Perreaux 200iX Owner's Manual page 11

1
AES/EBU digital input
Pin 1: Shield
2 1
Pin 2: +ve signal (hot)
3
Pin 3: -ve signal (cold)
2
Bluetooth antenna input
3
Coaxial SPDIF digital inputs
4
USB digital input
The AES/EBU input accepts digital signals from a
source component with an AES/EBU digital output.
The pin assignments of the AES/EBU XLR input con-
nector is:
The 200iX/300iX provides CD quality, Bluetooth audio
streaming direct from any Bluetooth equipped PC,
laptop, smartphone or tablet. Supported codecs are
SBC, AAC, aptX, aptX-LL, aptX-HD and LDAC.
In order to use the Bluetooth input, please follow the
next steps:
1. Select BT as the source within the 200iX/300iX.
2. Within the source device (e.g. smartphone), en-
able Bluetooth and connect to the 200iX/300iX (i.e.
"200iX/300iX Audio-xxxx"). The xxxx is unique to your
unit and noted on the back panel above the serial.
3. Play your favourite music in your source device; vol-
ume can be controlled both in the source device as
well as the 200iX/300iX.
The Bluetooth antenna input provides a SMA type, 50
Ohm, coaxial, screw connection for connection of the
wireless Bluetooth antenna (supplied).
Note: Bluetooth is switched off when you switch to an-
other channel to lower noise.
The 200iX/300iX features 2 High-Resolution Coaxial
SPDIF (RCA) digital audio inputs providing 24 bit 192
kHz audio performance.
Stream high resolution digital audio directly from your
computer via the integrated, ES SABRE Reference
9038 PRO 24-bit/384kHz asynchronous USB DAC.
Compatibility
• Windows 10 (release 1703) or later.*
• Mac users using OSX 10.6.3 or later.
Note: Always use a high quality USB connection cable
certified as USB Hi- Speed (cable provided with your
200iX/300iX). USB cable connections longer than 3m
may result in inconsistent audio performance.
* Starting with Windows 10, release 1703, a USB Audio
2.0 driver is shipped with Windows. Device is reported
as XMOS USB Audio.
