MSP-070C Battery Maintainer

Product Specifications

Operating Parameters
Input Voltage
110V – 240V~, 50 – 60 Hz, 12A max.
Output 1 14.4VDC max., 70A max.
Charge Cables
•
2m (Standard)
• 3m
•
5m
Power Cord
Accepts locking C13 connector for region-specific power
cables:
•
United States: EMA 5-15 termination, rated at 15A/125V
UL CSA
Applications
•
Automotive
• Heavy-Duty
• Power Sports
Battery Chemistries
•
Lead acid
• AGM
CCA Range
•
100 – 2000 CCA
Dimensions
(without handle or base)
• Height: 4.80 in (12.19 cm)
•
Width: 13.1 in (33.27 cm)
•
Length: 12.0 in (30.48 cm)
•
Weight:18 lbs
Safety
•
UL1236, IEC 60335
EMC
•
EN61000-6-4 (Emissions) CISPR 11 Class A
• EN61000-6-2 (Immunity)
•
EN61000-3-2 (Harmonics)
•
EN61000-3-3 (Flicker)
•
CEC, California Energy Commission
•
Group 31
• Commercial 4D/8D
•
EFB
Protection Features
•
Reverse polarity
•
Non-12V battery
connection
•
Clamp connection

Error Codes

Error codes are transmitted via the red LED on the side of the
charger. The number of flashes correspond with the error code
number (Example: Two [2] flashes = Error Code 02)
Code Description
01 Reverse polarity
02 Connection problem
03 Non 12V battery
connected
04 Battery voltage too
low (<5.5V)
08 Internal current failure
09 Internal voltage failure
10 Internal temperature
too high
11 Cable temperature
sensor open
12 Cable temperature
sensor short
13 Charge cable (Vab)
14 Sensing cable (Vcd)
15 Battery temperature
exceeds thermal limit
16 Battery temperature
below thermal limit
20 Unit internal error
7
Shop for other automotive tools on our website.
Connections & Controls
•
Battery voltage too low
(<5.5V)
•
Clamp high temperature
detection
Action
Correct clamp connections to
battery
(Red to + / Black to –)
Correct connections & restart
charge sequence
Connect to 12V
Battery deeply discharged or may
be damaged. consider replacing
battery
Switch unit off then on again. If fan
is not running call for service.
Switch unit off then on again. If fan
is not running call for service.
Switch unit off then on again. If fan
is not running call for service.
Replace charge cable:
SO, (Tsensor = open)
Replace charge cable:
SS, (Tsensor = short)
Replace clamp or charge cable
Replace clamp or charge cable
Battery replacement recommended,
unsafe to charge
Frozen battery, may not recover
Call for service
