Summary of Contents for TECHTRAIL Trailhead
- Page 2 INTRODUCTION Congratulations on your purchase of ENDURO SERIES OUTDOOR INSTRUMENT. These products represent the state-of-the-art in recreational instruments. Please keep in mind, your unit is a sensitive technical instrument. With proper care and maintenance, it will last for many years. However, improper care and handling can cause the various sensors to be damaged and to stop functioning.
-
Page 3: Table Of Contents
TABLE OF CONTENTS HOW TO USE THIS MANUAL CARE & MAINTENANCE REPLACING THE BATTERY RESETTING THE INSTRUMENT DISPLAY SYMBOLS AND THEIR MEANINGS KEYS AND THEIR FUNCTIONS MODES OF OPERATION SETTING THE INSTRUMENT FUNCTIONS EL/BACKLIGHT SYSTEM VIEW TIME ZONE 1 / TIME ZONE 2 SETTING TIME/DATE SETTING THE CHRONOGRAPH SETTING THE TIMERS... -
Page 4: How To Use This Manual
HOW TO USE THIS MANUAL Enduro instruments have many unique features and functions. Be sure to read each section carefully so that you will fully understand how the units and its features work. The manual is divided into sections outlining each of the major functions of the instrument. -
Page 5: Replacing The Battery
REPLACING THE BATTERY The Enduro instruments use a common CR2032 3v Lithium battery. Normal battery life is approximately 1yr. NOTE: Heavy usage of the Compass or Backlight system may significantly reduce battery life. NOTE: A blank display or inaccurate compass readings are indications that the battery is getting weak and should be replaced. -
Page 6: Display Symbols And Their Meanings
DISPLAY SYMBOLS AND THEIR MEANINGS DISPLAY SYMBOLS symbol description what it means Auto-El Backlight is active when displayed "AUTO-EL" BACKLIGHT Chronograph is active when displayed CHRONOGRAPH Timer is active when displayed TIMER Hourly chime is active when displayed HOURLY CHIME Alarm is active when displayed ALARM ON Compass is active when displayed... -
Page 7: Keys And Their Functions
KEYS AND THEIR FUNCTIONS The Enduro has 5 individual keys. Each key has several functions. The drawing identifies the keys and their names as used in this manual. SET/CLEAR KEY MODE KEY EL/LIGHT KEY KEYS AND THEIR FUNCTIONS MODE KEY - Advances display through the various operational modes - Selects variable in setting mode... -
Page 8: Modes Of Operation
MODES OF OPERATION ENDURO MAIN DISPLAY MODES Advance through the modes below using QUICK PRESSES TIME CHRONOGRAPH COMPASS ALARM SETTING THE INSTRUMENT FUNCTIONS EL/BACKLIGHT SYSTEM of the MODE key. Activate the BACKLIGHT system at any time by EL/LIGHT of 2 seconds. AUTO EL/BACKLIGHT Auto-EL mode automatically illuminates the backlight for 2 seconds whenever any key is pressed. -
Page 9: View Time Zone 1 / Time Zone 2
SETTING THE INSTRUMENT FUNCTIONS VIEW TIME ZONE 1 / TIME ZONE 2 Your Enduro instrument allows you to set two separate time zones. In TIME MODE, Time Zone 2 can be viewed by a PRESSING START/LAP key. When viewing Time Zone 2, the display will indicate T2 in the upper left of the display. -
Page 10: Setting The Chronograph
SETTING THE INSTRUMENT FUNCTIONS SETTING TIME/DATE CONTINUED Advance to set MONTH by PRESSING Adjust by PRESSING START/LAP STOP/NEXT keys. Advance to set DAY by PRESSING MODE Adjust by PRESSING START/LAP STOP/NEXT keys. Advance to select 12 OR 24-HOUR mode. Select by PRESSING START/LAP STOP/NEXT... -
Page 11: Setting The Timers
SETTING THE INSTRUMENT FUNCTIONS SETTING THE TIMERS Enduro watches are equipped with 3 independent 24-hour Timers with enhanced functionality. In TIMER MODE, you can scroll through Timers 1 through 3 by PRESSING STOP/NEXT key. Timer options are: CD-STOP: Counts down, then stops at 00:00:00. CD-REPEAT: Counts down, then automatically starts to count down again. -
Page 12: Calibrating The Compass
SETTING THE INSTRUMENT FUNCTIONS CALIBRATING THE COMPASS The Enduro Trailhead is equipped with a digital magnetic compass with reading in one-degree increments. The compass can be adjusted to compensate for the magnetic PRESSING MODE key. - Page 13 SETTING THE INSTRUMENT FUNCTIONS CALIBRATING THE COMPASS CONTINUED In Compass mode: PRESS & HOLD SET/CLEAR key to enter the calibration sequence. ROTATE CAL will appear in the center of the display. 32- segment ring around the outside will animate clockwise to prompt the user to rotate the instrument during calibration.
-
Page 14: Setting Daily Alarms
SETTING THE INSTRUMENT FUNCTIONS SETTING DAILY ALARMS The Enduro instruments are equipped with three individual daily alarms which can be set to the hour and minute. Alarms are active for current Time Zone selected. SELECTING ALARM 1, 2 OR 3 Scroll through ALARM 1, 2 or 3 (indicated in the upper line of the display) by PRESSING STOP/NEXT... -
Page 15: Operating The Instrument
OPERATING THE INSTRUMENT OPERATING THE CHRONOGRAPH Enduro instruments are equipped with a 24-hour, 100-lap Chronograph with 1/100- second resolution. In Chronograph mode: PRESS START/LAP key to BEGIN TIMING. To ACTIVATE A LAP, PRESS START/LAP To STOP TIMING, PRESS STOP/NEXT To RESUME TIMING, PRESS START/LAP To SAVE CHRONOGRAPH DATA, when chronograph is stopped,... -
Page 16: Reviewing Runs/Workouts
OPERATING THE INSTRUMENT REVIEWING RUNS/WORKOUTS In Review mode: Scroll through the STORED RUNS by PRESSING STOP/NEXT key. Select FILE TO REVIEW by PRESSING key. View LAP, SPLIT, BEST, AVERAGE and TOTAL TIMES PRESSING START/NEXT key. PRESS STOP/NEXT key to exit file review and return to Review directory. -
Page 17: Operating The Compass
OPERATING THE INSTRUMENT OPERATING THE COMPASS The Enduro Trailhead is equipped with a digital magnetic compass with reading in one-degree increments. Advance to COMPASS MODE by PRESSING key. To ACTIVATE COMPASS READING, PRESS START/LAP STOP/NEXT key. Compass will be active for 10 seconds. -
Page 18: Trouble Shooting Basic
TROUBLE SHOOTING BASIC Your Enduro instrument is a very sensitive and sophisticated instrument. If properly cared for it should last and remain accurate for many years. However, from time to time problems may occur. It has been our experience that the majority of the problems seen by consumers with products such as the Enduro are related to dead or dying batteries. - Page 19 SET/CLEAR KEY MODE KEY EL/LIGHT KEY HIGHGEAR USA/TECHTRAIL INC. web: www.highgear.com www.techtrail.com email: contacts@highgear.com © 2006 HighGear USA/TechTrail, Inc. All Rights Reserved. START/LAP KEY STOP/NEXT KEY...
