- Page 1 Energy Monitoring SWITCH Smart Plug Rev 1.0 -SP011AU SMART SOLUTIONS FOR SMART HOMES QUICK GUIDE Electronics Design & Manufacturing PTY LTD...
- Page 2 What's in the box Consult the checklist below for all components. Plug - Main Unit Quick Start Guide Description 240V Plug 240V Socket Power Button Status Light Power AC 100-240V 50/60HZ 10A Status light Blinking blue light: Awaiting WiFi connection Blinking red light: Connecting Solid blue light: Switch is OFF Solid red light: Connected, Switch is ON...
- Page 3 Connect Download Interactive Home is available for both IOS and Android. Search “Interactive Home” on the Apple / Google Play Store, or scan the QR-Code below. Set up router This device only supports 2.4GHz WiFi frequency, it does not support 5GHz frequency or special characters such as !@#$%^&*().
- Page 4 Registration Process Step 1 Open the interactive Home APP, click "Register", read the "Privacy Policy" and click "Agree" . Step 2 Input a valid Mobile number or Email address and click "Get Authentication Code". Once received, input the Veri- fication Code to finalize login.
-
Page 5: Smart Configuration
Smart Configuration Getting started Follow the instructions and make sure your passwords are inputted correctly. If this device has previously been registered, click the power button untill either the light is OFF or solid Blue, reset the device by holding down the power button for 5 seconds. The blue light should be flashing fast. - Page 6 Step 2 Select "Plugs & Switches" then "Socket". Power the device on and make sure the indicator light is flashing rapidly blue, If not press the power button until indicator light is solid blue or not illuminat- ed. Hold power button down for 5 seconds until you see the indicator light flashing rapidly blue.
- Page 7 Step 5 Once the device is added, you are able to change the nick- name and room assignment from this menu (These settings can be changed in the Home Management settings).
-
Page 8: Ap Mode Configuration
AP Mode Configuration Getting started Follow the instructions and make sure your passwords are inputted correctly. If this device has previously been registered, click the power button untill either the light is OFF or solid Blue, reset the device by holding down the power button for 5 seconds. The blue light should be flashing fast. - Page 9 Step 2 Select "Plugs & Switches" then "Socket". Power the device on and make sure the indicator light rapidly blinks. (If not follow Step 2 on Page 5) Step 3 Select "AP Mode" in the top right. Hold the power button down for 5 seconds until the status light blinks red slowly.
- Page 10 Step 4 Input WiFi password and click "Confirm" (You can change the network connection before pairing). Step 4 It will then ask you to connect to the device’s hotspot. Click "Go Connect" to enter your phone’s WiFi settings then connect to the devices hotspot named "Smart Life-xxxx"...
- Page 11 Step 5 Once the device is added, you are able to change the nick- name and room assignment from this menu (These settings can be changed in the Home Management settings). Q: Why does my device not connect using smart config? A: Make sure you input your WiFi password correctly.
- Page 12 Functions Remote Operation You can operate your plug On/Off from anywhere with your mobile phone or voice assistant (Extra setup is required) Scheduling Schedule your plug to turn On/Off at specific times of the day and night. These schedules will be stored in the device’s memory so they can still operate even if you lose WIFI Automation Turn On/Off your plug using the APP’s automation feature.
-
Page 13: Home Automation
Product Ecosystem Cameras, Lighting devices, Smart switches and Garage door con- trollers are all able to work together seamlessly from the one APP. This allows your whole home to be controlled and viewed at the touch of a button. Interactive Home Home Automation: Automation is a big part of the Interactive Home APP. - Page 14 Contact Us 18 Brumby street Seven Hills, Sydney NSW, Australian, 2147 Admin@edm.com.au Support Email: Support@edm.com.au Phone: +61-2 9672 1777 Approvals AS/NZS 4268:2017, AS/NZS 2772.2:2016, AS/NZS CISPR 32:2015 EN 50130-4:2011/A1:2014, EN 55032:2015, EN 55024:2010/A1:2015 EN 61000-3-2: 2014,EN 61000-3-3:2013 ETSI EN 301 489-1 V2.2.0 (2017-03), ETSI EN 301 489-17 V3.2.0 (2017-03) ETSI EN 300 328 V2.1.1 (2016-11), EN 62311:2008...
