BS-IPT4002LPR / BS-IPT4012LPR
USER GUIDE
1
BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BS-IPT4002LPR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BOS BS-IPT4002LPR

  • Page 1 BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 2: Product Overview

    FTP upload, SMTP upload, SD card record and SIP phone  G.711/AAC audio compression capability  Real-time video electronic amplification  Three-privilege levels of users for flexible management  microSD/SDHC/SDXC card local storage support, expand the edge storage BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 3: Setting The Camera Over The Lan

    Please look up the router's user manual for assistance with port forwarding; Step4: Apply a domain name from a domain name provider; Step5: Configure the DDNS settings in the setting interface of the router; Step6: Visit the camera via the domain name. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 4 Figure 2-2 Connect the network camera via a router using dynamic IP BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 5: Chapter Iii Accessing The Network Camera

    Step2: Start Smart Tools, click the IPC Tools page, then enter the device information including IP address, MAC address, Status, Port number, Netmask, and Gateway of all network cameras will be displayed. Details are shown as shown below; BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 6 Step4: If the selected camera shows "Active" in the status bar, you can directly type the User Name and Password (Camera with version lower than 4x.7.0.69 is using admin/ms1234 by default), change the IP address or other network values, and then click “Modify” button; BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 7 (1) Password must be 8 to 32 characters long, contain at least one number and one letter. (2) You need to upgrade Smart Tools version to V2.4.0.1 or above to activate the camera. After activation, you can change the IP address or other network values, and then click “Modify” button. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 8 Step5: Change the IP address successfully; Step6: By double clicking the selected camera, you can access the camera via web browser directly. The Internet Explorer window will pop up. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 9: Assign An Ip Address Via Browser

    9). In the pop-up window, enter an IP address that in the same segment with network camera ( e.g. 192.168.5.61, but please note that this IP address shall not conflict with the IP address on the existing network); BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 10 Step4: After login, please select “Configuration”→ “Basic Settings”→ “Network”→ “TCP/IP”. The Network Settings page appears (Shown as following Figure); Step5: Change the IP address or other network values. Then click “Save” button; Step6: The change of default IP address is completed. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 11: Accessing From The Web Browser

    If IE9 or higher version browser is used, it is suggested that the camera web link should be added as a trusted site. See the instructions as follows: Step1: Start the IE9 or higher version browser, and select “Tools”→ “Internet Options”; BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 12 Step2: Select “Security” to “Trusted”; Step3: Enter the IP address of the camera in the blank and click “Add”; BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 13 3) For V4x.7.0.74 or above, you can enjoy Plugin-Free Mode without any configuration about the browser (Please upgrade the browser to the latest version). You can preview the video without plugin by selecting Plugin-Free Mode in Live View interface. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 14: Chapter Iv System Operation Guide

    After logging in the network camera web GUI successfully, user is allowed to view live video as follows. Table 4-1-1 Description of the buttons Parameter Description Brightness: Adjust the Brightness of the scene Contrast: Adjust the color and light contrast BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 15 When an alarm of Smart Event was triggered, the icon appears Alarm When an alarm of Motion Detection was triggered, the icon appears Alarm Except for the two kinds of alarms above, when other alarms were triggered, the icon appears BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 16 Start Talking Click to select system language 4.2 Playback This section explains how to view the recorded video files stored in SD cards or NAS. Step1: Click [Playback] on the menu bar to enter playback interface; BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 17: Operation

    The toolbar on the button of playback interface can be used to control playing progress. Table 4-1-2 Description of the buttons Button Operation Play Pause Stop Slow Forward Fast Forward BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 18: Local Settings

    Set Playback Time filed. You can also click to zoom out/in the progress bar. 4.3 Local Settings Record File Length and storage path can be customized in this setting page. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 19: Basic Settings

    4.4 Basic Settings 4.4.1 Video Stream parameters can be set in this module, adapting to different network environments and demands. Primary Stream Settings Record Stream Type (General) Record Stream Type (Event) Secondary Stream Settings BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 20: Function Introduction

    Smart Stream it is a 10-level adjustable codec. It is optional to turn On/Off Smart Stream mode. Level: Level 1~10 are available to meet your need. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 21 (On Screen Display) content and video time can be displayed to rich the image information. Display Table 4-4-2 Description of the buttons Parameters Function Introduction Power Line Frequency 60Hz flicker for 30fps camera model and 50Hz flicker for 25fps camera model BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 22 There are four options available, you can select one to meet your need Off: Keep the image in normal direction Image Rotation Rotating 180°: Upside down the image Flip Horizontal: Flip the image horizontally Flip vertical: Flip the image vertically Enhancement BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 23 1~1/100000 he higher the value s, t is, the brighter the image is; Schedule Mode:You can customize the schedule to enable/disable Auto Mode and Manual Mode. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 24 Day Enhancement Mode BLC/WDR/HLC are available. Night Enhancement BLC/WDR/HLC are available. Mode Schedule Setting Customize the schedule to enable/disable BLC/WDR/HLC mode Note: 1) You can customize the schedule to enable/disable the difference White Balance modes. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 25 2) You can customize the schedule to enable/disable the difference exposure modes. 3) You can customize the schedule to enable/disable BLC/WDR/HLC mode. 4) WDR/HLC has higher priority than exposure settings at the same time frame. 5) Defog Image. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 26: Day/Night Mode

    6) HLC Image. Day/Night Mode BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 27: On-Screen Display (Osd)

    Enable to set different color for title and date Enable to set different colors for display information background on screen Background Color You can set different colors for font and background of image , then the image BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 28: Privacy Mask

    Copy the settings to other streams Privacy Mask Privacy mask enables to cover certain areas on the live video to prevent certain spots in the surveillance area from being viewed and recorded. You can set four mask areas at most. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 29 By using ROI technology, more than 50% of bit rate can be saved and therefore less bandwidth demanded and the storage usage reduced. So according to this, you can set a small bit rate for high resolution. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 30 A two-way communication is also possible to be achieved with this feature. Alarm can be triggered when the audio input is above a certain alarm level you set, and configured audio can be played when an alarm occurs. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 31 Output Volume: Adjust volume of output You can upload up to 5 audio files manually to Flash or SD Card on the Audio web page and you can also edit the audio file’s name when upload. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 32 Primary DNS: The DNS Server translates the domain name to IP address IPv6 Mode: Choose different mode for IPv6: Manual/Route Advertisement/ DHCPv6 IPv6 Address: IPv6 Address used to identify a network camera on the network BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 33 Start or stop using HTTPS HTTPS Port Web GUI login port via HTTPS, the default is 443 HTTP Settings Upload and set the SSL certificate . HTTP URL are as following: Stream Main Steam http://username:password@IP:port/ipcam/mjpeg.cgi Secondary Stream http://username:password@IP:port/ipcam/mjpegcif.cgi BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 34 Multicast Group Support multicast function Address QoS DSCP The valid value range of the DSCP is 0-63. RTSP URL are as following: Stream Main Steam rtsp://username:password@IP:port/main Secondary Stream rtsp://username:password@IP:port/sub BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 35 Table 4-4-12 Description of the buttons Parameters Function Introduction Enable Check the checkbox to enable the UPnP function Enable Port Mapping Check the checkbox to enable the Port Mapping Name The name of the device detected online can be edited BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 36 2) Make sure that the internal and the external port number of RTSP are the same. Email Alarm video files can be sent to specific mail account through SMTP server. You must configure the SMTP settings correctly before using it. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 37 Check the checkbox to enable SSL or TLS if it is required by the SMTP server. Alarm video files can be sent to specific FTP server. You must configure the FTP settings correctly before using it. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 38 If you choose to customize image file name, YYYY-MM-DD/ MM-DD-YYYY/ DD- Image File Name MM-YYYY/ Add prefix are available. Timing Snapshot File Default(YYYY-MM-DD) /MM-DD-YYYY/ DD-MM-YYYY/ Add prefix/ Overwrite with Name the base file name are available. Note: BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 39 Before setting the SNMP, please download the SNMP software and manage to receive the camera information via SNMP port. By setting the Trap Address, the camera can send the alarm event and exception messages to the surveillance center. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 40 Input the name of Write Security Community Level of Security There are three levels available: (auth, priv), (auth, no priv) and (no auth, no priv) SNMP Port The port of SNMP, the default is 161 Note: BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 41 Internet, between a Flash player and a server. RTMP is a TCP-based protocol which maintains persistent connections and allows low-latency communication. It can realize the function of live broadcast so that customers can log in to the camera wherever there is a network. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 42: Date And Time

    Enable the daylight saving time NTP server Input the address of NTP server NTP Sync Synchronize the time with your computer Manual Set the system time manually Synchronize with Synchronize the time with your computer computer time BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 43: Advanced Settings

    ActiveCells Settings Compatible. Select All Click the button, the motion in the area will be detected Clear All Click the button, the area drawn before will be removed Step2: Set motion detection schedule; BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 44 Support to pop up the alarm news to specified HTTP URL. Note: HTTP Notification 1) Three HTTP notifications at most can be added to the same event. 2) HTTP Notification supports Basic & Digest authentication NOTE: BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 45: Audio Alarm

    Play Audio Interval Auto/ 10 seconds/ 30 seconds/ 1 minute/ 5 minutes/ 10 minutes are available. Note: You can customize the schedule of Audio Action. Audio Alarm Enable the Audio before using Audio Alarm function. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 46: External Input

    The meaning of items please refer to table 4-5-2 and 4-5-3, here will not repeat again. External Input BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 47: External Output

    The meaning of items please refer to table 4-5-2 and 4-5-3, here will not repeat again. External Output BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 48 External Output on the Alarm Action firstly Audio Action Settings: Set the audio schedule to trigger different audio files and action times in different time, which is corresponded to alarm action BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 49: Storage Management

    The network disk should be available within the network and properly configured to store the recorded files, etc. NAS (Network-Attached Storage), connecting the storage devices to the existing network, provides data and files services. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 50: Record Settings

    Function Introduction Enable/Disable Recycle Storage, if you enable this option, it will delete the files Enable Recycle Storage when the free disk space reach a certain value. Pre-record Reserve the record time before alarm, 0~10 sec BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 51: Snapshot Settings

    Files will be seen on this page when they are configured to save into SD card or NAS. You can set time schedule every day for recording videos and save video files to your desired BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 52 SD card by ftp, for example, ftp://username:password@192.168.5.190(user name and password are the same as the camera account and the IP followed is the IP of your device.). 4.5.3 Security User BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 53 “Forget Password” button on login page to reset the password by answering three security questions correctly. Security Question There are twelve default questions below, you can also customize the security questions. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 54: Access List

    It also supports set-up of the security questions for the devices. Users can reset the password by answering the correct security Access List BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 55: Security Service

    Security Service Table 4-5-11 Description of the buttons Parameters Function Introduction Secure Shell (SSH) has many functions: it can replace Telnet and also provides a SSH Settings secure channel for FTP, POP, even for PPP. Watermark BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 56: Sip Settings

    2) Register another user account for the SIP device from the same SIP server; 3) Call the camera User ID from the SIP device, you will get the video on the SIP device. SIP Settings BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 57 SIP account password Server Address Sever IP address Server Port Sever port Connection UDP/TCP Protocol Video Stream Choose the video stream Max Call Duration The max call duration when use SIP Note: SIP supports Directly IP call. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 58: White List

    Table 4-5-14 Description of the buttons Parameters Function Introduction Phone Type Phone Number(Call by phone number) & Direct IP Call Phone Number/ Including the phone number or IP address on the white list IP Address BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 59 Enable White List When enabled, it can only visited by the designated phone number or IP Number Filter address. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 60 Motorized Mini Bullet, Motorized Pro Bullet Network Camera, Mini Bullet Network Camera. (2) Currently we have three LPR versions, LPR1, LPR2 and LPR3. LPR1 is for Asian regions, LPR2 is for European regions and the former Soviet Union and LPR3 is for Korea. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 61 Generated by camera’s information (Only for LPR2 and LPR3) License Status Show present license status, including Valid and Invalid. (Only for LPR2 and LPR3) Processing Resolution Resolution of the stream for LPR analysis, including 1920*1280, 1280*720, BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 62 Click the "Clear" button to clear the area being drawn. Delete All Click the "Delete All" button to delete all the added areas. Step4: Schedule Settings. You can draw the schedule by clicking Edit button. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 63 You can set Repeat Plate Checktime from 0 to 60min or 0 to 60000ms. Check Region(Only for LPR2), ROI_ID, Direction or All to enable Feature Feature Identification Identification, it will display the corresponding information on the Smart Search interface. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 64 In the interface, you can set display information on snapshot of license plate recognition, and also customize the file name of snapshots which are uploaded via FTP or Email or stored on local LPR Picture File Path. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 65 You can customize the snapshot file name according to items chosen. Item of File Name The default items checked are Time and License Plate. Each time when an item is checked, the list will add the item row, including the item name and BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 66 Once license plate is recognized, and the snapshot will be uploaded via FTP or Email or stored on your local LPR Picture File Path. Then, You can see the snapshot file name which you customize as shown below: full-snapshot Recognized successfully full-snapshot Recognized failed BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 67: List Management

    List Search button, the corresponding license plate will be displayed in the list below. Click the "Export List" button to export the license plate in the current list to a Export List csv form locally. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 68 Note: It supports adding 1000 Black List and White List. Black List Mode Step1: Check the checkbox to enable Black List Mode. Step2: Schedule Settings. You can draw the schedule by clicking Edit button. Step3: Set alarm action. Step4: Set alarm settings. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 69 White List Mode Step1: Check the checkbox to enable White List Mode. Step2: Schedule Settings. You can draw the schedule by clicking Edit button. Step3: Set alarm action. Step4: Set alarm settings. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 70 After that, when a license plate marked as “White” is detected, the camera will respond accordingly to your settings. Visitor Mode Step1: Check the checkbox to enable Visitor Mode. Step2: Schedule Settings. You can draw the schedule by clicking Edit button. Step3: Set alarm action. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 71: Smart Search

    Step1: Select Plate Type or directly enter the license plate number and then select Start Time and End Time. The related license plate information will be displayed as below by one click on the “Search” button. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 72 Step2: Click on the thumbnail photo under the LPR Logs, then the license plate details will be shown as below : Step3: Click the "Export" or “Export All” button to export the desired files in the current list to a local folder. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 73 All information about the hardware and software of the camera can be checked on this page. Table 4-7-1 Description of the buttons Parameters Function Introduction Device Name The device name can be customized. It will be seen in file names of video files BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 74: System Maintenance

    Uptime The elapsed time since the last restarted of the device Note： The Alarm Input/Alarm Output will appear only when the camera has alarm input/output interface. Maintenance System Maintenance Table 4-8-1 Description of the buttons BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 75 Import Config File: Click this button, then a window will pop up and you can click "OK" to update the configuration. It will pop up a window to prompt "Input the password of config file" , then enter password and click save button to import configuration file. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...

  • Page 76: Auto Reboot

    Click “Reboot” button to restart the device immediately Auto Reboot Set the date and time to enable Auto Reboot function, the camera will reboot automatically according to the customized time in case that camera overload after running a long time. BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 77 BOS ITALY S.R.L Via Chiesa, 22 – 36044 Val Liona (VI) – ITALY P.IVA 03576140242 – Tel. +39 0444868678 – Fax. +39 04441491650 BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
  • Page 78 – www.bositaly.it BS-IPT4002LPR / BS-IPT4012LPR USER GUIDE...
