MACHINE COMPLETION AND EQUIPMENT - 05
ENGINE - 10
HYDRAULIC SYSTEMS - 35
[35.000] Hydraulic systems - 35.1
[35.300] Reservoir, cooler, and filters - 35.2
[35.304] Combination pump units - 35.3
[35.352] Hydraulic swing system - 35.4
[35.353] Hydraulic travel system - 35.5
[35.357] Pilot system - 35.6
CX36B
Tier 4B (final)
Compact Hydraulic Excavator
PIN NETN36001(PX17-40001) and above
SERVICE MANUAL
Part number 47797999
1
edition English
st
October 2014
Advertisement
Table of Contents
Related Manuals for Case CX36B
Summary of Contents for Case CX36B
- Page 1 [35.300] Reservoir, cooler, and filters - 35.2 [35.304] Combination pump units - 35.3 [35.352] Hydraulic swing system - 35.4 [35.353] Hydraulic travel system - 35.5 [35.357] Pilot system - 35.6 CX36B Tier 4B (final) Compact Hydraulic Excavator PIN NETN36001(PX17-40001) and above SERVICE MANUAL...
- Page 2 INTRODUCTION S5PX0011E01 14/10/2014...
-
Page 3: Table Of Contents
Contents INTRODUCTION Foreword - Important notice regarding equipment servicing ........3 Safety rules . -
Page 4: Foreword - Important Notice Regarding Equipment Servicing
In any case, no warranty is given or attributed on the product manufactured or marketed by the manufacturer in case of damages caused by parts and/or components not approved by the manufacturer. - Page 5 Thanks very much for your reading, Want to get more information, Please click here, Then get the complete manual NOTE: If there is no response to click on the link above, please download the PDF document first, and then click on it. Have any questions please write to me: admin@servicemanualperfect.com...
-
Page 6: Safety Rules
INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions. -
Page 7: Safety Rules - Ecology And The Environment
Batteries and electric accumulators contain several substances that can have a harmful effect on the environment if the batteries are not properly recycled after use. CASE CONSTRUCTION strongly recommends that equipment owners return all used batteries to a [Brand] dealer, who will dispose of the used batteries or recycle the used batteries properly. -
Page 8: Safety Rules Personal Safety
INTRODUCTION Safety rules Personal Safety CX36B Most accidents involving machine operation and maintenance can be avoided by following basic safety rules and precautions. Read and understand all the safety messages in this manual and the safety signs on the machine before you operate or service the machine. -
Page 9: Basic Instructions - Shop And Assembly
Only use CNH Original Parts or CASE CONSTRUCTION Original Parts. Only genuine spare parts guarantee the same quality, duration, and safety as original parts, as they are the same parts that are assembled during standard production. Only CNH Original Parts or CASE CONSTRUCTION Original Parts can offer this guarantee. - Page 10 W0111A Special tools The special tools that CASE CONSTRUCTION suggests and illustrate in this manual have been specifically re- searched and designed for use with CASE CONSTRUCTION machines. The special tools are essential for reliable repair operations. The special tools are accurately built and rigorously tested to offer efficient and long-lasting oper- ation.
-
Page 11: Torque - Minimum Tightening Torques For Normal Assembly
INTRODUCTION Torque - Minimum tightening torques for normal assembly CX36B Decimal hardware Grade 5 bolts, nuts and studs Size lb in/lb ft 1/4 in 12 - 15 Nm 108 - 132 lb in 5/16 in 23 - 28 Nm 204 - 252 lb in... - Page 12 INTRODUCTION Grade 10.9 bolts, nuts and studs Size lb in/lb ft 4 mm 4 - 5 Nm 36 - 48 lb in 5 mm 9 - 11 Nm 84 - 96 lb in 6 mm 15 - 18 Nm 132 - 156 lb in 8 mm 37 - 43 Nm 324 - 384 lb in...
- Page 13 INTRODUCTION Size lb in/lb ft 5/8-11 in 190 - 203 Nm 140 - 150 lb ft O-ring face seal end O-ring boss end fitting or lock nut Nominal Tube outside diameter Thread size Nm lb in/lb ft Thread size Nm lb in/lb ft SAE dash size...
-
Page 14: Torque - Standard Torque Data For Hydraulics
INTRODUCTION Torque - Standard torque data for hydraulics CX36B Installation of adjustable fittings in straight thread O-ring bosses 1. Lubricate the O-ring by coating it with a light oil or petroleum. Install the O-ring in the groove adjacent to the metal backup washer which is assembled at the extreme end of the groove (4). - Page 15 INTRODUCTION Pipe thread fitting torque Thread size Torque (maximum) 1/8-27 13 N·m (10 lb ft) Before installing and tightening pipe fittings, clean the 1/4-18 16 N·m (12 lb ft) threads with a clean solvent or Loctite cleaner and apply 3/8-18 22 N·m (16 lb ft) sealant L ®...
-
Page 16: Capacities
INTRODUCTION Capacities Manufacturer International Component to be filled Quantity Consumable specifications specifications CASE AKCELA NO. 1™ ENGINE OIL SAE MAT3507 3.9 - 6.7 L 10W-30 API CI 4/CH-4 Engine oil pan (1.0 - ACEA E7/E5 CASE AKCELA NO. 1.8 US gal) 1™... - Page 17 Viscosity Temperature operating range Consumable -25.0 - 25.0 °C (-13.0 - 77.0 °F) SAE 10W - 30 CASE AKCELA NO. Engine 1™ ENGINE OIL -15.0 - 40.0 °C (5.0 - 104.0 °F) SAE 15W - 40 Travel motor, upper rollers and idler CASE AKCELA GEAR SAE 80W - 90 -25.0 - 45.0 °C (-13.0 - 113.0 °F)
- Page 18 • Do not mix bio-oil with original factory-filled mineral oil; in case it is necessary to use bio-oil, flush the hydraulic system that was filled with bio-oil three times.
-
Page 19: Hydraulic Contamination
INTRODUCTION Hydraulic contamination CX36B Contamination in the hydraulic system is a major cause of the malfunction of hydraulic components. Contamination is any foreign material in the hydraulic oil. Contamination can enter the hydraulic system in several ways: • When you drain the oil or disconnect any line •... -
Page 20: General Specification
INTRODUCTION General specification Complete machine weight Rubber crawler belt Iron crawler shoe Canopy Canopy 3650 kg 3810 kg (8400 lb) 3740 kg (8245 lb) 3900 kg (8598 lb) (8047 lb) Speed and gradeability Detail Rubber crawler belt Iron crawler shoe Rotation speed 8.4 RPM Travel speed... -
Page 21: Product Identification
INTRODUCTION Product identification CX36B The terms right-hand, left-hand, front, and rear are used in this manual to indicate the sides as they are seen from the operator's seat. 1. Front 2. Right 3. Rear 4. Left RAIL14CEX0007AA S5PX0011E01 14/10/2014... - Page 22 INTRODUCTION S5PX0011E01 14/10/2014...
