- Page 2 Step 1 Assemble motor_end Motor Motor_end Put six M3*14mm inner hexagon screws and M3 cushion rings into the Motor_end , lock with M3 nuts but do not tighten ,as picture. Put the motor on the motor_end , locking with four M3*10mm and M3 cushion rings.
- Page 3 Step 2 Assemble idler_end Ball bearing M5 small Put fouaaaaar M3*14mm inner cushion ring*3 hexagon screws and M3 cushion M5*25mm inner rings into the idler_end , lock hexagon screw with M3 nuts but do not tighten ,as picture. M5 cushion ring*2 ...
- Page 4 Step 3 Assemble Cooling fan 1 Assemble the Cooling fan and the Fan_mount 1 Fan_mount 1 together, locking with 2pcs M3*14mm inner hexagon screw and M3 nuts. M3 nut*2 M3*14mm Inner hexagon screw*2 The fan wire is out of this side Cooling fan...
- Page 5 Step 4 Assemble Cooling fan 2 Assemble the Cooling fan and the Fan_mount 2 Cooling fan together, locking with 2pcs M3*14mm inner hexagon screw and M3 nuts. M3*14mm Inner hexagon screw*2 M3 nut*2 Fan_mount 2 The fan wire is out of this side...
- Page 6 Step 5 Assemble Extruder_Mount M3*14mm inner hexagon screws *3 Insert Extruder into Extruder_Mount Assemble Extruder_Buckle with the extruder as picture , locking with 3ps M3*14mm inner hexagon screws Extruder_Buckle and 3pcs nuts. Extruder_Mount The fan wire is out of this side M3 nuts Extruder...
- Page 7 Step 6 Assemble Fan mounts M3*14mm inner hexagon screw Put Fan_mount 1 and Fan_mount 2 to the Extruder_mount as picture, locking with 1pcs M3*14mm inner screw each Fan_mount 2 Fan_mount 1 Extruder_mount...
- Page 8 Step 7 Assemble Aluminum plate Firstly install Copper pillar on the Acrylic board , locking with 3pcs M3*10mm Aluminum plate Flat_head screws from bottom to up, as picture. Through Aluminum plate and Pressure Acrylic board spring which used M3*14mm flat_head screws ,locking to the copper pillar.
- Page 9 Step 8 Assemble Base plate Base plate Put 3pcs Motor_ends under the Base plate, Locking with M4*30mm inner hexagon screws and M4 cushion rings Put LCD display to the Base M4 cushion ring Control board plate , locking with 2pcs assembly M3*16mm Round head cross screws and M3 nuts...
- Page 10 Step 9 Assemble Carbon fibre hollow tubes Lock one end of the Carbon fibre hollow tube to the Carriage with 1pcs M3*25mm inner hexagon screws and 2pcs M3 nuts as picture. The other two carriage are the same assembly Carriage M3 nuts Carbon fibre...
- Page 11 Step 10 Connect Extruder & Carriage Lock the other end of the Carbon fibre hollow tube to the Extruder with 1pcs M3*25mm screws and 2pcs M3 nuts as picture. Others end are the same assembly. M3 nut Carriage Magnified M3 nut M3*25mm inner Extruder...
- Page 12 Ensure the same Step 11 Insert the Sliding Rods. height of each sliding Insert the 6pcs Sliding rods to the Motor_end, ensure the same height of each sliding rods. Then locking the Carriage 18pcs M3*14mm screws. Through the Carriage to each sliding rod, attention the cooling fan 1 is on the right side.
- Page 13 Step 12 Assemble Top Plate Install the 3pcs Idler_ends to the Top plate as picture, locking with 2pcs M4*30mm inner hexagon screws and M4 cushion rings Top plate Put Feeder on the Top plate ,locking with 2pcs M3*14mm hexagon screws from bottom.
- Page 14 Top plate Step 13 Install Top plate Insert the Sliding rod to the Idler_end hole one by one. Feeder Locking the M3*14mm screws on the idler_end. M3*14mm inner hexagon screws Idler_end...
- Page 15 Step 14 Install Timing belt Put one end of the Timing belt into the Bearing Carriage tooth. Another end through motor_end and Carriage idler_end , tense the belt and then insert to the carriage tooth. Timing belt synchronizing wheel...
- Page 16 Step 15 Connect the Cables Connect the DC power cable and On_off switch as picture . On_off switch DC power jack...
- Page 17 Attention the Flat cable ,the red wire is on the top...
- Page 18 Step 16 Assemble Filament Feeder Separately put two Steel Pipe holder on Filament spool Steel Pipe two Filament support frame, locking with holder four M3*20mm Round head screws. Connect the two Filament support frames with two Fixed links , locking with four M3*20mm Round head screws &...
- Page 19 Step 17 Install Filament holder Put the Filament holder on the top of the machine, as picture.
