Summary of Contents for CROWNFUL IM2102-UL
- Page 1 CROWNFUL ICE MAKER INSTRUCTION MANUAL Model: SKU：CF-IM01 IM2102-UL Read this manual thoroughly before using and save it for future reference...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, explosion, electric shock, or injury when using your ice maker, follow these important safety instructions: 1. Before using, check if the voltage power corresponds to the one shown on the appliance nameplate or manual. This appliance only works with 120v. 2. - Page 3 frostbite or other issues. 13. Do not immerse any part of the product in water. 14. To disconnect, turn all controls to “OFF”, then remove the plug from wall outlet. 15. Do not plug or unplug product with wet hands. 16.
- Page 4 environmentally responsible way of recycling or disposing appliances with flammable refrigerant and blowing gas to ensure safety and compliance. SAVE THESE INSTRUCTIONS HOUSEHOLD USE ONLY KNOW YOUR ICE MAKER Evaporator Top lid Ice tray Viewing window Ice shovel Front cover W ater reservoir Hole plug Back housing...
-
Page 5: Control Panel
CONTROL PANEL Key (with indicator) Function ON/OFF Start or stop the appliance； Long press for cleaning； Standby mode: “ICE” indicator blinks; Cleaning mode: Alternating “ICE” /“ICE FULL”/“ADD WATER” indicator light blinks rapidly； Working condition: “ICE” indicator light is solid. “ICE FULL” indicator lights up when the ICE FULL ice basket is full. -
Page 6: Before First Use
BEFORE FIRST USE 1. Unpack the appliance, then check and make sure that all the accessories including ice basket and ice scoop etc. are complete. Please contact customer support or the seller if some accessories are missing. 2. Please ensure the ice maker is leveled on a flat surface and on a stable table or platform to avoid malfunction. - Page 7 6. Press “ON/OFF” key, and the “ICE” indicator light will turn on (solid light). 7. The ice-making cycle will last approximately 7-15 minutes, depending on the ambient temperature and water temperature. 8. The ice-making cycle starts with the water being pumped into the ice tray situated below the evaporator.
-
Page 8: Cleaning And Maintenance
CLEANING AND MAINTENANCE To ensure cleanliness, quality and safety, we recommend that you clean your ice maker at least once a week. 1. Stop the ice-making cycle by pressing the “ON/OFF” key, unplug the ice maker from the wall outlet and allow it to warm up to room temperature. 2. - Page 9 （Fig.1） （Fig.2） （Fig.3）...
-
Page 10: Troubleshooting
TROUBLESHOOTING Problem Possible causes Solution “ADD WATER” 1.Low water level or lack of 1.Stop making ice, refill indicator turns on water water then press “ON/OFF” key to restart the 2.The water screen at the bottom of water reservoir is blocked. ice-making cycle. -
Page 11: Technical Parameters
8℃ and 28℃. 3. Operate the ice maker at a environment with ambient temperature between 10℃ and 32℃. TECHNICAL PARAMETERS Model: IM2102-UL Applicable climate: ST/SN/N/T Class: Power source: 120V/60Hz Rated current: 1.7A Net weight: 7.99kg Housing:... -
Page 12: Customer Support
CUSTOMER SUPPORT Should you encounter any issues or if you have any questions regarding your new product, feel free to contact our helpful Customer Support Team. Your satisfaction is our goal! Email: support@crownful.com Support Hours Monday - Friday: 9:00 am - 5:00 pm PST * Please have your order invoice or order number ready before contacting customer support.
Need help?
Do you have a question about the IM2102-UL and is the answer not in the manual?
Questions and answers
the ice maker red lite comes on indicating its full of ice, when it is not.
The red "ICE FULL" indicator on the CROWNFUL IM2102-UL ice maker may light up even when the ice basket is not full due to one of the following reasons:
1. Infrared light blockage – Foreign objects or dirt on the infrared light-emitting and light-receiving diodes may be obstructing the sensors.
2. Malfunctioning sensors – If cleaning the infrared diodes does not resolve the issue, the sensors may not be working properly.
Solution:
- Wipe off any foreign objects or dirt from the infrared light-emitting and light-receiving diodes.
- If the problem persists, contact customer service for further assistance.
This answer is automatically generated
