/5%/2.7ohm) CRJ10DJ2R7T R1365 90M-NN000640R RES, CHIP(1608/5%/2.7ohm) CRJ10DJ2R7T R1366 90M-NN000640R RES, CHIP(1608/5%/2.7ohm) CRJ10DJ2R7T R1372 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R1373 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R1374 90M-NN000640R RES, CHIP(1608/5%/2.7ohm) CRJ10DJ2R7T R1375 90M-NN000640R RES, CHIP(1608/5%/2.7ohm) CRJ10DJ2R7T R1376...
Page 201 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver R1930 RES, CHIP(1005/5%/100ohm) CRJ06IJ101T R1931 RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T R1932 RES, CHIP(1005/5%/8.2Kohm) CRJ06IJ822T R1933 RES, CHIP(1005/5%/100ohm) CRJ06IJ101T R1934 RES, CHIP(1005/5%/22Kohm) CRJ06IJ223T R1935 RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T R1936 RES, CHIP(1005/5%/15Kohm) CRJ06IJ153T R1937 RES, CHIP(1005/5%/100ohm) CRJ06IJ101T R1938...
Page 202 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver R2251 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2252 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2253 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2254 RES, CHIP(1005/5%/100ohm) CRJ06IJ101T R2255 RES, CHIP(1005/5%/100ohm) CRJ06IJ101T R2256 RES, CHIP(1005/5%/100ohm) CRJ06IJ101T R2257 RES, CHIP(1005/5%/100ohm) CRJ06IJ101T R2260 RES, CHIP(1005/5%/100ohm) CRJ06IJ101T R2261...
Page 203 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver R2631 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2633 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2634 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2635 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2636 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2637 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2638 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2639 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2640...
Page 204 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver R2839 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2840 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2841 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2842 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2843 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2844 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R2845 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2846 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2847...
Page 205 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver R3865 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R3866 RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T R3867 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R3868 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R3871 RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T R3872 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R3873 RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T R3874 RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T R3875...
Page 206 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver R4071 RES, CHIP(1608/1%/2.7Kohm) CRJ10DF2701T R4074 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R4075 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R4076 RES, CHIP(1005/5%/47ohm) CRJ06IJ470T R4077 RES, CHIP(1005/5%/47ohm) CRJ06IJ470T R4078 RES, CHIP(1005/5%/47ohm) CRJ06IJ470T R4079 RES, CHIP(1005/5%/47ohm) CRJ06IJ470T R4080 RES, CHIP(1005/5%/47ohm) CRJ06IJ470T R4081...
Page 207 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver R5033 RES, CHIP(1005/0.5%/300ohm) CRJ06ID3000T R5034 RES, CHIP(1005/0.5%/1.8Kohm) CRJ06ID1801T R5036 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R5037 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R5038 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R5043 RES, CHIP(1005/5%/33Kohm) CRJ06IJ333T R5044 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R5045 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R5061...
Page 208 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver RN401 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN402 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN403 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN404 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN405 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN406 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN407 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN408 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN409...
Page 209 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C1211 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C1212 CAP, CHIP(2012, 16V/10uF, X5R)_SAMSUNG CCUC1C106KCS C1213 CAP, CHIP(2012, 16V/10uF, X5R)_SAMSUNG CCUC1C106KCS C1214 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C1215 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C1217 CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG...
Page 210 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C2027 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2028 CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS C2030 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2031 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2032 CAP, CHIP(1005, 25V/0.022uF, X7R)_SAMSUNG CCUI1E223KCS C2033 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG...
Page 211 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C2591 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2592 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2593 CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CCUI1H102KCS C2594 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2595 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2596 CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG...
Page 212 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C2709 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2710 CAP, CHIP(1608, 50V/18pF, C0G)_SAMSUNG CCUS1H180JAS C2711 CAP, CHIP(1608, 50V/18pF, C0G)_SAMSUNG CCUS1H180JAS C2712 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2714 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2715 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG...
Page 213 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C2829 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2830 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2831 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2832 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2833 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C2834 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG...
Page 214 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C3212 CAP, CHIP(1608, 6.3V/2.2uF, X7R)_SAMSUNG CCUS0J225KCS C3213 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C3214 CAP, CHIP(1608, 6.3V/2.2uF, X7R)_SAMSUNG CCUS0J225KCS C3215 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C3216 CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS C3217 CAP, CHIP(1005, 50V/2200pF, X7R)_SAMSUNG...
Page 215 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C3641 CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS C3642 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C3643 CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS C3644 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C3645 CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS C3646 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG...
Page 216 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C3822 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C3823 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C3824 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C3825 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C3826 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C3827 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG...
Page 217 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C4019 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C4020 CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS C4021 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C4022 CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS C4023 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C4024 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG...
Page 218 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C4149 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C4150 CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS C4151 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C4152 CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS C4153 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C4154 CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG...
Page 219 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C4374 CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS C4375 CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS C4381 CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS C4382 CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS C4383 CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS C4384 CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG...
Page 220 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver L1171 FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V L1174 FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V L1175 COIL , SMD(2.2uH, 4.6A 5040, 50X40) CLQ28E2R2NRH L1181 FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V L1184 FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V L1185 COIL , SMD(2.2uH, 4.6A 5040, 50X40) CLQ28E2R2NRH L1191...
Page 221 SMPS SMPS PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
Page 222 SMPS REF No. Part No. Part Name Remarks Q'ty New Ver ! T9001 943102100510S TRANS, SWITCHING VLT9Z119ZE RUBBER , TRANS CHG1A587...
Page 223 VIDEO VIDEO PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
Page 224 VIDEO REF No. Part No. Part Name Remarks Q'ty New Ver C5187 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C5188 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C5189 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C5190 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C5191 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C5192 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG...
Page 225 SPK PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
Page 226 REF No. Part No. Part Name Remarks Q'ty New Ver R9248 RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T R9249 RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T R9250 RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T R9251 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R9323 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R9324 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R9325 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R9400 RES, CHIP(3216/5%/0ohm) CRJ14CJ0R0T R9402 RES, CHIP(1608/5%/4.7Kohm)
Page 227 REF No. Part No. Part Name Remarks Q'ty New Ver BN951 WIRE ASS'Y, (3P, 2.5mm, 50mm, UL1007#20, 80) CWB1E0030503D CN25D PIN HEADER (27P,1.25mm,STRAIGHT,B-TO-B) CJP25GI281Z CN711 WAFER , LOCKING(3P, 2mm PITCH, DIP, STRAIGHT) CJP03GI352ZY CN712 WAFER , LOCKING(3P, 2mm PITCH, DIP, STRAIGHT) CJP03GI352ZY CN77D PIN HEADER (13P,1.25mm,STRAIGHT,B-TO-B)
Page 228 FRONT CNT FRONT CNT PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
Page 229 FRONT CNT REF No. Part No. Part Name Remarks Q'ty New Ver R3138 RES, CHIP(1608/5%/180ohm) CRJ10DJ181T R3139 RES, CHIP(1608/5%/180ohm) CRJ10DJ181T R3140 RES, CHIP(1608/5%/180ohm) CRJ10DJ181T R3141 RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T R3142 RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T R3143 RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T R3144 RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T R3145 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T...
Page 230 FRONT CNT REF No. Part No. Part Name Remarks Q'ty New Ver C3143 CAP, CHIP(2012, 50V/680pF, MURATA GRM21) CCUMUC1H681JAM C3144 CAP, CHIP(2012, 50V/680pF, MURATA GRM21) CCUMUC1H681JAM C3147 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C3148 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C3149 CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS C3150 CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG...
Page 231 SIDE CNT SIDE CNT PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
Page 232 INPUT INPUT PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
Page 233 INPUT REF No. Part No. Part Name Remarks Q'ty New Ver R4662 RES, CHIP(1608/5%/0ohm) E3, JP CRJ10DJ0R0T R4662 RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T R4663 RES, CHIP(1608/5%/390ohm) CRJ10DJ391T R4664 RES, CHIP(1608/5%/390ohm) CRJ10DJ391T R4665 RES, CHIP(1608/5%/68Kohm) CRJ10DJ683T R4666 RES, CHIP(1608/5%/68Kohm) CRJ10DJ683T R4667 RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T R4668 RES, CHIP(1608/5%/150Kohm)
Page 234 INPUT REF No. Part No. Part Name Remarks Q'ty New Ver R4858 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R4861 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R4862 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R4863 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R4864 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R4865 RES, CHIP(1608/5%/68Kohm) CRJ10DJ683T R4866 RES, CHIP(1608/5%/68Kohm) CRJ10DJ683T R4867 RES, CHIP(1608/5%/68Kohm) CRJ10DJ683T R4868...
Page 235 INPUT REF No. Part No. Part Name Remarks Q'ty New Ver R8779 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R8780 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R8781 RES, CHIP(1608/5%/220ohm) CRJ10DJ221T R8782 RES, CHIP(1608/5%/220ohm) CRJ10DJ221T R8783 RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T R8784 RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T R8785 RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T R8786 RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T R8787...
Page 236 INPUT REF No. Part No. Part Name Remarks Q'ty New Ver C4672 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C4673 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C4675 CAP, ELECT(10V/220uF) CCEA1AH221T C4676 CAP, ELECT(10V/220uF) CCEA1AH221T C4677 CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS C4678 CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS C4679 CAP, MYLAR(50V/0.022uF/J)
Page 237 INPUT REF No. Part No. Part Name Remarks Q'ty New Ver C4902 CAP, ELECT(50V/10uF) CCEA1HH100T C4935 CAP, ELECT(35V/470uF) CCEA1VH471T C4936 CAP, ELECT(35V/470uF) CCEA1VH471T C4937 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C4938 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C4939 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C4940 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG...
Page 238 AMP PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
Page 239 REF No. Part No. Part Name Remarks Q'ty New Ver Q7738 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 Q7739 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 Q7800 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 Q7804 21785000550AS T.R, PNP, DUAL, HN4A06J, SOT-25, TOSHIBA CVTHN4A06J Q7814 943212500020S High Voltage PNP Transistors(SOT-23)
Page 240 REF No. Part No. Part Name Remarks Q'ty New Ver R7245 RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T R7301 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T R7302 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T R7303 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T R7304 RES, CARBON(1/5W,1Kohm,J) CRD20TJ102T R7305 RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT R7306 RES, CHIP(1608/5%/390ohm) CRJ10DJ391T R7307 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R7308...
Page 241 REF No. Part No. Part Name Remarks Q'ty New Ver R7602 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T R7603 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T R7604 RES, CARBON(1/5W,1Kohm,J) CRD20TJ102T R7605 RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT R7606 RES, CHIP(1608/5%/390ohm) CRJ10DJ391T R7607 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R7608 RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT R7610 RES, CARBON(1/5W,110ohm,J) CRD20TJ111T...
Page 242 REF No. Part No. Part Name Remarks Q'ty New Ver R7895 RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T R7896 943252101080S PTC THEMISTORS, CHIP(75'C) CRTDHPTF1608471P75T R7900 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T R7901 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T R7902 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T R7903 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T R7904 RES, CARBON(1/5W,1Kohm,J) CRD20TJ102T R7905 RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT...
Page 243 REF No. Part No. Part Name Remarks Q'ty New Ver C7620 EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T C7621 EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T C7625 CAP, ELECT(35V/470uF) CCEA1VH471T C7631 CAP, ELECT(100V/10uF) CCEA2AH100T C7632 CAP, ELECT(100V/10uF) CCEA2AH100T C7638 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C7701 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V)
Page 244 F_HDMI F_HDMI PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
Page 245 SELECT KNOB ASS'Y CGK1A167ZA 41201007601AD SELECT KNOB ASS'Y CGK1A167YA 41201007500AD VOLUME KNOB ASS'Y CGK1A166ZA 41201007501AD VOLUME KNOB ASS'Y CGK1A166YA 42141003400AD BADGE , DENON E3, JP CGB1A275Z 42141002400AD BADGE , DENON BKE2 CGB1A254Z-V1 42141002401AD BADGE , DENON SPE2 CGB1A254Y-V1 42131003300AD BADGE , INCOMEND...
Page 246 EXPLODED REF No. Part No. Part Name Remarks Q'ty New Ver NUT - ENCORDER WASHER - ENCORDER 943416100770D WINDOW , VFD CGU1A463Z 943451101230D SHEET , VOLUME KNOB CGX1A473 943451101210D SHEET , SELECT KNOB CGX1A474 42451003000AD RING , SELECT CGR1A536 42451003001AD RING , SELECT CGR1A536C73 42451002900AD...
Page 247 PACKING PACKING ※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.

Denon AVR-X4300H Service Manual

Quick Links

Related Manuals for Denon AVR-X4300H

Summary of Contents for Denon AVR-X4300H
