1. Identifying the Parts
Mounting Holes B
Lens
•
Mounting hole A dimension: M3 x 0.4P, 3.5mm depth.
•
Mounting hole B dimension: M2 x 0.5P, 3mm depth.
2. How to Connect the Camera
•
Refer to the scenarios below to connect the camera module using a USB Type-C cable. Make sure there is a USB Type-C connector on your
computer.
Connect to a laptop
Mounting Holes A
Mounting Holes B
Lock Ring
Quick Install Guide
Mounting Holes A
USB Type-C Connector
Connect to a desktop
Vizioncam Series Camera
Advertisement
Table of Contents
Related Manuals for TechNexion Vizioncam Series
Summary of Contents for TechNexion Vizioncam Series
- Page 1 Quick Install Guide INNOVATORS OF TECHNOLOGY Vizioncam Series Camera 1. Identifying the Parts Mounting Holes B Mounting Holes A Mounting Holes A Mounting Holes B Lens Lock Ring USB Type-C Connector • Mounting hole A dimension: M3 x 0.4P, 3.5mm depth.
- Page 2 Turn the lens clockwise or counterclockwise until you have achieved the best quality of the image. Turn the lock ring clockwise to tighten the lens. 5. Getting Information Select a compatible camera Software and development resources https://www.technexion.com/products/embedded-vision/vizioncam/ https://www.technexion.com/support For more information contact TechNexion sales www.technexion.com sales@technexion.com INNOVATORS OF TECHNOLOGY...
