Hardware Maintenance Manual
Yoga Slim 7 (15", 05) and Yoga Creator 7 (15", 05)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Yoga Slim 7 and is the answer not in the manual?

Questions and answers

Related Manuals for Lenovo Yoga Slim 7

Summary of Contents for Lenovo Yoga Slim 7

  • Page 1 Hardware Maintenance Manual Yoga Slim 7 (15″, 05) and Yoga Creator 7 (15″, 05)
  • Page 2 First Edition (May 2020) © Copyright Lenovo 2020.

  • Page 3: Table Of Contents

    Trademarks ....lxiii Remove the Wi-Fi card ... . Remove the LCD module ... © Copyright Lenovo 2020...
  • Page 4 Hardware Maintenance Manual...

  • Page 5: About This Manual

    Important: • This manual is intended only for trained service technicians who are familiar with Lenovo products. • Before servicing a Lenovo product, be sure to read all the information under Chapter 1 “Safety information” on page 1. © Copyright Lenovo 2020...
  • Page 6 Hardware Maintenance Manual...

  • Page 7: Chapter 1. Safety Information

    • Do not work alone under hazardous conditions or near equipment that has hazardous voltages. • Disconnect all power before: – Performing a mechanical inspection – Working near power supplies © Copyright Lenovo 2020...

  • Page 8: Safety Inspection Guide

    This guide addresses only those items. You should use good judgment to identify potential safety hazards due to attachment of non-Lenovo features or options not covered by this inspection guide.

  • Page 9: Handling Devices That Are Sensitive To Electrostatic Discharge

    4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.

  • Page 10: Grounding Requirements

    Grounding requirements Electrical grounding of the computer is required for operator safety and correct system function. Proper grounding of the electrical outlet can be verified by a certified electrician. Safety notices (multilingual translations) The safety notices in this section are provided in the following languages: •...
  • Page 11 DANGER DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 12 Hardware Maintenance Manual...
  • Page 13 PERIGO PERIGO PERIGO Chapter 1 Safety information...
  • Page 14 PERIGO PERIGO PERIGO PERIGO PERIGO Hardware Maintenance Manual...
  • Page 15 DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 16 DANGER DANGER DANGER DANGER VORSICHT Hardware Maintenance Manual...
  • Page 17 VORSICHT VORSICHT VORSICHT VORSICHT Chapter 1 Safety information...
  • Page 18 VORSICHT VORSICHT VORSICHT Hardware Maintenance Manual...
  • Page 19 Chapter 1 Safety information...
  • Page 20 Hardware Maintenance Manual...
  • Page 21 Chapter 1 Safety information...
  • Page 22 Hardware Maintenance Manual...
  • Page 23 Chapter 1 Safety information...
  • Page 24 Hardware Maintenance Manual...
  • Page 25 Chapter 1 Safety information...
  • Page 26 Hardware Maintenance Manual...

  • Page 27: Chapter 2. General Checkout

    • Scratched (cosmetic) parts • Distortion, deformation, or discoloration of the cosmetic parts • Plastic parts, latches, pins, or connectors that have been cracked or broken by excessive force • Damage caused by liquid spilled into the system © Copyright Lenovo 2020...

  • Page 28: Cru List

    • Check for obvious damage to a hard disk drive. If the spindle of a hard disk drive becomes noisy, the hard disk drive might have been dropped or subject to excessive force. CRU list Table 1. Models: Yoga Slim 7 15IMH05 (Machine type: 82AB) Type ac power adapter...

  • Page 29: Chapter 3. Identifying Frus (Crus)

    Chapter 3. Identifying FRUs (CRUs) Locate FRUs and CRUs The exploded illustrations help Lenovo service technicians identify FRUs or CRUs that they may need to replace when servicing a customer’s computer. © Copyright Lenovo 2020...
  • Page 30 Figure 1. Exploded view - Yoga Slim 7 15IMH05 Hardware Maintenance Manual...
  • Page 31 Table 2. FRU (CRU) categories FRU (CRU) category Upper case (with keyboard) Power button (with fingerprint board) System board I/O bracket RTC battery Wi-Fi card Thermal module (with fans) Speakers (with subwoofer) Battery pack Lower case Solid-state drive (SSD) DC-in cable Touchpad with cable Power cord ac power adapter...
  • Page 32 Figure 2. LCD module exploded view - Yoga Slim 7 15IMH05 Table 3. LCD module FRU (CRU) categories FRU (CRU) category LCD cover Removable tape CCD cable Hardware Maintenance Manual...
  • Page 33 Table 3. LCD module FRU (CRU) categories (continued) LCD panel Hinges LCD side caps Hinge cover LCD bezel Microphone cable EDP cable Camera module Chapter 3 Identifying FRUs (CRUs)
  • Page 34 Hardware Maintenance Manual...

  • Page 35: Chapter 4. Removing A Fru Or Cru

    Chapter 4. Removing a FRU or CRU Service tools The following table lists tools for servicing Lenovo computers. Tools with a cross mark are needed for serving the product models as described by this publication. Prepare them before you service the product.

  • Page 36: Remove The Lower Case

    3. Follow the correct sequence in the steps for removing an FRU, as shown in the illustrations by the numbers in square callouts. 4. When removing an FRU, move it in the direction as shown by the arrow in the illustration. 5.

  • Page 37: Remove The Battery Pack

    Pry up the latches and then remove the lower case. Figure 4. Pry up the latches and remove the lower case Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Lower case Remove the battery pack Make sure the following FRU (or CRU) has been removed.

  • Page 38: Remove The Solid-State Drive (Ssd) Module

    Screw specifications Number of screws M2 x L5 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Battery pack Remove the solid-state drive (SSD) module Make sure the following FRU (or CRU) has been removed.

  • Page 39: Remove The Wi-Fi Card

    Figure 8. Remove the SSD module Step 4. Remove the SSD AL foil. Figure 9. Remove the SSD AL foil Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: SSD AL foil Remove the Wi-Fi card Make sure the following FRU (or CRU) has been removed.

  • Page 40: Remove The Lcd Module

    Figure 11. Remove the Wi-Fi card Screw specifications Number of screws M2 x L2.5 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Wi-Fi card Remove the LCD module Make sure the following FRU (CRU) has been removed.
  • Page 41 Step 1. Disconnect the battery cable from the system board.. Attention: Use your fingernails to pull the connector to unplug the cables. Do not pull the cable. Step 2. Peel off the mylar strip and detach the antenna cable connectors. Release the CCD cable and the antenna cables, disconnect the CCD cable and the EDP cable from the system board.
  • Page 42 Number of screws Screw specifications M2 x L3.5 Step 4. Remove the LCD module. Figure 14. Remove the LCD module Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: LCD module Hardware Maintenance Manual...

  • Page 43: Remove The Thermal Module (With Fans)

    Remove the thermal module (with fans) Make sure the following FRU (or CRU) has been removed. “Remove the lower case” on page 30 Step 1. Disconnect the battery cable from the system board. Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable. Step 2.

  • Page 44: Remove The Speakers (With Subwoofer)

    Screw specifications Number of screws M2 x L2.5 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Thermal module (with fans) Remove the speakers (with subwoofer) Make sure the following FRUs (CRUs) have been removed.

  • Page 45: Remove The Dc-In Cable

    Release the speaker cables from the cable guide and then remove the speakers (with subwoofer). Figure 19. Remove the speakers (with subwoofer) Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Speakers (with subwoofer) Remove the DC-in cable Make sure the following FRU (or CRU) has been removed.

  • Page 46: Remove The I/O Bracket

    Open the hinge and then remove the DC-in cable. Figure 21. Remove the DC-in cable Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: DC-in cable Remove the I/O bracket Make sure the following FRU (or CRU) has been removed.
  • Page 47 Step 2. Disconnect the fingerprint board cable from the system board. Figure 22. Disconnect the fingerprint board cable from the system board Step 3. Release the antenna cables and the CCD cable. Remove two screws on hinge and open the hinge. Separate the power button (with fingerprint board) from the I/O bracket.

  • Page 48: Remove The Rtc Battery

    Figure 24. Remove the I/O bracket Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: I/O bracket Remove the RTC battery Make sure the following FRU (or CRU) has been removed. “Remove the lower case” on page 30 Note: Only some models come with the fingerprint board.

  • Page 49: Remove The System Board

    Remove the system board Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 30 “Remove the battery pack” on page 31 “Remove the solid-state drive (SSD) module” on page 32 “Remove the Wi-Fi card” on page 33 “Remove the thermal module (with fans)”...

  • Page 50: Remove The Power Button (With Fingerprint Board)

    Figure 28. Remove the system board Screw specifications Number of screws M2 x L3.5 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: System board Remove the power button (with fingerprint board) Make sure the following FRUs (or CRUs) have been removed.

  • Page 51: Remove The Touch Pad With Cable

    Separate the fingerprint board cable from the power button. Figure 30. Separate the fingerprint board cable from the power button Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement parts: Fingerprint board cable Power button (with fingerprint board) Remove the touch pad with cable Make sure the following FRUs (or CRUs) have been removed.
  • Page 52 “Remove the lower case” on page 30 “Remove the battery pack” on page 31 “Remove the solid-state drive (SSD) module” on page 32 “Remove the Wi-Fi card” on page 33 “Remove the thermal module (with fans)” on page 37 “Remove the I/O bracket” on page 40 “Remove the system board”...
  • Page 53 Step 2. Remove six screws. Figure 32. Remove six screws Screw specifications Number of screws M2 x L1.5 Step 3. Remove the touchpad with cable. Figure 33. Remove the touchpad with cable Step 4. Separate the touchpad cable from the touchpad. Figure 34.

  • Page 54: Remove The Upper Case (With Keyboard)

    “Remove the system board” on page 43 “Remove the power button (with fingerprint board)” on page 44 “Remove the touch pad with cable” on page 45 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Upper case (with keyboard) Disassemble the LCD module The LCD module as a whole is not an FRU.

  • Page 55: Remove The Hinges

    Step 1. Pry up the bottom of the hinge cover and then remove the hinge cover. Figure 35. Remove the hinge cover Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Hinge cover Remove the hinges Make sure the following FRUs (or CRUs) have been removed.

  • Page 56: Removal Procedure For Lcd Panel (Non-Glass)

    Number of screws M2 x L2.5 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: LCD bezel Remove the LCD panel (non-glass) and the EDP cable Make sure the following FRUs (or CRUs) have been removed.
  • Page 57 Figure 38. Remove the LCD bezel Step 2. Disconnect the EDP cable from the back of the LCD panel. Figure 39. Remove the EDP cable Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: LCD panel EDP cable...

  • Page 58: Removal Procedure For Lcd Panel (Glass)

    Step 1. Remove the LCD side caps. Figure 40. Remove the LCD side caps Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: LCD side caps Remove the LCD panel (glass) and the EDP cable Make sure the following FRUs (or CRUs) have been removed.
  • Page 59 Figure 41. Remove four screws Screw specifications Number of screws M2 x L1.5 M2 x L2.5 Step 2. Remove the two pieces of removable tape with tweezers carefully. Figure 42. Remove the two pieces of removable tape with tweezers carefully Step 3.

  • Page 60: Remove The Camera Module And Microphone Cable

    Step 4. Disconnect the EDP cable from the back of the LCD panel. Figure 44. Remove the EDP cable Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following replacement parts: LCD panel EDP cable Removable tape Remove the camera module and microphone cable Make sure the following FRUs (or CRUs) have been removed.

  • Page 61: Remove The Ccd Cable

    Figure 46. Remove the camera module Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Camera module Microphone cable Remove the CCD cable Make sure the following FRUs (or CRUs) have been removed. “Remove the LCD module” on page 34 “Remove the hinge cover”...
  • Page 62 52 “Remove the camera module and microphone cable” on page 54 “Remove the CCD cable” on page 55 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: LCD cover Hardware Maintenance Manual...

  • Page 63: Appendix A. Label Locations

    For the laser etched label, print the label and apply it to the replacement cover according to the label location illustrated above. The artworks for the laser etched labels are country/ region specific and can be found in Appendix B. Artworks for laser etched labels. © Copyright Lenovo 2020...
  • Page 64 Hardware Maintenance Manual...

  • Page 65: Appendix B. Artworks For The Laser Etched Labels

    Appendix B. Artworks for the laser etched labels © Copyright Lenovo 2020...
  • Page 66 Hardware Maintenance Manual...
  • Page 67 Appendix B. Artworks for the laser etched labels...
  • Page 68 Hardware Maintenance Manual...

  • Page 69: Trademarks

    Trademarks Lenovo and the “lenovo” logo are trademarks of Lenovo in the United States, other countries or both. Other company, product, or service names may be trademarks or service marks of others.
