A/V DOLBY DIGITAL RECEIVER
SERVICE MANUAL
ESD WARNING.....................................2
LEAKAGE TESTING................................3
BASIC SPECIFICATIONS........................4
DETAILED SPECIFICATIONS..................5
FRONT PANEL CONTROLS..................13
REAR PANEL CONNECTIONS...............15
IDLE CURRENT ADJUST.....................23
TUNER ALIGNMENT...........................24
All manuals and user guides at all-guides.com
AVR7000
PRELIMINARY
CONTENTS
harman/kardon, Inc.
250 Crossways Park Dr.
Woodbury, New York 11797
TROUBLESHOOTING GUIDE................27
UNIT EXPLODED VIEW.......................28
EXPLODED VIEW...............................29
BLOCK DIAGRAM..............................30
PCB DRAWINGS................................31
MECHANICAL PARTS LIST..................47
ELECTRICAL PARTS LIST...................67
SCHEMATICS....................................70
WIRING DIAGRAM..............................94
PACKAGE.........................................95
Rev1 - 11/2000

Advertisement

loading

Related Manuals for Harman Kardon AVR7000

Summary of Contents for Harman Kardon AVR7000

  • Page 1: Table Of Contents

    All manuals and user guides at all-guides.com harman/kardon AVR7000 A/V DOLBY DIGITAL RECEIVER PRELIMINARY SERVICE MANUAL CONTENTS ESD WARNING…………………..….……….2 TROUBLESHOOTING GUIDE…...…….…27 LEAKAGE TESTING………………...….…..3 UNIT EXPLODED VIEW…………………..28 BASIC SPECIFICATIONS……………….…..4 EXPLODED VIEW………………………….29 DETAILED SPECIFICATIONS………….…..5 BLOCK DIAGRAM…………………………30 FRONT PANEL CONTROLS………….…..13 PCB DRAWINGS……………………..……31 REAR PANEL CONNECTIONS……..….…15 MECHANICAL PARTS LIST………………47...
  • Page 2 All manuals and user guides at all-guides.com Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field effect transistors and semiconductor "chip"...
  • Page 3 All manuals and user guides at all-guides.com Before returning the unit to the user, perform the following safety checks : 1. Inspect all lead dress to make certain that leads are not pinched or that hardware is not lodged between the chassis and other metal parts in the unit.
  • Page 4 Height measurement includes feet and chassis. All features and specifications are subject to change without notice. Harman Kardon is a registered trademark, and Power for the digital revolution is a trademark, of Harman International Industries, Inc. *Manufactured under license from Dolby Laboratories.
  • Page 5 DETAILED SPECIFICATION FOR RECEIVER AVR7000 (120V) All manuals and user guides at all-guides.com PARAMETERS Measuring methods are based on IHF and IEC standard 268-3 Measurement conditions,unless otherwise noted : Output resistive load = (8) ohms / All channels loaded. Tone Off or Tone(Bass,Treble), Balance, EQ control : Center Position , Other SW's : OFF, Volume:Max Nominal input level : 200mV for general purpose inputs Power figures should be kept minimum 10min., between 15 and 35...
  • Page 6 All manuals and user guides at all-guides.com at 0.1% THD, 10 Hz-80 KHz 20 KHz >110 >115 measurement BW.Volume at Max. CONTINUOUS AVERAGE at 0.1% THD, 10 Hz-80 KHz POWER: B) All 5 6 CH DIRECT 20 Hz >100 >105 measurement BW.Volume at Max.
  • Page 7 All manuals and user guides at all-guides.com Volume at Max. Apply Sinewave Signal Gen amplitude to the tested All Analog input, to obtain R/O-3dB at the speaker Stereo and 6 CH 10 kHz outputs. Record the FL and FR speaker >...
  • Page 8 All manuals and user guides at all-guides.com S/N RATIO VCR1(1Vp-p) 1MHz COMPONENT VIDEO OUTPUT LEVEL at 75ohms "Y" LEVEL(GREEN) VCR1(1Vp-p) 1 +/- 20mV 1 +/- 10mV "Cb" LEVE(BLUE) VCR1(0.678Vp-p) Vp-p 0.678+/-10mV 0.678+/-5mV "Cr" LEVE(RED) VCR1(0.678Vp-p) 0.678+/-10mV 0.678+/-5mV...
  • Page 9 All manuals and user guides at all-guides.com TUNER SECTION Measuring methods in confirmity with IEC standard 315 Measurements condition FM : Radio frequency = 98.1MHz, Audio frequency = 1kHz Reference level = 1mV on ( 75ohms , 300ohms ) Deviation : MONO = ?5kHz, Stereo = ?7.5kHz?.5kHz MONO = ?0kHz, Stereo = ?0kHz?.5kHz Test Point : TP 1 = 90.1MHz, TP 2 = 98.1MHz, TP 3 = 106.1MHz...
  • Page 10 All manuals and user guides at all-guides.com S/N RATIO > 40 > 45 INPUT=10mV/m TOTAL HARMONIC DISTORTION > 1.5 > 0.8 OVER LOAD DISTORTION 5mV 80% MOD > 10 > 5 FREQUENCY RESPONSE at -6dB 100~2K 80~2.3K SELECTIVITY 10kHz/9kHz > 20 >...
  • Page 11 All manuals and user guides at all-guides.com DIGITAL(AC3) Section AC-3 SECTION Measurements conditions,unless otherwise noted : Input Function : DVD Digital Input Mode : OPTICAL1 Speker Mode : Front/Center/Surround:LARGE, Sub-Woofer:YES Main Vol Position : 1 Vrms Output Position Trim Vol Position : All "0 dB" Test Point : Pre-Out Test disc : DOLBY TEST DVD VERSION 1.0 Center, Rear delay : 0 ms...
  • Page 12 All manuals and user guides at all-guides.com DIGITAL(AC3) Section L/C/R/Ls/Rs/LFE - Main Vol level 30Hz 15 < +/- 2 15 < +/- 1 >Sub Out C/Ls/Rs/LFE -> "60" Position 30Hz -6.5 < +/- 3 -6.5 < +/- 2 L, R :Sub: No Main Vol Level : * 12...

  • Page 13: Front Panel Controls

    All manuals and user guides at all-guides.com Front Panel Controls Ò Ó ˆ ı Ù Û Ú Ô & @ # $ % 1 Main Power Switch ! Input Source Selector Ô Delay 2 System Power Control @ FM Mode Selector Digital Input Selector 3 Power Indicator # Bass Control...
  • Page 14 All manuals and user guides at all-guides.com Front Panel Controls 7 Surround Mode Selector: Press this but- In normal use, they are an input that may be Digital Input Selector: When playing a selected by pressing the Input Source ton to change the surround mode by scrolling source that has a digital output, press this Selector ! on the front panel, or the Video button to select between the Optical ·...

  • Page 15: Rear Panel Connections

    All manuals and user guides at all-guides.com Rear Panel Connections · ° ‡ fl fi › ¡ ™ £ ¢ ∞ § ¶ • ª ‚ ⁄ ¤ ‹ ¡ AM Antenna ⁄ Amplifier Inputs b Multiroom IR Input ™ FM Antenna ¤...
  • Page 16 IR sensor in the receiver to serve other information on speaker polarity.) remote controlled devices. Connect this jack to the “IR IN” jack on Harman Kardon or other ‚ Tape Outputs: Connect these jacks to the compatible equipment.

  • Page 17: Remote Control Functions

    All manuals and user guides at all-guides.com Main Remote Control Functions a Program Indicator b AVR Selector c CD/Tape/DVD Input Selectors d Power Off Button e Test Tone f Mute Buttons ⁄ ¤ h Channel Select Button harman kardon i Set Button Button ‹...
  • Page 18 AVR 7000 and most Harman Kardon CD or DVD step increments. When the FM band is in use, process. (See page 34 for more information on players and cassette decks.
  • Page 19 All manuals and user guides at all-guides.com Main Remote Control Functions w Preset Up/Down: When the tuner is Delay/Prev Ch.: Press this button to Volume Up/Down: Press these buttons to in use, press these buttons to scroll through the begin the process for setting the delay times raise or lower the system volume.
  • Page 20 Models: AVR7000 Subject: Video Signal, Color Shift In the event you receive an AVR7000 receiver with the complaint “when the video signal is routed through my AVR7000, there is a noticeable color shift with certain program material”, perform the following modification: 1.
  • Page 21 3) Replace the top cover. 4) Test the Switched AC Accessory Outlets by connecting a low power device, such as a CD player, DVD player, or Tape Deck and assure the unit powers up normally when the AVR7000 System Power Control is switched on.

  • Page 22: Service Bulletins/Tech Tips

    For models: AVR7000 TIP# HKTT2000-01 Complaint: The Remote Control has stopped working for the AVR7000. First Check: 1. Make sure the batteries in the remote are installed correctly. (Plus and minus to correct terminals) 2. Make sure the area between the remote control and receiver is not blocked by some object, and the distance is no more than 15 feet at an angle no greater than 30 degrees from the front of the receiver.
  • Page 23 All manuals and user guides at all-guides.com AVR7000 IDLE CURRENT ADJUSTMENT 1) 2-CH AMP and 3-CH AMP sections should be adjusted when they are intact on the Heat-sink 2) Initial warm-up and test condition: 1Khz - Signal input, SPKR-OUT(8ohm load), 5CH All driven...

  • Page 24: Tuner Alignment

    All manuals and user guides at all-guides.com AVR700 TUNER ALIGNMENT • Europe Mono 40kHz Stereo 67.5kH 1.Electrical specificat • America Mono 75kHz Stereo 40kHz SPECIFICATION ITEMS Above the receiving Frequency Local OSC •522 ~ 1620kHz •87.5 ~ 108.0MHz Frequency cover r •520 ~ 1720kHz •87.5 ~ 107.9MHz 15.0 (+/-1.5V)
  • Page 25 All manuals and user guides at all-guides.com AVR700 TUNER ALIGNMENT (con't) Europe Mono 40kHz Stereo 67.5kHz Pilot 7 1.Electrical speci America Mono 75kHz Stereo 40kHz Pilot 7.5k SPECIFICATION ITEMS Local OSC Above the receiving Frequency •522 ~ 1620kHz •87.5 ~ 108.0MHz Frequency cover ra •520 ~ 1720kHz •87.5 ~ 107.9MHz...
  • Page 26 All manuals and user guides at all-guides.com AVR700 TUNER ALIGNMENT (con't) 3.Adjustment Points...

  • Page 27: Troubleshooting Guide

    Light around power switch is red due to possible short speaker ends • Amplifier is in protection mode • Contact your local Harman Kardon service depot due to internal problems No sound from surround or • Incorrect surround mode • Select a mode other than Stereo center speakers •...
  • Page 28 All manuals and user guides at all-guides.com      ...
  • Page 29 All manuals and user guides at all-guides.com...
  • Page 30 All manuals and user guides at all-guides.com...
  • Page 31 All manuals and user guides at all-guides.com...
  • Page 32 All manuals and user guides at all-guides.com...
  • Page 33 All manuals and user guides at all-guides.com...
  • Page 34 All manuals and user guides at all-guides.com...
  • Page 35 All manuals and user guides at all-guides.com...
  • Page 36 All manuals and user guides at all-guides.com...
  • Page 37 All manuals and user guides at all-guides.com...
  • Page 38 All manuals and user guides at all-guides.com...
  • Page 39 All manuals and user guides at all-guides.com...
  • Page 40 All manuals and user guides at all-guides.com...
  • Page 41 All manuals and user guides at all-guides.com...
  • Page 42 All manuals and user guides at all-guides.com...
  • Page 43 All manuals and user guides at all-guides.com...
  • Page 44 All manuals and user guides at all-guides.com...
  • Page 45 All manuals and user guides at all-guides.com...
  • Page 46 All manuals and user guides at all-guides.com...
  • Page 47 All manuals and user guides at all-guides.com AVR7000 MECHANICAL PARTS LIST J5541001020X WASHER FLAT J2822110014X*POWER TRANS 120/60 J2822410014X*POWER TRANS 230/50 JE99005307EA MNBD ASM 7000RDS J43730100200*CORD AC POWER JE99005307UA MNBD ASM AVR7000 J43731100200*CORD AC POWER RDS JE99005507EA FRBD ASM 7000RDS J43732100200*CORD AC POWER SG...
