- Page 1 VI P420 CAULKING GUN BATTERY 7.2V - 1.5Ah INSTRUCTION MANUAL...
- Page 2 OVERVIEW Battery pack Transformer 7.2V - 1.5Ah (Charger) P420 Carriage Trigger Cartridge holder Pressing the trigger starts the forward motion of the plunger rod. Push plate Trigger lock Parts contact and squeeze with the cartridge plunger. The trigger lock prevents depression of trigger. Plunger rod Ventilation holes The forward movement of the plunger rod applies pressure to the...
- Page 3 GETTING STARTED Check up on the battery Release and remove the Load the cartridges into Tighten the static Pull the trigger for pack to be fully charged coaxial cartridges cap. carriage. mixer. operation. and firmly loaded. Battery loading and removal Loading caulk material Hold the pull knob and pull it back Press the rod release button.
- Page 4 WARNING Never remove the plunger rod off the tool in In case of that residual material left on the any case, otherwise it will cause failure of plunger rod, please clean it up thoroughly spheres locating which makes the gun fail to before pulling the rod to the backward work.
