SAFETY GUIDELINES
This monitor is designed to be safe to use. However, due to high voltage of about 400 V,
fire or serious injury may occur unless you use this monitor in correct way.
You are strongly suggested to follow the instruction shown below in order to avoid such
injury.
Warning and Caution are indicated in this guide and monitor itself.
Fire or electric shock may cause death or serious injury unless you
Warning
follow the instruction.
Electric shock or other accidents may cause serious injury or damage
Caution
of your properties.
Keep the safety guideline
Do not use the monitor if it fails
If you find something unusual ,
If smoke comes out,
If there is a strange smell,
If water enters the case,
If you drop the monitor or
damage the cabinet,
Turn off the monitor
Disconnect the power
plug from the power point
Request for repair
i

Advertisement

Table of Contents
loading

Related Manuals for Hitachi CMP402HDU

Summary of Contents for Hitachi CMP402HDU

  • Page 1 SAFETY GUIDELINES This monitor is designed to be safe to use. However, due to high voltage of about 400 V, fire or serious injury may occur unless you use this monitor in correct way. You are strongly suggested to follow the instruction shown below in order to avoid such injury.
  • Page 2 SAFETY GUIDELINES(continued) Fire or electric shock may cause death or serious injury unless you Warning follow the instruction below. If something smells strange or smoke comes from the monitor: Turn off the monitor and disconnect the power plug from the power point immediately. Contact service center after confirming that the smoking has stopped.
  • Page 3 Fire or electric shock may cause death or serious injury unless you Warning follow the instruction. The enclosed power cord must be used! Failure to do so may cause electric shock hazard or fire hazard. In USA/Canada, use a UL LISTED/CSA LABELLED or CERTIFIED power cord set meeting the following specifications : Rating: min.
  • Page 4 SAFETY GUIDELINES(continued) FOR THE CUSTOMERS IN THE U.K. THIS PRODUCT IS SUPPLIED WITH A TWO PIN MAINS PLUG FOR USE IN MAINLAND EUROPE. FOR THE U.K. PLEASE REFER TO THE NOTES ON THIS PAGE. IMPORTANT FOR UNITED KINGDOM WORDING FOR CLASS I EQUIPMENT INSTRUCTION BOOKS AND LABELS The mains lead on this equipment is supplied with a molded plug incorporating a fuse, the value of which is indicated on the pin face of the plug.
  • Page 5 Electric shock or other accidents may cause serious injury or damage to Caution your property. You must to check the user manual of the computer when you connect to the monitor. The weight of the monitor or obstructing the ventilation hole of the computer equipment may cause distortion or damage of the computer equipment.
  • Page 6 SAFETY GUIDELINES(continued) You may have serious injury or your property may be damaged unless Caution you follow the instruction below. Do not bundle the power cord. It will be heated up or it may cause a fire. Caution for 200 - 240V operation only This equipment relies on the protective devices in the building installation for short - circuit and over - current protection.
  • Page 7 This monitor has been designed pursuant to the FCC Rules and so on in order to prevent a problem to TV/Radio receivers. However, this monitor may cause a problem to TV/Radio receivers if you put this monitor close to them.
  • Page 8 Precautions for TV & Radio - Keep the monitor away from TV or Radio. - Adjust TV or radio antennas in order for the monitor not to receive interference. - The antenna cable of TV or Radio should be kept away from the monitor.

  • Page 9: Table Of Contents

    CONTENTS SAFETY GUIDELINES CONTENTS FEATURES INSTALLATION INSTRUCTIONS Standard accessories Installation Anti-tumble measures Component Names Installation and Cabling Handling the Remote Controller OPERATING INSTRUCTIONS Turning Power On and Off Input Selection Volume Adjustment Contrast Adjustment Sound Mute Input Signal Status Display On-Screen Display System, EasyMenu Displays According to Selected DISPLAY AREA (RGB Input) OTHER FEATURES...

  • Page 10: Features

    FEATURES The following features are provided by the color Plasma Display Monitor. Large-screen, high-definition plasma display panel The 42-inch color plasma display panel, with a resolution of 1024 (H) x 1024(V) pixels, creates a high-definition, large-screen (aspect ratio : 16:9) and low-profile flat display. Free from electromagnetic interferences from geomagnetic sources and ambient power lines, the panel produces high-quality display images free from color misconvergence and display distortion.

  • Page 11: Installation Instructions

    VESA DPMS. The ENERGY STAR® emblem does not represent EPA endorsement of any product or service. As an ENERGY STAR® Partner, Hitachi,Ltd. has deter mined that this product meets the ENERGY STAR® guidelines for energy efficiency. Instruction manual...

  • Page 12: Component Names

    INSTALLATION INSTRUCTIONS (continued) Component Names Panel Remote-control sensor Control panel The Adjustment button is located on the bottom. RGB/ MENU SELECT ▽ VOLUME △ VIDEO RGB/ MENU SELECT VOLUME VIDEO Subpower button VOLUME button SELECT button MENU button RGB/VIDEO button Front RGB/ MENU...

  • Page 13: Remote Controller

    External device connection terminals AUDIO IN SPEAKER VIDEO2 TERMINAL Nearer Terminal L/MONO COMPONENT IN (8Ω8W) Further Terminal External speaker Video input terminal terminals POWER button RECALL button MUTE button MENU button Rear VIDEO1 RGB1 COMPOSITE IN RGB2 D-SUB IN VIDEO RGB input terminals Remote controller RGB/VIDEO button...

  • Page 14: Installation And Cabling

    INSTALLATION INSTRUCTIONS (continued) Installation and Cabling Connecting to the PC Read Usage Notes ( these steps: 1) Make sure that the display signals produced by your PC meet the specifications of this product. For the specifications of this product, see Product Specifications ( 2) Choose an appropriate site and install the product on a level table where the stand is secure.

  • Page 15: Connecting To Video Equipment

    Connecting to Video Equipment (such as a video disc player, a DVD player, or a video camera) Read Usage Notes ( ) carefully to ensure maximum safety before proceeding to these steps: 1) Choose an appropriate site and install the product on a level table where the stand is secure. Install the monitor to have ready access to a power socket available.

  • Page 16: Handling The Remote Controller

    INSTALLATION INSTRUCTIONS (continued) Handling the Remote Controller Loading Batteries 1) Open the battery cover. Slide the battery cover towards the arrow mark while pressing it. 2) Load batteries. Load two Size AA batteries included observing the correct polarities. 3) Close the battery cover. Slide back the battery cover towards the arrow mark.

  • Page 17: Operating Instructions

    OPERATING INSTRUCTIONS Turning Power On and Off To turn on the set power supply, set the MAIN POWER switch ( ) of the main unit to ON and then press the SUB POWER button or the POWER button of the remote control. To turn off the set power supply, press the SUB POWER button of the main unit or the POWER button of the remote control, then set the MAIN POWER switch ( ) to OFF.

  • Page 18: Input Selection

    OPERATING INSTRUCTIONS (continued) Input Selection Press the RGB/VIDEO button on the remote controller or the unit to switch the input in the sequence of RGB1 -> RGB2 -> VIDEO1 -> VIDEO2 -> RGB1. When the same signal is input to RGB1 and RGB2, the phase may in some cases shift slightly but this is not a malfunction.

  • Page 19: Contrast Adjustment

    Contrast Adjustment While the on-screen display system, EasyMenu controller SELECT button When you press these buttons, the status of contrast adjustment and the input horizontal (H) and vertical (V) frequencies of the input signal will be displayed in a guidance image. While the guidance is on display, press the narrow the difference between darkness and brightness.

  • Page 20: On-Screen Display System, Easymenu

    OPERATING INSTRUCTIONS (continued) On-Screen Display System, EasyMenu Press the MENU button to open an adjustment menu allowing you to complete various adjustments and settings using the SELECT buttons (The remote control or the SELECT or VOLUME button of the main unit.). Press the SELECT button of the main unit ( key of the remote control) to select an item by moving the pink text.
  • Page 21 Adjustment Item List Selected Menu item Adjustment item characters CONTRAST Contrast PICTURE if RGB is selected BRIGHTNESS Brightness COLOR SELECT Color temperature OPTIONS GAMMA Gamma correction VIDEO LEVEL Input signal level CONTRAST Contrast BRIGHTNESS Brightness PICTURE if VIDEO is COLOR Color (color density) selected TINT...
  • Page 22 OPERATING INSTRUCTIONS (continued) Adjustment Item List (continued) Selected Menu item Adjustment item characters Display DISPLAY AREA area H.POSITION Horizontal position V.POSITION DISPLAY CLOCK Dot clock frequency if RGB is selected PHASE SCAN ( * ) DISPLAY INITIALIZE Display initialization INIT. DISPLAY SIZE DISPLAY if VIDEO is...
  • Page 23 Adjustment Item List (continued) Selected Menu item Adjustment item characters LANGUAGE Language selection Input status automatic AUTO FREQ. FUNCTION if RGB is selected INTERPOLATION Enlargement LANGUAGE Language selection FUNCTION if VIDEO is Input status automatic AUTO FREQ. selected LINE INTP. Line correction Three-dimensional 3D COMB...

  • Page 24: Displays According To Selected Display Area (Rgb Input)

    OPERATING INSTRUCTIONS (continued) Displays According to Selected DISPLAY AREA (RGB Input) Resolution Overall display FULL (640 480) FULL SVGA (800 600) FULL (1024 768) FULL SXGA (1280 1024) Only FULL display is possible with SXGA (1280 x 1024) - 75Hz. Overall display (FULL) fills the display area with data;...

  • Page 25: Other Features

    OTHER FEATURES Automatic Store Approximately 1 sec. after adjustment is completed, the adjustments will be recorded as shown in the table below. Item Sound volume VOLUME Sound balance BALANCE Treble TREBLE Bass BASS Mute volume MUTE LEVEL Input status automatic display AUTO FREQ.

  • Page 26: Reset (Settings Initialization)

    OTHERFEATURES (continued) Reset (Settings Initialization) The EasyMenu shown to the right will be displayed when the SELECT button is used to select DISPLAY and moreover DISPLAY INT is selected from the On-screen Display System Easy Menu . If the SELECT button is pressed at this time, the user adjustment values in the table below for the signal currently being received will be deleted and the factory settings will be restored.

  • Page 27: Displays By Selecting The Display Sizes (Video Input)

    Using a wide-screen monitor This monitor has a screen mode selection feature. If an incompatible screen mode is selected to play certain software, such as a TV program, the image would appear different from the original. Take this into consideration when making screen mode choices.

  • Page 28: Power Save Mode

    OTHERFEATURES (continued) Power Save Mode When the RGB input jack is selected This unit meets the power-saving requirements of VESA and International Energy Program. When this unit is connected to a VESA DPMS computer, the Power Save (Standby/Suspend/Off) mode can be set to be activated automatically when the computer is not being used to reduce power consumption by this unit.

  • Page 29: Troubleshooting

    TROUBLESHOOTING Symptoms That Seemingly Appear to be Failures Make the checks suggested below depending on the symptoms observed. If the symptoms remain uncorrected, contact your dealer. WARNING Customer servicing can be hazardous. Symptom The screen appears blank with the power-indicating lamp off.
  • Page 30 TROUBLESHOOTING (continued) Symptom Flicker causes stripes to move up and down (during personal computer signal input). The temperature of the display panel surface is high. There are locations on the screen that are different from the periphery (*). *Points that do not light, points with brightness different from that of the periphery, points with color different from that of the periphery, etc.

  • Page 31: Actions To Correct Abnormal Displays

    Actions to Correct Abnormal Displays Depending on the kind of system equipment used, images may not be displayed normally. In this case, make the adjustments suggested below. Text displayed across the screen appears vertically streaked, with some characters blurred (display 1). Symptom 1 The display image appears flowing (display 2) (RGB input).
  • Page 32 TROUBLESHOOTING (continued) Text displayed across the screen appears blurred in its entirety (display 2). Symptom 2 A fine pattern flickers when displayed on the screen (display 3). Display 2 ABCDEFGHIJ abcdefgABCDEFGabcd ABCDEFGHIJ abcdefgABCDEFGabcd Example 1) Press MENU button to open the adjustment menu. 2) Press SELECT button 3) Press to open the DISPLAY menu.

  • Page 33: Product Specifications

    20% to 80%, Storage : 20% to 90% (non-condensing) humidity The monitor takes at least 30 minutes to attain the status of optimal picture quality. CMP402HDU RGB input Video 1 video input terminal Video 1 audio input terminal (left, right)

  • Page 34: Signal Input

    PRODUCT SPCIFICATIONS (continued) Signal Input RGB terminal (D-sub 15-pin connector) Input signal R. video G. video or sync on green B. video No connection No connection R.GND G.GND B.GND No connection No connection No connection H. sync or H/V composite sync V.sync.

  • Page 35: Recommended Signal List

    Recommended Signal List The following are recommended for use with this projector (RGB input): Signal mode Resolution Signal name Vertical frequency (Hz) 640 400 640 480 640 480 640 480 800 600 800 600 800 600 VESA 800 600 1024 768 1024 768 1024 768 1280 1024...
