INSTALATION & ASSEMBLY:
1. Shut off power at the fuse box or circuit breaker box. Remove the old
fixture, including the mounting hardware.
2. Carefully unpack your new fixture and lay out all the parts on a clear
surface. Take care not to lose any small parts necessary for
installation.
3. Thread the Hex Nut onto the Nipple. Thread the Nipple into the
center hole of the Mounting Bracket. Do not tighten the Hex Nut at
this time. (Fig. 1)
4. Attach the Mounting Bracket to the Outlet Box using the Bracket
Mounting Screws. (Fig. 1)
5. Pull the Supply Wires out from the Outlet Box. Strip approximately
¼" of insulation from each Supply and Fixture Wire.
Bracket Mounting Screw
Mounting Bracket
Hex Nut
Nipple
Power Supply Wires
Fig. 1
Wall
Outlet Box
