- Page 1 ÜNO/DÜO Installation Instructions English Revision March 2022...
-
Page 2: Table Of Contents
TABLE OF CONTENTS ABOUT THIS GUIDE ......3 VOICEMEETER SETTINGS ....17 IMPORTANT SAFETY INSTRUCTION ..3 INSTALLATION CONFIGURATION ..20 GYM (D) ..........21 LÜ INSTALLATION INSTALLERS POLICIES ......4 Palestra (D) ..........22 PACKAGE CONTENTS ......5 Camera module (E) ........23 Projection module (F) ......24 REQUIRED ITEMS FOR THE INSTALLATION ........ -
Page 3: About This Guide
ABOUT THIS GUIDE The Lü interactive system installation manual provides basic product information such as safety and operation. Disclaimer The information and specifications contained in this installation manual are subject to change without notice. IMPORTANT SAFETY INSTRUCTION Do not use this system near water. Clean only with a dry cloth. -
Page 4: Lü Installation Installers Policies
The methods used, the procedures followed and the safety measures put in place during the installation engage the responsibility of the installer, and this, for the total lifetime of the product. For any further questions, information or validations, please contact our facility coordination team at support@play-lu.com. -
Page 5: Package Contents
PACKAGE CONTENTS Each ÜNO/DÜO configuration consist of: Heart module Light & sound module Projection module Lü management system. 6 x 200 watts LED spotlights 5200 lumens WXGA* projector to manage the ambient protected in a custom lighting and general colors, enclosure. -
Page 6: Required Items For The Installation
REQUIRED ITEMS FOR THE INSTALLATION The following items are not included in the box : All the material needed for structural hanging on the ceiling depending of construction type (ex. Cantruss, 1/2” [13 mm] threaded rod, bolts and nuts, etc.). Security steel cables and fasteners to secure components directly to building structure, second safety, 3/16”... -
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS ÜNO configuration Camera module Projector module Installation position* 15’ from the wall / 18’ high 28’ from the wall / 20’ high Size (L x W x H) 6” x 4” x 5” 22” x 20” x 16” Weight 3.05 lb (1.38 kg) 37 lb (16.78 kg) -
Page 8: Light And Sound Module
TECHNICAL SPECIFICATIONS Light and sound module With speaker Without speaker Installation position* 16’ from the wall / 20’ high 16’ from the wall / 20’ high or less Size (L x W x H) 37” x 76” x 15” 37’’ x 46” x 15’’ Weight 178 lb (80.74 kg) 99 lb (44.91 kg) -
Page 9: Heart Module
TECHNICAL SPECIFICATIONS Heart module Heart module Installation position* 12” over the projection (centered) Size (L x W x H) 14” x 23” x 5” Weight 18 lb (8.16 kg) Rigging Screw on the wall 120-240V - 216W (1.8A) Power consumption IMPORTANT : The installation parameters in this guide are optimal recommendations. -
Page 10: Installation Configuration
INSTALLATION CONFIGURATION ÜNO & DÜO Lü can be sold in two different configurations. The ÜNO configuration broadcasts on an interactive wall while the DÜO configuration includes two ÜNO units projecting on two interactive walls face to face or side by side. All it takes is a few minor tweaks and additional connections to allow for a synchronized experience occupying the entire gym. -
Page 11: Gym Configuration
GYM CONFIGURATION ÜNO Installation Configuration Side view All units must be mounted to the ceiling and aligned according to the projection surface. The diagram below shows the optimal position. Some exceptions for special environments can be made, within the flexibility margins. D: 28’... -
Page 12: Üno Wiring Diagram
GYM CONFIGURATION ÜNO wiring diagram Top view Connect modules 1, 2, 3 and 4 using this diagram Projector Lighting Heart Top view 120 Volts cable 10’ (3 m) et 25’ (4,5 m) IEC HDMI cable 65’ (20 m) XLR Speakers cable 25’... -
Page 13: Düo Wiring Diagram
GYM CONFIGURATION DÜO wiring diagram Top view Use the ÜNO wiring diagram to connect the projector, light and sound, camera, and Heart modules. Interconnect the two light modules following this diagram. Lighting Projector Projector Lighting Master unit Master unit Secondary unit Secondary unit Top view 30’... -
Page 14: Palestra Configuration
PALESTRA CONFIGURATION ÜNO installation diagram Side view All units must be mounted to the ceiling and aligned with the projection area. The diagram below shows the optimal position. Some exceptions for special environments can be made, provided they fall within the margins. UNÖ-DUÖ... -
Page 15: Üno Wiring Diagram
PALESTRA CONFIGURATION ÜNO wiring diagram Top view Use this wiring diagram to connect the projector, light and sound, camera, and Heart modules. Sound Lighting Camera Heart Projector Sound Top view 120 Volts cable 10’ (3 m) HDMI cable 65’ (20 m) XLR Speakers cable 25’... -
Page 16: Düo Wiring Diagram
PALESTRA CONFIGURATION DÜO wiring diagram Top view Use the ÜNO wiring diagram to connect the projector, light and sound, camera, and Heart modules. Interconnect the two light modules following this diagram. Speaker A Speaker C Ligting Projector Projector Lighting Heart Heart Master unit Master unit... -
Page 17: Voicemeeter Settings
VOICEMEETER SETTINGS Open the Windows taskbar, then open Voicemeeter Banana and click on “Menu” at the top right. Uncheck “Lock Graphic User Interface.”... - Page 18 Open the A1 source menu at the top right and select “WDM: Speakers (Realtek [R] Audio).” Click on “Menu” at the top right, then on “Save Settings…”...
- Page 19 After the window opens, select the XML Document file “Lu-Voicemeeter-settings” and click on “Save” to agree to overwrite the old save. Click on “Menu” at the top right and check “Lock Graphic User Interface.”...
-
Page 20: Installation Configuration
INSTALLATION CONFIGURATION Step by step (A to C) Choose the best projection location on the wall (center and 4 corners) The recommended width is 19’ (5.8 m) and the recommended height is 10.7’ (3.3 m). For the ideal position, the lower end of the screen should be placed at 12” (20 cm) from the floor.Minimal height is 8” (20 cm) from the floor and maximal height is 16”... -
Page 21: Gym (D)
INSTALLATION RIGGING - GYM (D) Lighting module Lift and install the lighting module in place, as follows: Make sure the base is installed in the direction indicated by the sticker. Hang the mounting base with the threaded rods, making sure the bolts are doubled. Disconnect and then unscrew the two moving lights from the lighting tray with an 8 mm socket (so that the weight of the module is under 23 kg [50 lbs] for a safe single-person installation). -
Page 22: Palestra (D)
INSTALLATION RIGGING - PALESTRA (D) Lighting module Lift and install the lighting module in place, as follows: Make sure the base is installed in the direction indicated by the sticker. Hang the mounting base with the threaded rods, making sure the bolts are doubled. Screw the mounting base directly to the ceiling using 8 screws appropriate for the structure. -
Page 23: Camera Module (E)
INSTALLATION RIGGING - CAMERA MODULE (E) Lift and install the camera module Secure the camera module using the ceiling plate and a DN 40 (1 1/2”-11.5 NPS) threaded pipe (length to be determined by the ceiling height; the bottom of the camera should be at 18’ [5,5 m] from ground). Use a self-drilling screw at the ceiling plate to block any pipe rotation. -
Page 24: Projection Module (F)
INSTALLATION RIGGING - PROJECTION MODULE (F) Lift and install the projector module Secure the projector module using the ceiling plate and a DN 40 (1 1/2”-11.5 NPS) threaded pipe (length to be determined by the ceiling height; the bottom of the camera should be at 20’ [6 m] from ground). Use a self-drilling screw at the ceiling plate to block any pipe rotation. -
Page 25: Heart Module (G)
INSTALLATION RIGGING HEART MODULE (G) Lift and install the Heart, as follows Install the mounting plate to the projection wall in the center of the markers made in step 2. The bottom of the mounting plate should be between 6’ (15 cm) and 12’ (30 cm) above the projection. Insert the Hearth module from top to bottom into the wall mount. -
Page 26: Connection - Cables (H)
CONNECTION - CABLES (H) Connect the cables, as follows : Plug the Cat5 network cable into the computer’s network jack. Plug the Heart power cable into the power outlet. Bring the USB, HDMI, and DMX cables to the light module, attaching them to the structure. Connect the USB extension cable to the camera’s USB cable. -
Page 27: Projector Alignment (I)
PROJECTOR ALIGNMENT (I) Projector alignment procedure Using the projector’s (vertical) lens adjuster, lower the image as far as possible. Physically guide the projector module until it is at a 90° angle to the wall, then use the 4 screws on the bracket to stop the rod from rotating. -
Page 28: System Startup (J)
SYSTEM STARTUP (J) System startup At this point, all components must be plugged in and powered according to the wiring diagram (see pages 14 to 16). On the HDMI 1 source, the video projector should display the “Let’s get started!” message from the computer screen. -
Page 29: Camera Calibration
CAMERA CALIBRATION This step checks if the camera is set up properly. Camera feed The camera feed will let you adjust the camera so that the projection is fully visible within the feed. Please note that the projected image has a 4:3 ratio to the displayed image. Aim the camera at the wall by physically adjusting the tilt of the module, then screwing the module to the pole. - Page 30 Turn off the lights around the interactive wall (the room should not be completely dark). Click on the “CALIBRATE” button. A calibration grid will be displayed while the system is calibrating. A few seconds later, the message “Calibration successful” should appear. Even if the automatic calibration has failed, continue on to manual calibration.
-
Page 31: Lighting And Sound
LIGHTING AND SOUND Lighting Click on “Ready” to test the lighting system. Make sure the lights match the colors shown. Click on “Ready” to test the moving (or robotic) lights. Make sure both fixtures in each lighting unit are working. If one or more lights are not working, make sure you have connected the DMX cables properly or contact the technical support team. -
Page 32: Acceptation Of Installation
Pictures of the 4 walls and ceilings of the place of the installation (gym) at the time of your departure, if a system for occulting the windows is available, put it on the picture with the general lights on. Signed acceptation of the installation. Send these photos to : support@play-lu.com... -
Page 33: Contact Informations
CONTACT INFORMATIONS For support, any questions or comment on this product : Lü North America Lü Europe 1-855-781-0797 +32 87 60 87 54 support@play-lu.com support@play-lu.eu 202-707, St-Vallier Street East Quebec, QC, Canada G1K 3P9...
