TURFCO WIDESPIN 1540 TEC Operator's Manual

Truck mounted broadcast top dresser
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
Truck Mounted Top Dresser
OPERATOR'S MANUAL
MAINTENANCE MANUAL
PARTS LIST
TURFCO
®
WIDESPIN
1540 TEC
™
Truck Mounted Broadcast
Top Dresser
Product Number 85816
Starting Serial Number N00101
US Patent 6,149,079, 6,508,419 and 6,817,552
Additional Patents Pending
Manual Number 665973-GB
DANGER
- IF INCORRECTLY USED THIS MACHINE CAN CAUSE SEVERE
INJURY. THOSE WHO USE AND MAINTAIN THIS MACHINE SHOULD BE
TRAINED IN ITS PROPER USE, WARNED OF ITS DANGERS, AND SHOULD
READ THE ENTIRE MANUAL BEFORE ATTEMPTING TO SET-UP, OPERATE
OR SERVICE THE MACHINE.
TURFCO MFG. INC.
1655 101st. Avenue NE ● Minneapolis, MN 55449-4420 USA
Phone (763) 785-1000 ● FAX (763) 785-0556
Internet - www.turfco.com ● E-Mail - service@turfco.com
2009 Turfco Mfg., Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WIDESPIN 1540 TEC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TURFCO WIDESPIN 1540 TEC
