Summary of Contents for Christie Vive Audio BKT-LA4
- Page 1 Christie Vive Audio BKT-LA4 Bracket U s e r M a n u a l 020-101284-02...
- Page 2 The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the required international warranty fee has been paid.
-
Page 3: Table Of Contents
Accessories ........... 12 Christie Vive Audio BKT-LA4 Bracket User Manual... -
Page 4: Safety Information
• Two people are required to safely lift and install the bracket. • Only use attachments or accessories specified by Christie. • Changes or modifications to the product not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 5: Introduction
M6 lock washer M10 60 mm button head bolt M10 star washer M10 45 mm button head bolt M10 hex nut Left base bracket Right base bracket Rubber end cup Christie Vive Audio BKT-LA4 Bracket User Manual 020-101284-02 Rev. 1 (01-2017) -
Page 6: Installation
1. Place the LA4 speaker on its left side on a flat, stable surface free of debris. 2. Remove the center and bottom bolts from the right side of the LA4 speaker. Christie Vive Audio BKT-LA4 Bracket User Manual 020-101284-02 Rev. 1 (01-2017) -
Page 7: Attach The Bracket Assemblies To The La4 Speaker
4. Align the 0° mark on the pivot brace with the hole on the bottom of the speaker. 5. Secure the bracket in position with one M6 lock washer and one M6 35 mm button head bolt to the torque of 2.0 N*m (18 in*lbf). Christie Vive Audio BKT-LA4 Bracket User Manual 020-101284-02 Rev. 1 (01-2017) -
Page 8: Install The Cross Strap Plates
2. Install the cross strap plate with one M10 45 mm button head bolt, one M10 star washer, and one M10 hex nut in each of the two holes. Do not fully torque the bolts, you will secure them in a later step. Christie Vive Audio BKT-LA4 Bracket User Manual 020-101284-02 Rev. 1 (01-2017) -
Page 9: Secure The La4 Speaker To The S215 Subwoofer
2. Remove the six pre-installed M10 x 60 mm button head bolts from the top of the S215 subwoofer. 3. Align the left and right base brackets over the left and right bolt holes in the top of the S215 subwoofer. Christie Vive Audio BKT-LA4 Bracket User Manual 020-101284-02 Rev. 1 (01-2017) - Page 10 7. Install one M10 x 60 mm button head bolt into each of the six bracket foot holes. Do not fully torque any of the six bolts until they are aligned and correctly engaged. Christie Vive Audio BKT-LA4 Bracket User Manual 020-101284-02 Rev. 1 (01-2017)
- Page 11 11. Aim the S215 subwoofer and LA4 speaker using a laser distance measurement tool. 12. Secure the S215 subwoofer to the platform with BKS-SUB brackets. See the BKS-SUB Bracket User Manual for installation instructions. Christie Vive Audio BKT-LA4 Bracket User Manual 020-101284-02 Rev. 1 (01-2017)
-
Page 12: Specifications
Christie Vive Audio LA4 speaker 145-102104-XX Christie Vive Audio LA4 speaker with grill 145-121105-XX Christie Vive Audio S215 subwoofer 145-103105-XX Christie Vive Audio S215 subwoofer with grill 145-127101-XX BKS-SUB bracket 145-110103-XX Christie Vive Audio BKT-LA4 Bracket User Manual 020-101284-02 Rev. 1 (01-2017) - Page 13 Corporate offi ces Worldwide offi ces USA – Cypress Australia Eastern Europe and India Singapore ph: 714-236-8610 ph: +61 (0) 7 3624 4888 Russian Federation ph: +91 (080) 6708 9999 ph: +65 6877-8737 ph: +36 (0) 1 47 48 100 Canada –...
