PROGLOVE
USER MANUAL
Technical document

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ProGlove LEO

Summary of Contents for ProGlove LEO

  • Page 1 PROGLOVE USER MANUAL Technical document...

  • Page 2: Table Of Contents

    Switch on Scanner .......... 18 step: Connect Scanner ..........19 Hardware & Wearables ..........step: Scan ..............24 SCOPE OF DELIVERY step: Disconnect ProGlove System ......25 Hardware & Wearables ..........step: Release Scanner from Wearables ....29 TECHNICAL PROPERTIES CONFIGURING DEVICES AND Scanner ................
  • Page 3 step: Configure devices and Firmware Update ..32 Gateway - Data transfer ..........42 Charging Station ............43 SIGNAL TABLE DISPOSAL General Scanning ............34 .............. 44 Connection via BLE ............35 DIRECTIVES & CERTIFICATION Gateway ................36 ..... 44 STORAGE AND CLEANING SUPPORT Storage ................
  • Page 4 It is intended for process planners, integrators and maintenance Slight bodily injury or danger of physical damage to technicians who are using ProGlove system for the first time. It ProGlove system is possible. is designed so that ProGlove system can be used safely without prior knowledge.

  • Page 5: Safety Instructions

    CAUTION CAUTION Otherwise this may Otherwise the safe cause pain or pressure points on your hand. functioning of ProGlove system cannot be ensured. CAUTION This may otherwise lead to ProGlove system not functioning properly. CAUTION This may otherwise lead to ProGlove not functioning properly.

  • Page 7: Scope Of Delivery

    SCOPE OF DELIVERY CAUTION Do not use any damaged Hardware or Wearables! Check whether Hardware and Wearables are properly packaged and undamaged. SCANNER WEARABLES Index Trigger Hand Strap Reel CHARGING STATIONS Charging Station S / 10-Slot Charging Station with power cable (USB-C) and power supply...

  • Page 8: Scanner

    SCANNER OVERVIEW After scanning a barcode, the scanner returns feedback signals: haptically by vibrations, acoustically by audio signals and optically by LEDs. Standard range: 4 - 28 in (10 - 70 cm) Serial number Connection Battery symbol symbol LED’s...
  • Page 9 TECHNICAL DATA - LEO MECHANICAL PROPERTIES: BARCODE TYPES - 1D: Auto decodes all standard 1D codes including GS1 Dimensions: 1.47 x 1.77 x 0.67 in (50 x 45 x 17 mm) DataBar linear codes et al. Weight: 1.23 oz (35g)

  • Page 10: Connectivity Device

    USB cable. In the USB HID mode, the Gateway simulates a computer keyboard. A serial connection is emulated in the USB CDC mode. In order to use the USB CDC mode, the device must be set to “USB CDC” in the ProGlove Insight Configuration Tool (https://insight.proglove.com/)
  • Page 11 (via host computer) UTILITIES & ACCESSORIES: ProGlove Configuration Tool: https://insight.proglove.com/ Use for barcode, interface, device configuration et al. UTILITIES & ACCESSORIES: USB: USB HID (keyboard input on host) USB CDC (virtual com port) ProGlove Deep Integration Protocol via USB NOTE docs.proglove.de.

  • Page 12: Charging Station

    Power supply: 5 VDC (1.2 A) via power supply EU: SYS1561-1105 Attachment opening for M5 NA: SAW-06D-050-1200GB Pins screws Charging tray USB-C NOTE Further technical specifications are available on docs.proglove.de. Attachment opening for cable ties Label with serial number...
  • Page 13 10-SLOT CHARGING STATION OVERVIEW TECHNICAL DATA MECHANICAL PROPERTIES: The 10-Slot Charging Station provides multiple options to mount to flat surfaces, workstations and racks. The Dimensions: 3.74 x 2.06 x 0.94 in charging status is indicated by the LEDs of the scanner. The (298 x 203 x 25 mm) LEDs pulse red while in charging mode.

  • Page 14: Wearables

    WEARABLES HAND STRAP PROPERTIES GENERAL: The ProGlove Hand Strap offers an elastic, adjustable Velcro closure that ensures an optimal fit for any user's hand size Packaging unit: 3 or 10 pieces per package and shape. It can be worn with or without other gloves underneath.
  • Page 15 WEARABLES INDEX TRIGGER PROPERTIES GENERAL: The ProGlove Index Trigger offers hand size optimized variants and can be wrapped around the hand in one movement. The thumb hole fixes the wrap in the correct Packaging unit: 3 or 10 pieces per package position and the flexible Velcro mechanism allows it to be securely fastened to the user's hand.
  • Page 16 WEARABLES REEL PROPERTIES GENERAL: The ProGlove Reel can be attached with the black, rotating fastening clip to the desired spot. This can be, for example, on the user's clothing or on a belt. Alternatively, the Reel Packaging unit: 2 reels per package can also be worn on a lanyard around the neck.

  • Page 17: St Step: Charge Scanner

    APPLICATION OF PROGLOVE SYSTEM STEP: CHARGE SCANNER STEP: CONNECT THE CONNECTIVITY DEVICE CAUTION CAUTION Only use scanner in a dry Charging Station and Only touch the connectivity device with dry hands! This may otherwise only touch with dry hands! lead to the connectivity device not functioning properly.

  • Page 18: Rd Step: Switch On Scanner

    STEP: SWITCH ON THE SCANNER 2. Plug the other end of the 1. Position scanner on the USB cable into the Micro USB fastening rail of the wearable. socket of the Gateway. A The pins face down. clear clicking sound confirms 2.

  • Page 19: Th Step: Connect Scanner

    CONNECT VIA PROGLOVE INSIGHT MOBILE: TIP 2 For using a ProGlove scanner with ProGlove Insight Mobile Adhere the pairing barcode to the end device. In this way, via software keyboard, Intent or SDK find more information the user can find it quickly and easily.
  • Page 20 Bluetooth devices. Read the serial number of the scanner. RESULT Example serial number: LEO - 00000. To make the scanner visible for the end device, the scanner must be put into pairing mode: LEO - 00000 1.
  • Page 21 CONNECT WITH GOOGLE ANDROID 4.4 OR HIGHER: RESULT LEO - 00000 Under “Settings - Connected Tap “Bluetooth” and select Confirm the “Bluetooth Pairing The scanner will flash blue twice devices,” switch on the Bluetooth “Pair new device.” Request”. and you will hear two beeps.
  • Page 22 CONNECT WITH MICROSOFT WINDOWS 10: RESULT LEO - 00000 LEO - 00000 - 00000 Select ‘LEO - 00000’. The scanner will flash blue twice Under “Bluetooth & other Select the option “Bluetooth: and you will hear two beeps. devices,” click on “Add Bluetooth...
  • Page 23 RESULT LEO - 00000 LEO - 00000 LEO - 00000 Select “LEO - 00000”. Click “Done”. The scanner will flash blue twice and you will hear two beeps. The scanner will be shown as connected under “Bluetooth & other devices,” and is ready for...

  • Page 24: Th Step: Scan

    STEP: SCAN CAUTION The scanner is an omnidirectional scanner. Scanner can scan barcodes from different angles. The scanning range is between 4 - 28 in (10-70 cm) depending on application case and barcode size. 1. Press the trigger on the glove in order to activate the scanner.

  • Page 25: Th Step: Disconnect Proglove System

    STEP: DISCONNECT SCANNER DISCONNECT SCANNER FROM THE DISCONNECT THE CONNECTION CABLE CONNECTIVITY DEVICE FROM THE GATEWAY: Unplug Use the scanner connection cable to scan the pairing from the Micro code of a different USB port. Gateway. RESULT RESULT Scanner is disconnected from the Gateway and is The LED of the Gateway no longer lights up green.
  • Page 26 DISCONNECT FROM APPLE iOS: NOTE: Only disconnect scanner if this is to be newly connected to another end device. RESULT LEO - 00000 Under: “Settings - Bluetooth, ” Tap on “Forget this device.” Confirm “Forget Device.” The scanner will flash red three tap on the symbol.
  • Page 27 In the Bluetooth option under Select “Forget.” The scanner will flash red three “Paired devices,” tap on the gear times and you will hear three wheel symbol of “LEO - 00000.” beeps. Scanner will no longer be shown as connected under “Paired devices.”...
  • Page 28 LEO - 00000 Under “Bluetooth & other Click “Remove device.” The scanner will flash red three devices,” select “LEO - 00000.” times and you will hear three beeps. Scanner will no longer be shown as connected under “Bluetooth & other devices.”...

  • Page 29: Th Step: Release Scanner From Wearables

    Do not rub over the pins of the wearable with the scanner! This may otherwise lead to bent pins. More information about removing scanner from wearable can be found under proglove.com/support. 1. Use your fingers to press between the scanner and the fastening rail of the wearable.

  • Page 30: Configuring Devices And Firmware Updates

    CONFIGURING DEVICES AND FIRMWARE UPDATES The configuration tool under https://insight.proglove.com/ can be used to individually set the ProGlove System to improve scanning processes and to update the firmware. To update the firmware proceed with step 7. To create a new configuration proceed with step 1.

  • Page 31: Th Step: Device Settings

    IF a condition is true, THEN an action is executed. An action is also carried out without a condition. APPLICATION EXAMPLE: Insert the prefix “Pro” for the following barcode: Condition: Barcode matches “Glove” Action: Add Prefix “Pro” Outcome: “ProGlove”...

  • Page 32: Th Step: Configure Devices And Firmware Update

    ProGlove contact person. Follow the next steps. To configure PG Insight Mobile: Copy the downloaded configuration file in the following folder on your mobile device: (/sdcard)/Android/data/de.proglove. connect/files` RESULT The configuration file will be deployed automatically on the mobile phone.
  • Page 33 To configure the Gateway / Firmware update: 1. Connect the Gateway with the 5. Scan this barcode to disable the computer. The Gateway boots Gateway as a mass storage device on up. This takes about 2 min and the computer. is finished when the USB LED shows constant green light.

  • Page 34: Signal Table

    SIGNAL TABLE GENERAL SCANNER: Description Connection symbol Battery symbol Audio signal Vibration Barcode data could be Short green Short positive Short vibration transferred flashing beep Barcode data could not be Red flashing 3 Long negative Long vibration transferred times briefly beep Battery charge under 10% Slow red flashing...

  • Page 35: Connection Via Ble

    (915) SCANNER CONNECTION VIA BLE: Description Connection symbol Battery symbol Audio signal Vibration Scanner searches for an Pulsing Blue Pulsing Blue Continuously end device rising beep Scanner is connected to Blue flashing 2 Blue flashing 2 Short rising Short vibration an end device times briefly times briefly...

  • Page 36: Gateway

    GATEWAY Description LED 1 (USB - LED) LED 2 (SCANNER - LED) LED 3 (Cloud - LED) Gateway boots up Left to right run through all LEDs alternating Blue / Green until start *the boot up takes around 2 min. Gateway is connected to the Constantly green end device via USB...
  • Page 37 Description LED 1 (USB LED) LED 2 (Scanner - LED) LED 3 (Cloud - LED) Firmware Update: Constantly yellow Constantly yellow Constantly yellow Gateway is in download mode Firmware Update: Constantly purple Constantly purple Constantly purple Scanner is flashing / Gateway deploys Firmware Update: left to right run trough all LEDs alternating purple until done Gateway is flashing...

  • Page 38: Storage And Cleaning

    STORAGE AND CLEANING STORAGE STORAGE LOCATION: HARDWARE: Store hardware wearables in a dry and dirt-free environment. In case of transport, ProGlove System must CAUTION: be transported shockproof in its original packaging. Protect hardware from moisture! TEMPERATURE: This may otherwise lead to ProGlove System not Store hardware wearables in an environment between - functioning properly.

  • Page 39: Solution To The Problem

    SOLUTION TO THE PROBLEM SCANNER PROBLEM CAUSE SOLUTION Scanner is not responding. Battery is not charged. Charge scanner in the Charging Station for at least 20 min. Wearable is defective. Change wearable. Scanner is not vibrating or does not Feedback signals are disabled. Check whether the feedback signals in the beep after successful data transfer.
  • Page 40 SCANNER PROBLEM CAUSE SOLUTION What lights up? But no barcodes The barcode label cannot be read. Create new barcode label. are scanned. The barcode type cannot be read. Check whether the barcode type in the configuration tool is enabled under “Symbology settings”.

  • Page 41: Ble - Data Transfer

    BLE - DATA TRANSFER PROBLEM CAUSE SOLUTION Barcode data is not transferred. Scanner is not connected to the 1. Scan the pairing barcode. end device. 2. Lights up blue twice briefly while scanner is connecting and after a successful connection. Scanner lights up green after the Scanneris out of range of the end Bring scanner closer to the end device and...

  • Page 42: Gateway - Data Transfer

    (Maximum range is 100 - 130 ft. (30 - 40m)) Gateway is defective. Gateway must be replaced. More detailed information can be found at proglove.com/support. Scanner is defective. Scanner must be replaced. More detailed information can be found at proglove.com/support.

  • Page 43: Charging Station

    Connect Charging Station to power to power source. source. Scanner is defective. Scanner must be replaced. More detailed information can be found at proglove.com/support Charging Station is defective. The Charging Station must be replaced. More detailed information can be found at proglove.com/support...

  • Page 44: Disposal

    ProGlove System The ProGlove System, comprised of: MARK 2 MR, MARK Carry out the following steps to decommission ProGlove 2 SR, MARK Basic, MARK Display, LEO, Charging Station system: S, Access Point, Gateway, wearables, peripherals and 1. Release Scanner from Wearables accessories, complies with the following FCC/IC product 2.
  • Page 45 Under the regulations of the FCC and the IC the user has to be aware of the following when using the ProGlove LEO: 1. This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC...
  • Page 46 IC Specific Certification Compliance Under the regulations of the IC the user has to be aware of the following when using the ProGlove LEO: 1. This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference;...

  • Page 47: Support

    SUPPORT TECHNICAL SUPPORT CONTACT DATA If you have questions about integrating or using the ProGlove devices, our customer support department will be happy to help you. They will process your request as soon as possible. You can reach them at: SUPPORT WEBSITE: proglove.com/support...
  • Page 48 Workaround GmbH Building 64.08a Rupert-Mayer-Str. 44 81379 München Germany ProGlove Inc. 520 W. Erie St. Suite 400 Chicago, IL. 60654 Support at: proglove.com/support support@proglove.com...
