Christie Vive Audio BKT-LA3 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Christie Vive Audio BKT-LA3
Bracket
U s e r M a n u a l
020-101251-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vive Audio BKT-LA3 and is the answer not in the manual?

Questions and answers

Related Manuals for Christie Vive Audio BKT-LA3

Summary of Contents for Christie Vive Audio BKT-LA3

  • Page 1 Christie Vive Audio BKT-LA3 Bracket U s e r M a n u a l 020-101251-02...
  • Page 2 The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the required international warranty fee has been paid.

  • Page 3: Table Of Contents

    Accessories ........... 12 Christie Vive Audio BKT-LA3 Bracket User Manual...

  • Page 4: Safety Information

    • Two people are required to safely lift and install the bracket. • Only use attachments or accessories specified by Christie. • Changes or modifications to the product not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 5: Introduction

    M6 35 mm button head bolt M6 lock washer M10 60 mm button head bolt M10 star washer M10 45 mm button head bolt M10 hex nut Rubber end cup Christie Vive Audio BKT-LA3 Bracket User Manual 020-101251-02 Rev. 1 (01-2017)

  • Page 6: Installation

    1. Place the LA3 speaker on its left side on a flat, stable surface free of debris. 2. Remove the center and bottom bolts from the right side of the LA3 speaker. Christie Vive Audio BKT-LA3 Bracket User Manual 020-101251-02 Rev. 1 (01-2017)

  • Page 7: Attach The Bracket Assemblies To The La3 Speaker

    4. Align the 0° mark on the pivot brace with the hole on the bottom of the speaker. 5. Secure the bracket in position with one M6 lock washer and one M6 35 mm button head bolt to the torque of 2.0 N*m (18 in*lbf). Christie Vive Audio BKT-LA3 Bracket User Manual 020-101251-02 Rev. 1 (01-2017)

  • Page 8: Install The Cross Strap Plates

    2. Install the cross strap plate with one M10 45 mm button head bolt, one M10 star washer, and one M10 hex nut in each of the two holes. Do not fully torque the bolts, you will secure them in a later step. Christie Vive Audio BKT-LA3 Bracket User Manual 020-101251-02 Rev. 1 (01-2017)

  • Page 9: Secure The La3 Speaker To The S215 Subwoofer

    3. Remove the six pre-installed M10 x 60 mm button head bolts from the top of the S215 subwoofer. 4. Place the LA3 and bracket assembly on its back, with the bracket feet position over the six bolt holes on the top of the S115 subwoofer. Christie Vive Audio BKT-LA3 Bracket User Manual 020-101251-02 Rev. 1 (01-2017)
  • Page 10 8. Move the assembly to its final position on the platform. 9. Place a rubber end cup over the end of each square frame tube. Christie Vive Audio BKT-LA3 Bracket User Manual 020-101251-02 Rev. 1 (01-2017)
  • Page 11 10. Aim the S215 subwoofer and LA3 speaker using a laser distance measurement tool. 11. Secure the S215 subwoofer to the platform with BKS-SUB brackets. See the BKS-SUB Bracket User Manual for installation instructions. Christie Vive Audio BKT-LA3 Bracket User Manual 020-101251-02 Rev. 1 (01-2017)

  • Page 12: Specifications

    Christie Vive Audio LA3 speaker 145-102104-XX Christie Vive Audio LA3 speaker with grill 145-125109-XX Christie Vive Audio S215 subwoofer 145-103105-XX Christie Vive Audio S215 subwoofer with grill 145-127101-XX BKS-SUB bracket 145-110103-XX Christie Vive Audio BKT-LA3 Bracket User Manual 020-101251-02 Rev. 1 (01-2017)
  • Page 13 Corporate offi ces Worldwide offi ces USA – Cypress Australia Eastern Europe and India Singapore ph: 714-236-8610 ph: +61 (0) 7 3624 4888 Russian Federation ph: +91 (080) 6708 9999 ph: +65 6877-8737 ph: +36 (0) 1 47 48 100 Canada –...
