LCD HDTV with Built-in DVD Player
IMPORTANT SAFETY INSTRUCTIONS ................................................................................ 3
THE REMOTE CONTROL .................................................................................................... 12
FIRST TIME USE ............................................................................................................ 16-17
ON-SCREEN DISPLAY ......................................................................................................... 18
DVD OPERATION ........................................................................................................... 23-30
LIMITED WARRANTY .......................................................................................................... 39
READ THE ENCLOSED INSTRUCTIONS CAREFULLY. KEEP THIS OPERATING GUIDE FOR FUTURE REFERENCE.
Record the model name and serial number of your LCD Television for future reference.
MODEL NAME.
This information is located on the back of the television.
please visit www.dtvtransition.org
Operating Guide for L26D103
SERIAL NO.
Advertisement
Table of Contents
Related Manuals for Hitachi L26D103
Summary of Contents for Hitachi L26D103
- Page 1 NEED MORE INFO ON THE DTV TRANSITION? See page 14 in this Operating Guide and please visit www.dtvtransition.org LCD HDTV with Built-in DVD Player Operating Guide for L26D103 IMPORTANT SAFETY INSTRUCTIONS ... 3 THE REMOTE CONTROL ... 12 FIRST TIME USE ... 16-17 ON-SCREEN DISPLAY ...
- Page 2 - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance with the FCC Rules could void the user’s...
-
Page 3: Important Safety Instructions
Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 4: Declaration Of Conformity
29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. -
Page 5: Child Safety Notice
• Flat Panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and cause injury. HITACHI CARES! • The consumer electronics industry is commited to making home entertainment enjoyable and safe. TUNE INTO SAFETY •... -
Page 6: Safety Precautions
Notes when mounting the LCD TV/DVD on a wall If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV/DVD for advice, and have the equipment professionally installed. Incomplete or improper installation may cause injury to you, and/or damage to the LCD TV/DVD. -
Page 7: Features
Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS. Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed for up to 120 minutes to turn off automatically. -
Page 8: Table Of Contents
Subtitles ...28 Changing angles ...28 Title selection ...28 DVD menu ...28 Setting the language ...28 Setting the aspect ratio of TV screen ...28 Setting on screen display ...29 Setting the picture mode ...29 Night mode ...29 Digital out ...29 Parental control ...30 Temporary disabling of rating level by DVD disc ...30... -
Page 9: Disc
Playable discs Disc type and logo mark DVD Video CD-DA The following discs are also available. • DVD-R/RW discs of DVD video format. • CD-R/RW discs of MP3/WMA/JPEG. Region Number Region number (Regional restriction code) is built-in to the unit and DVD video discs. Region number “1”... -
Page 10: Location Of Controls
Location of controls Front Left side DISC slot To display the menu screen. Press MENU button to display the menu screen. CHANNEL / buttons, VOLUME +/– buttons and INPUT/ENTER button can be used to select the desired setting during the menu screen operations. - Page 11 Location of controls (continued) Rear side PC MONITOR IN jack VAR (VARIABLE) AUDIO OUT jack DIGITAL AUDIO COAXIAL OUT jack RF (ANT) IN jack AC INPUT jack HDMI 1/DVI IN jack COMPONENT IN jacks HDMI 2 IN jack LINE 2 VIDEO IN jack PC/DVI AUDIO IN jack LINE 1 IN jacks (VIDEO/S-VIDEO/AUDIO (L/R)) AUDIO (L/R) jacks...
-
Page 12: Remote Control
Adjust volume of TV MUTE Switch off the sound SLEEP Sleep timer SETUP/ TV mode - Display menu of TV TV MENU DVD mode - Call up initial setup mode DVD MENU Display DVD menu Select channel of TV CH / ▲▼◀▶... -
Page 13: Power Source
NOTE: • Please make sure to insert the cord securely at both the LCD TV/DVD and the wall outlet. • The AC Cord has a grounding-type AC line plug. If the supplied AC cord does not match your AC outlet, contact a qualified electrician, do not defeat the purpose of a grounding plug. -
Page 14: Antenna Connections
Please review this Operating Guide for further information regarding such connections. Hitachi supports the DTV transition and as a member of the DTV Transition Coalition urges consumers to visit these web sites for interactive guides and further detailed information: •... -
Page 15: Cable Tv Connections
Follow the connections shown below. With the switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the “A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to tune scrambled channels. -
Page 16: Tv Operation
To select the video input source To view a signal from another device connected to your LCD TV, such as a VCR player, press INPUT, then press ▲/▼ or corresponding Number buttons (0-7), then press ENTER. You can select TV, Video 1, Video 2, Component, HDMI1, HDMI2, PC or DVD (Built-in) depending on which input jacks you used to connect your devices. -
Page 17: Quick Guide For Menu Operation
VOL + or –. SLEEP To set the TV to turn off after a preset amount of time, press SLEEP on the remote control. The clock will count up 10 minutes for each press of the SLEEP button (Off, 0h 10m, 0h 20m, ..., 2h... -
Page 18: Convenience Functions
Select the language you prefer first, then proceed with the other menu options. See page 20. If the Auto Shut Off feature is On, a station being viewed stops broadcasting and the TV is not operated, the TV will automatically shut itself off after 15 minutes. -
Page 19: Memorizing Channels
Before selecting channels, they must be programmed into the TV’s memory. To use this TV with an antenna, set the Signal Type option to the Air mode. When shipped from the factory, this menu option is in the Cable mode. -
Page 20: Checking The Digital-Signal Strength
Checking the digital-signal strength This TV will allow you to view the digital signal meter for digital channels. Select “Channel”, then press ▶ or ENTER. Press ▲ or ▼ to select “Signal Meter”. Press ▶ or ENTER to check the Digital-signal strength. - Page 21 The downloadable Parental Control rating system is an evolving technology, and availability, content, and format may vary. • You cannot select this feature if the TV is not receiving a digital signal for the current station. To clear the all Parental Control settings Select “Locks”, then press ▶...
-
Page 22: Closed Caption
Closed Captioned signal. • If using an indoor antenna or if TV reception is very poor, the Closed Caption Decoder may not appear or may appear with strange characters or misspelled words. In this case, adjust the antenna for better reception or use an outdoor antenna. -
Page 23: Preparation
Press POWER on the unit or on the remote control to turn on the unit. The POWER indicator will change to green. • Each time you turn the unit ON, the TV/DVD starts from the TV mode. • When using an amplifier, switch on the amplifier. -
Page 24: Special Playback
• If a non-compatible disc is loaded, “Incorrect Disc”, “Region Code Error” or “Parental Error” will appear on the TV screen according to the type of loaded disc. If these appear, check your disc again (see pages 9 and 30). -
Page 25: Setting The Jpeg Interval
JPEG Preview Picture-07 Picture-08 W: 2048 H: 1536 Press ENTER or PLAY. The selected picture appears on the TV screen. Rotating an image You can rotate an image by 90 degrees. Tool kit Press ANGLE during playback of the image. -
Page 26: Repeat Playback (Cd)
Folder-1 Repeat :Off Folder-2 Mode :Off MP3-1 Edit Mode MP3-2 MP3-3 WMA-1 JPEG Preview WMA-2 WMA-3 Press ▲/▼/◀/▶ to select the file you want to add into the program list. Press ENTER. Selected file was marked. Repeat this procedure to select the other files. /MP3-1.MP3 Folder-1 Repeat... -
Page 27: Repeat Playback
• A-B Repeat does not work with an interactive DVD, MP3/WMA/ JPEG-CD. Marking desired scenes The TV/DVD stores the points that you want to watch again. You can resume playback from that scene. Marking the scenes: Press MARKER during playback. -
Page 28: Subtitles
You can select the aspect ratio of the picture. Press SETUP/TV MENU in the stop mode or No Disc. Press ▲ or ▼ to select “Video”, then press ▶ or ENTER. Press ▲ or ▼ to select “TV Screen”, then press ▶ or ENTER. -
Page 29: Setting On Screen Display
On screen display can be switched on or off when you press the any button. Press SETUP/TV MENU in the stop mode or No Disc. Press ▲ or ▼ to select “Video”, then press ▶ or ENTER. Press ▲ or ▼ to select “Display”, then press ▶ or ENTER. -
Page 30: Parental Control
Password and setting: Press SETUP/TV MENU in the stop mode or No Disc. Press ▲ or ▼ to select “Locks”, then press ▶ or ENTER. Press ▲ or ▼ to select “Parental Control”, then press ▶ or ENTER. -
Page 31: Language Code List
Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” (see page 28). Language Name Code Language Name Abkhazian 1112 Fiji Afar 1111 Finnish Afrikaans 1116 French Albanian 2927 Frisian Amharic 1123 Galician Arabic 1128 Georgian Armenian 1835 German Assamese 1129 Greek... -
Page 32: Connections To Other Equipment
Video/Audio cord (not supplied) To connect the LCD TV/DVD to a VCR with an S-Video cord If you connect a VCR with a S-Video cable to the S-VIDEO IN jack on the rear side of the unit, you must also connect the audio cables to the AUDIO IN jacks on the rear side of the unit. - Page 33 • If you connect an external component (cable box, satellite receiver, etc.) to this TV/DVD using an HDMI cable or a DVI to HDMI cable, the image will not display if the output resolution of the component is set to 480i. To receive the picture you must change the output resolution on the external component.
- Page 34 To hear sound when using an external audio amplifier, the volume of both the TV and the amplifier must be set above 0 (zero). For example, if the volume of the TV is set to 0, you will not be able to hear any sound, even if the volume of the amplifier is at its highest level.
-
Page 35: Reception Disturbances
The most common types of television interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast. -
Page 36: Problems And Troubleshooting
Problems and troubleshooting Use the following check list for troubleshooting when you have problems with your TV/DVD. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POWER TV/DVD does not operate. - Page 37 The disc may be dirty. Clean up the disc. • The unit cannot play CD-ROMs, etc. No picture. • TV/DVD selector is not set correctly. • Check the input selector of the amplifier is set properly. No sound. • The unit is in the Special playback mode.
-
Page 38: Specifications
Specifications GENERAL Power supply AC 120V 60Hz Power consumption Operation: 102W Stand by: 0.7W Weight 8.8 kg (19.4 lbs) Dimensions Width: 663 mm (26-1/8 inches) Height: 498 mm (19-5/8 inches) Depth: 214 mm (8-7/16 inches) Operating temperature 5˚C - 40˚C Operating humidity Less than 80% TELEVISION... -
Page 39: Limited Warranty
ORION warrants this product to be free from manufacturing defects in material and workmanship under normal use and conditions for a period of 1 year from date of original purchase in the United States. Should service be necessary under this warranty for any reason due to a manufacturing defect or malfunction during the first 12 months from date of original purchase, ORION will provide carry-in service only by an ORION authorized Independent Service Center at no charge.
