Hoshizaki SafeTemp RH1-AAC Parts List
Reach-in
Hide thumbs
Also See for SafeTemp RH1-AAC:
- Service manual (40 pages) ,
- Specifications (2 pages) ,
- Parts list (71 pages)
Related Manuals for Hoshizaki SafeTemp RH1-AAC
Summary of Contents for Hoshizaki SafeTemp RH1-AAC
-
Page 1: Parts List
Reliability is a beautiful thing REACH-IN SafeTemp Model RH1-AAC-W PARTS LIST 71226 ITEM #: ISSUED: October 16, 2003 August 9, 2005 REVISED:... -
Page 2: Table Of Contents
CONTENTS Auxiliary Codes... 3 Note About Ordering Parts ... 3 Material Abbreviations ... 4 A. Reach-In... 5 B. Refrigeration System... 7 C. Panel-Front Hinged Assembly... 10 D. Body-Final ... 11 E. Control Box Assembly ... 13 F. Label Location... 15 G. -
Page 3: Auxiliary Codes
Auxiliary Codes RH1-AAC-W Note About Ordering Parts Most assemblies cannot be ordered as complete units; parts in the assemblies generally must be ordered separately. November 2002 December 2002 January 2003 December 2003 October 2004 November 2004 December 2004 June 2005... -
Page 4: Material Abbreviations
Material Abbreviations ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene... -
Page 5: Reach-In
A. Reach-In RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6 B1 B2 B3 3b 3c... - Page 6 Cover – Connector Wire T2 Screw Cover – Wire T2 Screw Bracket – Hinge T2 Screw Bracket – Control Box Bushing Material or Model Number Part Number Q-5 Q-6 Refrigerator 1A0297A02 8×45 437889-01 5×25, SS 7C32-0525 7W22-0500 3A1670A01 8907-0102 8907-0103 4A0655-03...
-
Page 7: Refrigeration System
B. Refrigeration System RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6 18 18a 19 9 9a 29 29a 14b 14c 2 2a... - Page 8 Title: B. Refrigeration System Model: RH1-AAC-W Index Description Fan – Evaporator Assembly Truss Head Screw Evaporator Assembly Condenser Assembly T2 Screw Drier Mount – Drier T2 Screw Fitting – Drain Overflow Gasket – Condensate Coil Rubber Gasket Pan – Evaporator Drain Strap –...
- Page 9 Title: B. Refrigeration System Model: RH1-AAC-W Index Description Elbow – Tubing Start Relay Start Capacitor Latch – Holder Truss Head Screw Wire Clamp Latch – Case Truss Head Screw Material or Model Number Part Number 4A0711-01 501-96175 Supplied with compressor 243-292 MFD110 4A2993-01...
-
Page 10: Panel-Front Hinged Assembly
C. Panel-Front Hinged Assembly RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6 Title: C. Panel-Front Hinged Assembly Index Description Panel – Front Hinged Hinge – Front Panel (L) Hinge – Front Panel (R) Channel – Hinge Truss Head Screw Blind Support –... -
Page 11: Body-Final
D. Body-Final RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6 6 6a... - Page 12 Title: D. Body-Final Model: RH1-AAC-W Index Description Body – Prefinal Door – Left Hinge – Stop Pin Hinge – Tension Screw Hinge – Bushing Cover Hinge – Lock Washer Hinge – Pivot Pin (Top) Bracket – Door Hinge (LL) Countersunk Screw Bracket –...
-
Page 13: Control Box Assembly
E. Control Box Assembly RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6 12 13... - Page 14 Title: E. Control Box Assembly Model: RH1-AAC-W Index Description Base – Control Box Cover – Control Box Board – Control Display Controller Switch – Rocker Switch – Toggle Relay – Compressor Tapping Screw Transformer Tapping Screw Terminal Block Tapping Screw Plug Housing Receptacle Housing Plug Housing (6 Pin)
-
Page 15: Label Location
Index Description Cover – Nameplate Wiring Label Label – R404A Label – Penguin – HA (L) Label – Power Emblem – Hoshizaki Label – Display Label – Door Heater Switch Caution Label Material or Model Number Part Number 4A3727-01 2A2767-01... -
Page 16: Fan-Evaporator Assembly
G. Fan-Evaporator Assembly RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6 Title: G. Fan-Evaporator Assembly Index Description Blade – Evap Fan Motor – Fan Evap Truss Head Screw Hex Nut Split Lock Washer Bracket – Fan Motor Truss Head Screw Lock Washer Shroud –... -
Page 17: Evaporator Assembly
H. Evaporator Assembly RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6 Title: H. Evaporator Assembly Model: RH1-AAC-W Index Description Evaporator Bracket – Evaporator T2 Screw Expansion Valve Tube – Liquid Tube – Evaporator Inlet Insulation Tubing Expansion Valve Cover (A) Expansion Valve Cover (B) Thermistor –... -
Page 18: Condenser Assembly
J. Condenser Assembly RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6... - Page 19 Title: J. Condenser Assembly Model: RH1-AAC-W Index Description Shroud – Condenser T2 Screw Base – Condenser Condenser T2 Screw Motor – 16W Blade – Cond Fan Hex Nut Bracket – Condenser Fan Truss Head Screw Retainer – Filter T2 Screw Insert –...
-
Page 20: Body-Prefinal
K. Body-Prefinal RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6... - Page 21 Title: K. Body-Prefinal Model: RH1-AAC-W Index Description Cabinet – Prefoam Distributor – Air Top Assembly T2 Screw Pilaster Truss Head Screw Bulb – Light Shield – Light Plate – ABS Cheese Head Screw Divider – Air Switch – Door Lampholder Insert –...
-
Page 22: Door-Left
L. Door-Left RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6... - Page 23 Title: L. Door-Left Model: RH1-AAC-W Index Description Door – Prefoam (L) Lock – Tumbler Lock – Stop Washer Cam – Door Lock Lock – Screw Gasket – Door Lock Washer Lock – Key Washer – Door Lock Locking Hole Plug Handle Door Handle –...
-
Page 24: Literature & Packaging
M. Literature & Packaging RH1-AAC-W M-5, N-5, N-6, P-5, P-6, P-7, Q-5, Q-6 Title: M. Literature & Packaging Model: RH1-AAC-W Index Description Instruction Manual Packaging (Available only for models currently in production) Filler – Door Pad – Corner Post – Corner Support –...
