- Page 1 NLS-EM20-M37 OEM Scan Engine Integration Guide...
- Page 2 All pictures in this manual are for reference only and actual product may differ. Regarding to the product modification and update, Fujian Newland Auto-ID Tech. Co., Ltd. reserves the right to make changes to any software or hardware to improve reliability, function, or design at any time without notice.
-
Page 3: Revision History
Revision History Version Description Date V1.0.0 Initial release. September 20, 2018... -
Page 5: Table Of Contents
Table of Contents Revision History ..................................- 3 - About This Guide..................................1 Introduction ..................................1 Chapter Description ................................1 Explanation of Symbols ..............................1 Related Documents ................................2 Chapter 1 Getting Started ................................3 Introduction ..................................3 Illumination ..................................4 Chapter 2 Installation ................................... - Page 6 Power Supply ................................. 12 Ripple Noise ................................... 12 DC Characteristics ................................. 12 Operating Voltage / Current ........................... 12 I/O Voltage ................................13 Timing Sequence ................................13 Power Up and Power Down Timing Sequence ...................... 13 Chapter 4 Interfaces ................................... 14 Interface Pinouts ................................
-
Page 7: About This Guide
About This Guide Introduction The NLS-EM20-M37 OEM scan engines (hereinafter referred to as “the EM20-M37” or “the engine”) are armed with CMOS image capturer and the Newland patented , a computerized image recognition system-on-chip, featuring fast scanning and accurate decoding on barcodes on virtually any medium-paper, magnetic card, mobile phones and LCD displays. -
Page 8: Related Documents
Related Documents • 12-pin connector specification, CviLux Corporation, Model: CF20121V0R0-LF, https://cvilux.en.taiwantrade.com/ • 5-pin box connector specification, Xiamen Lianye Electronics Co., Ltd., Model: PH-5AW, http://www.lyconnxm.com/... -
Page 9: Chapter 1 Getting Started
Chapter 1 Getting Started Introduction The EM20-M37 is an area image engine for barcode reading. It includes an LED illumination system. LED Compliance Statement The EM20-M37 complies with IEC 62471:2006 for LED safety. The EM20-M37 includes: • a CMOS image sensor and its lens •... -
Page 10: Illumination
Illumination The EM20-M37 has 4 white LEDs for supplementary lighting, making it possible to scan barcodes even in complete darkness. The illumination can be turned On or Off. -
Page 11: Chapter 2 Installation
Chapter 2 Installation Introduction This chapter explains how to install the EM20-M37, including general requirements, housing design, and physical and optical information. △ Caution: Do not touch the imaging lens when installing the engine. Be careful not to leave fingerprints on the lens. ！... -
Page 12: Thermal Considerations
Thermal Considerations Electronic components in the EM20-M37 will generate heat during the course of their operation. Operating the EM20-M37 in continuous mode for an extended period may cause temperatures to rise on CPU, CIS, LEDs, DC/DC, etc. Overheating can degrade image quality and affect scanning performance. Given that, the following precautions should be taken into consideration when integrating the EM20-M37. -
Page 13: Mounting
Mounting The illustrations below show the mechanical mounting dimensions for the EM20-M37. The structural design should leave some space between components. Front View (Unit: mm) Figure 2-2 Side View (Unit: mm) Figure 2-3 Rear View (Unit: mm) Figure 2-4... -
Page 14: Top View (Unit: Mm)
Top View (Unit: mm) Figure 2-5 Optics Window Placement The window should be positioned properly to let the illumination beam pass through as much as possible and no reflections back into the engine (reflections can degrade the reading performance of the engine). The window should be mounted as close to the front of the engine (parallel) as possible. -
Page 15: Window Material And Color
Window Material and Color Window material must be clear. Use only cell-cast plastics or optical glass. PMMA, ADC and chemically tempered glass are recommended. Window material selected for the engine should meet or exceed the specifications specified in Table 2-2. •... -
Page 16: Window Size
Both tempered glass and plastic windows can be AR coated. However, it is easier and more cost-effective to put an AR coating on the glass than on the plastic. The AR coating specifications below should be met when using an AR coated window. Single side AR coating: 92% minimum transmittance within spectrum range from 420 nm to 730 nm. -
Page 17: Roll, Skew And Pitch
Three different reading angles, roll, skew and pitch are illustrated in Figure 2-9. Roll refers to rotation around the Z axis, skew to rotation around the X axis and pitch to rotation around the Y axis. For the engine’s technical specifications, please visit the Newland website or contact your dealer. Figure 2-9 Ambient Light The EM20-M37 shows better performance with ambient light. -
Page 18: Chapter 3 Electrical Specifications
Chapter 3 Electrical Specifications Power Supply Do not power up the EM20-M37 until it is properly connected. Be sure the power is cut off before connecting a cable to or disconnecting a cable from the host interface connector. Hot-plugging could damage the engine. Unstable power supply or sharp voltage drops or unreasonably short interval between power-ons may lead to unstable performance of the engine. -
Page 19: I/O Voltage
I/O Voltage Table 3-2 VDD=3.3 V, VSS=0 V, T=23° C Parameter Minimum Maximum Unit -0.3 Timing Sequence Power Up and Power Down Timing Sequence Figure 3-1 1. In the diagram above, it takes A+B (about 940ms) for the engine to power up: A is reset time (about 280ms), B is time needed to start the engine (including bootloader execution, kernel boot and decoding chip initialization). -
Page 20: Chapter 4 Interfaces
Chapter 4 Interfaces Interface Pinouts The physical interface of the EM20-M37 consists of 12-pin FPC connector and 5-pin box connector: • 12-pin FPC connector can be used as TTL-232 interface or USB interface. • 5-pin box connector can only be used as standard USB interface. The figure below illustrates the positions of 12-pin FPC connector and 5-pin box connector on the EM20-M37’s decoder board, as well as the pin layout of the FPC connector. -
Page 21: 12-Pin Fpc Connector
12-pin FPC Connector The following table lists the pin functions of the 12-pin FPC connector. Table 4-1 PIN# Signal Function Remark Not connected Power supply input Power-supply ground RXD/USB_D- TTL level 232 receive data/ USB D- differential data signal TTL level 232 transmit data nCTS/USB_D+ TTL level 232 clear to send /USB D+ differential data signal nRTS... -
Page 22: 5-Pin Box Connector
occurs. The Good Read LED can be programmed On or Off. To learn how to program these parameters, please see the EM20-M37 user guide. For the external LED circuit design, please see the “Good Read LED Circuit” section in this chapter. If the nGoodRead pin is not used, leave it unconnected. -
Page 23: 5-Pin Box Connector
Figure 4-2 5-pin Box Connector The 5-pin box connector on the EM20-M37 is supplied by Xiamen Lianye Electronics Co., Ltd., Model No.: PH-5AW. Figure 4-3... -
Page 24: 12-Pin Ffc Cable
12-pin FFC Cable A 12-pin cable can be used to connect the engine’s 12-pin FPC connector to a host device. Figure 4-4... -
Page 25: 5-Pin Usb Female
5-pin USB Female A 5-pin USB female can be used to connect the engine’s 5-pin box connector (male) to a host device. Figure 4-5... -
Page 26: External Circuit Design
External Circuit Design Good Read LED Circuit The circuit below is used to drive an external LED for indicating good read. The left part shows internal LED driver circuit on the decoder board and the right part shows external circuit that users may utilize in actual application. The nGoodRead signal is from PIN 10 of the 12-pin FPC connector. -
Page 27: Trigger Circuit
Trigger Circuit The circuit below is used to provide the engine with a signal to trigger a scan and decode session. The right part shows internal trigger processing circuit on the decoder board and the left part shows external circuit that users may utilize in actual application. -
Page 28: Chapter 5 Auxiliary Tools
The EM20-M37 can be connected to the EVK via a 12-pin FFC cable type 1 (contacts on the same side). Either USB connection or RS-232 connection can be used when connecting the EVK to a host device. EasySet EasySet is a Windows-based configuration tool developed by Newland, which can be used to configure the EM20-M37. - Page 29 Newland Auto-ID Tech. Co., Ltd. (Headquarters) 3F, Building A, No.1, Rujiang West Rd., Mawei, Fuzhou, Fujian, China 350015 Tel: +86 - (0) 591-83978605 Fax: +86 - (0) 591-83979216 E-mail: contact@nlscan.com Web: www.newlandaidc.com Newland Europe BV Rolweg 25, 4104 AV Culemborg, The Netherlands...
