Crystal Quest C-75 Installation Manual

C-75 Controller

Installation Manual

Table of Contents

Need help?

Do you have a question about the C-75 and is the answer not in the manual?

Page 2 TABLE OF CONTENTS I . I nt rod u ct i o n ......................3 I I .
Page 3 C-75 INTRODUCTION The Advantage Controls Series 75 RO controller is designed for the small commercial Reverse Osmosis system. This controller incorporates relay outputs and dry contact inputs to either run or shutdown as necessary for proper operation. The S75 Controller has up to three relay outputs: inlet solenoid valve, RO pump motor, and an optional flush solenoid valve.
Page 4 INSTALLATION WARNING: All switch inputs must be dry contact only. If voltage is applied to these inputs, damage to the controller will result. For power with neutral and hot leads, L1 is hot and L2 is neutral. SYSTEM OPERATION When the power switch is turned ON, the center status LED will flash Green, the inlet valve will OPEN and the RO pump will START. The center LED will be solid Green for normal run.
Page 5 WARRANTY & GUARANTEE VOID ABILITY OF WARRANTY This Warranty shall be void and unenforceable as to any Seller product which has been damaged by accident, mishandling, abuse or has been repaired, modified, altered, disassembled or otherwise tampered with by anyone other than Seller or an authorized Seller service representative;...
