- Page 1 NLS-EM2037 Series Scan Engine Integration Manual...
- Page 2 The information in this publication does not represent a commitment on the part of Newland. Newland shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
Table of Contents About EM2037 ..................................1 Introduction ....................................1 Main Features..................................... 1 Unpacking the Engine ................................. 1 Outline ......................................1 Electrical Specifications ................................. 2 Introduction ....................................2 Host Interface Connector ................................3 Host Interface Connector Pin Out ............................3 Host Interface Signal Descriptions ............................ - Page 4 Bottom View of the Engine ..............................10 Top View of EM2037 EVK..............................10 Imager Interface Connector ..............................11 Imager Connector and Decoder Board Imager Interface Connector ..................11 Connector Mechanical ................................11 Imager Flex Circuit ................................11 Host Interface Connector ................................12 Connection between Flex Strip and Host Interface ......................
-
Page 5: About Em2037
About EM2037 Introduction EM2037 is designed for OEM applications based on Newland`s image acquisition system. This high-performance decoded image engine can easily be integrated into various devices such as kiosks, ticketing machines and PDA's. The image acquisition interface, initial data interface as well as I/O interface are available for users, which enables users to easily realize second development via Newland`s SDK. -
Page 6: Electrical Specifications
Electrical Specifications Introduction The EM2037 Series are small decoded output engines that can read 1D and 2D bar codes and have image capture capabilities. The EM2037 Image Engine is specifically designed for easy integration into most existing applications. The decoder module supports a TTL level 232 interface which, in most cases, does not require any hardware modifications for integration. -
Page 7: Host Interface Connector
Host Interface Connector Host Interface Connector Pin Out The interface connector is a CviLux Corporation 0.5mm vertical surface mount FFC/FPC connector. TTL level 232 232INV Reserved Reserved PWRDWN O,od PWRDWN O,od nBEEPER O,od nBEEPER O,od nGoodRead O,od nGoodRead O,od nWake nWake nTrig nTrig... -
Page 8: Dc Characteristics
Signal Description Input/Output with 22 Ohm series termination resistor; USB D- differential data signal. Input/Output with 22 Ohm series termination resistor; USB D+ differential data signal. A USB speed indication resistor (menu selectable based on terminal ID) is also incorporated. DC Characteristics Operating Voltage (T=23°C) Parameter... -
Page 9: Usb
This is the illustration of interface circuit based on USB. Decode LED Circuit Illustration for Decode LED Circuit is as below. Here is the decode LED driving circuit. When a bar code is decoded, GPIO_LED pin will output high level signal and thus drives on the LED. -
Page 10: Beeper Driving Circuit
Beeper Driving Circuit The illustration for beeper driving circuit is as below. When EM2037 is powered on or decodes a bar code successfully, PWM signal will be output on PWM_BUZ pin and thus drives the beeper to sound. Sleep LED Driving Circuit Illustration for sleep LED driving circuit is as below. -
Page 11: Trigger Circuit
Trigger Circuit When the engine is in manual trigger mode, pull down the nTRIG pin will activate the engine to read. Host Interface External Circuit When using EM2037, please refer to the below circuits for connection. Interface Circuit for Decode LED nGoodRead signal is the LED for a good read, which should be connected to Resistance R4. -
Page 12: Interface Circuit For Sleep Led
Interface Circuit for Sleep LED PWRDWN signal is the sleep LED when the engine enters sleeping mode. When the engine is under work, PWRDWN outputs low level and LED D3 will not light; when the engine enters sleeping mode, PWRDWN outputs high level and the LED D3 lights. SY S_5V PWRDWN R1 1K... -
Page 13: Mechanical Specifications
Mechanical Specifications Introduction This chapter describes the mechanical interface of the engine. Features and Dimensions Front View of the Engine Unit : mm Right View of the Engine Unit : mm... -
Page 14: Bottom View Of The Engine
Bottom View of the Engine Unit : mm Top View of EM2037 EVK Unit : mm... -
Page 15: Imager Interface Connector
Imager Interface Connector EM2037 series (EM2037-RN, EM2037-RM and EM2037-RF) realize connection between Imager and Decoder Board through 23 PIN connector. Imager Connector and Decoder Board Imager Interface Connector Connector Mechanical Imager Flex Circuit The imager flex circuit is a custom component, there are two flex circuit options avaliable:one for bracketed and non-bracketed application and a longer one for non-bracketed application only. -
Page 16: Host Interface Connector
Unit: mm The 21.00mm flex strip, which is for bracketed applications only,is illustrated below. Unit: mm Host Interface Connector The host interface connector is a CviLux Corporation CF20121V0R0-LF,12PIN 0.5mm pitch vertical surface mount FFC/FPC connector. -
Page 17: Connection Between Flex Strip And Host Interface
Connection between Flex Strip and Host Interface Host Interface Connector Dimensions Unit: mm... -
Page 18: Host Flex Circuit
Host Flex Circuit The host interface flex should be compatible with a CviLux Corporation CF20121V0R0-LF style connector, the following is an example of a flex circuit. Unit: mm Design Proposal Space for EM2037 and flex strip should be taken into consideration during structure design so as to avoid any extrusion on components of EM2037 or any damage on flex strip. -
Page 19: Depth Of Field
Depth of Field Introduction The depth of field is defined as the distance over which the EM2037 is able to resolve and decode a bar code symbol. This distance is referenced from the end of the EM2037 lens tube. All depth of field data is verified at T = 23°C (73°F), Vin=5V, ambient light = 300lux. -
Page 20: Development Tools
Development Tools Introduction This section describes the development tools for EM2037. EVK2037 Here is a brief introduction to EM2037 Evaluation Kit, EVK2037 (Size: 50mm*65mm). Below is the layout for EVK2037 circuit board. The board contains beeper, Decode LED, Sleep LED, RS232 or USB Switch, 3.3V or 5V Switch, Trigger and Wake Button. Meanwhile there are USB and RS232 interfaces for communication. - Page 21 Contact Us Newland China Tel:+84-400-608-0591 Email: sales@nlscan.cn Newland Europe Tel:+31(0)-345-87-0033 Email: info@newland-id.com Newland Taiwan Tel:+886-2-7731-5388 Email: info@newland-id.com.tw Newland North America Tel:+1-510-490-3888 Email: info@newlandna.com...
