- Page 1 WA13SP Washing Machine user manual imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register WA13SPW-02817D-01_EN.indd 1 2010-10-08 2:22:35...
- Page 2 features 1. Water Saving course Designed to address concerns on water consumption. Less water is used per wash, while continuing to deliver a clean and effective washing performance. 2. The Mist Shower Effective residue removal - The mist dissolves laundry detergents more effectively to leave behind less residue.
- Page 3 It’s your responsibility to use common sense, caution, and care when installing, maintaining, and operating your washer. Samsung is not liable for damages resulting from improper use. IMPorTAnT SAFeTy SyMBoLS AnD PreCAuTIonS...
- Page 4 safety information To reduce the risk of fire or explosion: CAUTION • Do not wash items that have been washed, soaked, or treated with gasoline, dry cleaning solvents, or other flammable or explosive substances. They give off vapors that could ignite or explode. Rinse by hand any material that has been exposed to cleaning solvent or other flammable liquids or solids before putting in your washer.
- Page 5 Do not install the washer nearby electrical implements and do not place any candles or cigarettes on the washer. Do not go near the washer if it is flooded or under water, as there is a risk of electric shock. Unplug the washer and drain the water completely.
-
Page 6: Table Of Contents
contents seTTing uP your wAsher Description of part Checking before washing and caring for garments How to wash automatically depends on the laundry Control Panel Fuzzy program Quick program Super Clean program Water Saving program Keeping the tub clean Wool program Blanket program Delicate program Delay Start... -
Page 7: Setting Up Your Washer
setting up your washer DeSCrIPTIon oF PArT The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. Be sure to keep the lid closed during washing and spinning. Front control panel Filter Water supply hose (Hot) Water supply hose (Cold) Lint will be collected in the filter during washing. Detergent box Fabric softener dispenser... -
Page 8: Checking Before Washing And Caring For Garments
setting up your washer CheCkIng BeFore WAShIng AnD CArIng For gArMenTS Must follow the checkpoints in order to avoid machine problems or damages on garments. • If the below problems are caused by customer’s faults, separate service fee will be charged. Checkpoints Before Starting Washing Check if the clothes are bleaching or not. • Add liquid detergent to a white towel and the garment where you can’t notice well. Then, rub together strongly. Check if the color transferred to the towel. • Be careful for scarves and imported clothes since they are easily discoloring. • Check for stains or partial dirt. - Page 9 CArIng For CLoTheS BeFore WAShIng Take out personal belongings from pockets. • Caution, Check the pockets! Hairpins and coins cause damages to clothes and washing machine. They make noise and problems to the machine. Must check the pocket. If pants zippers are open while washing, the spin basket may be damaged. The zipper should be closed and fixed with a string before washing.
-
Page 10: How To Wash Automatically Depends On The Laundry
setting up your washer hoW To WASh AuToMATICALLy DePenDS on The LAunDry Before starting washing, check the following; • Connect the water supply hose to the water tap. Leave a tap open. Plug the power cord in. Make sure to lay down the drain hose. Washing for the first time Before washing clothes for the first time, you must run a complete cycle without clothes. To do this: 1. -
Page 11: Control Panel
ConTroL PAneL For more details, see control panel of your washing machine. Press to pause and restart programs. To change the washing procedure START/PAUSE during an operation, press this button to stop the operation, and press it BUTTON again to restart the washer after changing the washing procedure. Press this button once to turn the power on. -
Page 12: Fuzzy Program
setting up your washer Press this button once to operate. Manually select the functions to use. Your choices are automatically saved when perssing the Start/Pause button. To use a memorized course, press the Memory button and then press the mEmORY BUTTON Start/Pause button. - The memorized functions will be displayed on the panel. (OPTION) Insert some detergent and rinse detergent in proportion to the water level and close the cover. -
Page 13: Keeping The Tub Clean
keeping the tub clean When using the machine under humid conditions for an extended time, various bacteria from the air may stick to the tub and form black dirt (fungi), causing damage to the human body. To keep the tub clean and hygienic at all times, it is recommended reading “Clean Tub program ”... -
Page 14: Delay Start
setting up your washer Delay Start Use this to specify a time for the wash cycle to start, for example, when you need to go out and are unable to monitor the washer. 1. Press the Power button to turn the washer “On”. 2. Press the Delay Start button once. You may set the delay end time using the Delay Start button from between 3 to 18 hours. 3. -
Page 15: Manual Functions _15
manual functions Possible to select the function for each program. (Example) For a simple washing as the little dirt program : Power Select the little dirt program Wash Start/Pause WASH ONLY Press the Power button. Press the Wash button. Press the Start/Pause button. -
Page 16: Installation & Maintenance
installation & maintenance The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. envIronMenT Leave some space Maintain at least 10cm between the washer and the wall. Place the washer on a sturdy flat surface. If the washer is placed on an uneven or weak surface, noise or vibration occurs. (Allowable is 1˚) Adjust the legs for even placement. never install the washer near water. -
Page 17: Connecting The Water Supply Hose
ConneCTIng The WATer SuPPLy hoSe 1. Remove the adaptor from the water supply hose. 2. First, using a “+” type screw driver, loosen the four screws on the adaptor. Next, take the adaptor and turn part(b) following the arrow for gap about 5 mm between them. 3. -
Page 18: How To Connect The Drain Hose
installation & maintenance hoW To ConneCT The DrAIn hoSe In case of pump-drained washer • Attach the drain hose to the rear of the washer. Install the clamp on the drain hose and tighten to prevent leakage of water. • Install the drain hose in the position of about 90~100cm above the ground. -
Page 19: Assembling The Vermin Protection Panel
ASSeMBLIng The verMIn ProTeCTIon PAneL 1. It is easier engaging the shutter when 2. Insert the shutter completely through the the set is lifted up a little, as shown in the engagement hole from the back. figure below. hoW To PuT The DeTergenT In 1. -
Page 20: Cleaning The Filter
installation & maintenance CLeAnIng The FILTer Clean the filter net often to keep the washer clean. 1. Push the upper part of the Magic filter 2. Open the cover as shown in the figure. and pull in. 3. Clean the Magic filter. 4. Close the cover and insert the lower part of the filter in the basket first and then push the filter with “click”... -
Page 21: Troubleshooting
troubleshooting PROBLEm CHECK Washing machine won’t work - Is the water tap opened? - Is the washer plugged in? - Is the power cut off? - Is there enough water? Water dose not drain - Is the drain hose down?(No pump) - Is the drain hose frozen? - Is the drain hose clogged? - If the water dose not drain in 15 minutes, a buzzer will sound, and the remaining time... -
Page 22: Washing Machine Won't Work
washing machine won’t work? PROBLEm CHECK & SOLUTION The power is cut off. Is the electric voltage normal? Is the washer plugged in? Plug in the electric cord. Water does not drain. Is the drain hose down? Put the drain hose down. Is the drain hose folded? Unfold the drain hose. -
Page 23: Specification
Is the handle for leveling legs loose? Adjust the legs on the feet for leveling. Is around the washing machine filled with unnecessary stuffs? Remove those unnecessary things away from the wash machine. specification WA13SP WASH 470 W MAXIMUM 80 l POWER... - Page 24 OR VISIT US ONLINE AT AUSTRALIA 1300 362 603 www.samsung.com NEW ZEALAND 0800 SAMSUNG (0800 726 786) www.samsung.com 3030 8282 1800 110011 INDIA www.samsung.com 1800 3000 8282 1800 266 8282 MALAYSIA 1800-88-9999 www.samsung.com 1-800-10-SAMSUNG(726-7864) 1-800-3-SAMSUNG(726-7864) PHILIPPINES www.samsung.com 1-800-8-SAMSUNG(726-7864) 02-5805777 SINGAPORE 1800-SAMSUNG(726-7864) www.samsung.com SOUTH AFRICA 0860-SAMSUNG(726-7864 ) www.samsung.com Code No. : DC68-02817D-01_EN WA13SPW-02817D-01_EN.indd 24 2010-10-08 2:22:47...
