INNOVATION IN MOBILITY
™
S-Series
TM
Transit Use (ADA)
Wheelchair and Standee Lift
PRINT
Operator Manual
32DSSS01.A
©92-02 RICON CORPORATION
05/16/01
All Rights Reserved
Printed in the United States of America
U.S. Patent Nos: 5,228,538; 5,308,215; 5,373,915; 5,445,488; 5,605,431; 5,944,473
®
Australian Patent Nos: 661127; 687066
Canadian Patent No: 2,129,821
German Patent No: EP 0625896 B1
U.K. Patent No: EP 0625896 B1
Other U.S. and foreign patents pending.
Advertisement
Table of Contents
Related Manuals for Ricon S Series
Summary of Contents for Ricon S Series
- Page 1 S-Series Transit Use (ADA) Wheelchair and Standee Lift PRINT Operator Manual 32DSSS01.A ©92-02 RICON CORPORATION 05/16/01 All Rights Reserved Printed in the United States of America U.S. Patent Nos: 5,228,538; 5,308,215; 5,373,915; 5,445,488; 5,605,431; 5,944,473 ® Australian Patent Nos: 661127; 687066...
- Page 2 This RICON product must be installed and serviced by RICON authorized service technicians. The operator must refer to this manual for operating instructions, then retain it for future reference by authorized service technicians who service this product. Customer Name: Installing Dealer:...
- Page 3 REVISION RECORD ECR/ECO PAGES DESCRIPTION OF CHANGE 4216/ Cover Added U.S. patent number 5,944,473 32DSSS00 3669/4732 New release, in two-book format 32DSSS01 END OF LIST 32DSSS01.A...
-
Page 4: Table Of Contents
S-SERIES TRANSIT (ADA) TABLE OF CONTENTS Chapter: Page INTRODUCTION..................1-1 RICON FIVE-YEAR LIMITED WARRANTY ..........1-1 SHIPMENT INFORMATION ..............1-3 GENERAL SAFETY PRECAUTIONS ............1-3 MAJOR LIFT COMPONENTS ..............1-4 OPERATING INSTRUCTIONS ..............2-1 SAFETY PRECAUTIONS .................2-1 DAILY SAFETY CHECK................2-2 LIFT FUNCTIONS ...................2-3 CONTROLS AND INDICATORS ...............2-4 CONTROL PENDANT................2-4... - Page 5 intentionally This page left blank. 32DSSS01.A...
-
Page 6: Introduction
Ricon recommended maintenance and inspection instructions provided in Chapter III. If there are questions about this manual, or additional copies are needed, please contact Ricon Product Support at one of the following locations: Ricon Corporation 7900 Nelson Road Panorama City, Ca 91402 ............ - Page 7 Ricon Product Support. If You Need to Return a Product: Return this product to Ricon. Please give as much advance notice as possible, and allow a reasonable amount of time for repairs.
-
Page 8: Shipment Information
§ any missing items immediately to Ricon Product Support. The warranty and owner registration cards must be completed and returned to Ricon within 20 days for the warranty to be valid. NOTE: The Sales/Service Personnel must review Warranty and Owner Manual with user to be certain that they understand safe operation of product. -
Page 9: Major Lift Components
D. MAJOR LIFT COMPONENTS The references used throughout this manual are illustrated in Figure 1-1 and defined in Table 1-1. Refer to Service Manual, Chapter IV, “Parts Diagrams and Lists” for more details. FIGURE 1-1: TRANSIT USE (ADA) WHEELCHAIR AND STANDEE LIFT 32DSSS01.A... - Page 10 TABLE 1-1: S-SERIES LIFT TERMINOLOGY NAME DESCRIPTION Position references when lift is viewed from outside of Left vehicle. Right Front Rear (Left and Right) Telescoping steel tube, which converts Hydraulic Cylinder hydraulic pressure into lifting force. Hydraulic Power Contains pump used to create hydraulic pressure to raise Unit and fold lift, as well as a valve to unfold and lower lift.
- Page 11 This page intentionally left blank. 32DSSS01.A...
-
Page 12: Operating Instructions
S-SERIES TRANSIT USE (ADA) OPERATING INSTRUCTIONS his chapter contains safety precautions, daily safety check instructions, control and indicator descriptions and operating instructions for the RICON S-Series (ADA) Transit Use Wheelchair and Standee Lift. This chapter must be thoroughly understood before attempting to use the lift. -
Page 13: Daily Safety Check
Inspect the before each use and check that following conditions are met before operat- ing: All functions operate properly. DO NOT use if unusual noises or movements exist, § and contact a Ricon authorized service technician or Ricon Product Support for repair. § Vehicle interlock is operating properly. -
Page 14: Lift Functions
FUNCTION DESCRIPTION DEPLOY Platform unfolds/deploys out of vehicle from stowed position. (If equipped with a Ricon power door opera- tor, the doors automatically open before lift deploys.) DOWN Platform is lowered from vehicle floor level position to ground level. (The rollstop automatically lowers when platform reaches ground level.) -
Page 15: Controls And Indicators
CONTROLS AND INDICATORS WARNING THE LIFT IS ALLOWED TO OPERATE ONLY WHEN VEHICLE MANUFACTURER INTERLOCK CIRCUITRY IS ACTIVATED. NEVER ATTEMPT TO OPERATE LIFT WITH THE INTERLOCK BYPASSED. REFER TO VEHICLE OWNER/OPERATOR MANUAL FOR INTERLOCK INSTRUCTIONS BEFORE OPERATING LIFT. CONTROL PENDANT Refer to Figure 2-5. -
Page 16: Manual Back-Up Pump
In case of a door operator short circuit, the circuit breaker button will “pop-out”. If pressing and releasing button does not reset power, DO NOT press and hold. Contact a Ricon authorized service technician for repair. Refer to appropriate Ricon Remote Power Door Operator Ser- vice/Owner Manual for a detailed description. -
Page 17: Lift Operation
The lift operator must take special care to ensure that area is clear before deploy- ing lift. Be certain there are no obstacles beneath platform. Open doors completely if lift is not equipped with a Ricon Remote Power Door §... -
Page 18: Entering Vehicle
ENTERING VEHICLE NOTE: The occupant restraint belt must be fastened to enable the STOW/DEPLOY and UP/DOWN functions. The lift will not operate unless this safety mechanism is properly engaged. DEPLOY PLATFORM - Push and hold DEPLOY switch until platform completely unfolds from vehicle and stops at floor level. -
Page 19: Stowing Platform
NOT RELEASE SWITCH UNTIL LIFT HAS FOLDED COMPLETELY AND LIFT PUMP MOTOR HAS STOPPED AUTOMATICALLY. Close vehicle doors if lift is not equipped with a Ricon Remote Power Door Op- erator. (If equipped with a Power Door Operator, the vehicle door will auto- matically close after platform is stowed/folded). - Page 20 Insert notched end of pump handle into manual backup system hole marked “RELEASE VALVE” and engage pump release valve. CAUTION DO NOT OPEN PUMP RELEASE VALVE MORE THAN 1/4-TURN. OPEN- ING VALVE FURTHER MAY CAUSE IT TO DISENGAGE FROM PUMP BODY, WHICH WILL DISABLE PUMP LIFTING ABILITY.
- Page 21 Raise Platform Refer to Figure 2-11. Check pump release valve to be certain it is closed. FIGURE 2-11: MANUAL BACK-UP PUMP – RAISE PLATFORM Insert pump handle into pump handle socket. Operate pump to begin rais- ing platform. When platform reaches vehicle interior floor level turn valve CLOCKWISE to close;...
-
Page 22: Maintenance
III. S-SERIES TRANSIT USE (ADA) MAINTENANCE egular maintenance of the RICON S-Series (ADA) Transit Use Wheelchair and Standee Lift with Manual Rollstop will optimize its performance and reduce the need for repairs. This chapter contains cleaning instructions, a maintenance schedule, and a diagram showing decal locations and their part numbers. - Page 23 TABLE 3-1: MAINTENANCE SCHEDULE SERVICE POINT ACTION TO PERFORM Be certain that all lift mounting and support points are in proper order Lift Mountings and free from damage. and Support Points Be certain that all mounting bolts are sufficiently tight. Main Lifting Piv- Be certain all traveling frame pins are installed properly, free from dam- age and locked in position.
- Page 24 TABLE 3-1: MAINTENANCE SCHEDULE SERVICE POINT ACTION TO PERFORM CAUTION THIS SAFETY CHECK PERFORMED BY A RICON AUTHORIZED SERVICE TECHNICIAN. ANNUAL SAFETY CHECK (or @ 3500 cycles of operation) Check Hydraulic Cylinder for evidence of leaks. Hydraulic Cylin- der, Hoses and Inspect hydraulic hoses for damage.
-
Page 25: Decal Locations
C. DECAL LOCATIONS Refer to Figure 3-1. Inspect decals at interval in Table 3-1. Inspect for chipping, peel- ing, fading, and illegibility. Order replacement decals with part numbers given in Figure 3-1, and apply where shown FIGURE 3-1: DECAL LOCATIONS AND PART NUMBERS 32DSSS01.A...
