Washing Machine
This manual is made with 100% recycled paper.
DC68-03271C-01
F700S_W3050_WA18F7_03271C_EN_130326.indd 1
user manual
imagine
the possibilities
Thank you for purchasing a Samsung
product.
To receive a more complete service, please
register your product at
www.samsung.com/register
WA12F7S5
WA12F7S7
WA13F7S7
WA13F7S9
WA14F7S9
WA16F7S9
Advertisement
Table of Contents
Related Manuals for Samsung WA12F7S5
Summary of Contents for Samsung WA12F7S5
-
Page 1: Washing Machine
WA13F7S9 WA14F7S9 WA16F7S9 Washing Machine user manual This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register DC68-03271C-01 F700S_W3050_WA18F7_03271C_EN_130326.indd 1... - Page 2 • Digital Inverter Motor (Option) Samsung digital inverter motor can offer more effi cent energy and more powerful washing performance. With balancing the laundry better, it can give longer durability on your washing machine.
- Page 3 • (Eco) Tub Clean Samsung’s Eco Clean Tub is specially designed to remove dirt and biofi lm in the tub without special chemical detergent. This innovative function keeps drum extremely clean by soaking and spinning only with the water.
- Page 4 safety instructions Please note that the following precautions for safety intend to prevent unpredictable danger and damage by helping the proper use in safety. When using hot water in washing, please make sure that the water should not exceed 50°C. •...
- Page 5 For washing machines with ventilation openings on the base, ensure that the opening is not obstructed by a carpet or any other obstacles. Please use the new hoses. Do not use the old hoses. WARNING There might be serious injury or fatal accident when you violate this instruction. •...
- Page 6 The use for business purposes qualifi es as product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
-
Page 7: Table Of Contents
contents SETTING UP YOUR WASHER Description of part How to wash automatically depends on the laundry Control Panel MANUAL FUNCTIONS manual functions INSTALLATION & MAINTENANCE Environment Levelling Connecting the water supply hose Assembling the rat protection panel (option) How to connect the drain hose (option) Calibration mode Adding detergent Adding fabric softener... -
Page 8: Setting Up Your Washer
setting up your washer DESCRIPTION OF PART The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. Water supply hose (Cold) Water supply hose (Hot) Be sure to keep the lid closed during washing and spinning. -
Page 9: Checking Before Washing And Caring For Garments
CHECKING BEFORE WASHING AND CARING FOR GARMENTS Must follow the checkpoints in order to avoid machine problems or damages on garments. • If the below problems are caused by customer’s faults, separate service fee will be charged. Checkpoints Before Starting Washing Check if the clothes are bleaching or not. - Page 10 setting up your washer CARING FOR CLOTHES BEFORE WASHING Take out personal belongings from pockets. • Caution, Check the pockets! Hairpins and coins cause damages to clothes and washing machine. They make noise and problems to the machine. Must check the pocket. If pants zippers are open while washing, the spin basket may be damaged.
-
Page 11: How To Wash Automatically Depends On The Laundry
HOW TO WASH AUTOMATICALLY DEPENDS ON THE LAUNDRY Before starting washing, check the following; • Connect the water supply hose to the water tap. Leave a tap open. Plug the power cord in. Make sure to lay down the drain hose. Washing for the fi... -
Page 12: Control Panel
setting up your washer CONTROL PANEL For more details, see control panel of your washing machine. Displays the remaining wash time. Digital Displays the reserved delay end time. graphic Displays the error state if a problem occurs in the washing machine so that you display can take action. - Page 13 Magic Wash You can control the strength of water fl ow (High-Mid-Low) when washing by (Option) conventional motor. Press this button to speed dry your laundry. Each Press of the button cycles through the minute of Air Turbo function. Air Turbo 15 min.
- Page 14 setting up your washer CHILD LOCK This function is for protecting children, the elderly and the frail. 1. Press the Power button. 2. To activate the Child Lock function, press and hold both the Rinse and Spin buttons down simultaneously for 3 seconds. (If the Child Lock function is activated, the Child Lock icon blinks.) 3.
- Page 15 Downloading the Samsung Smart Washer app Download the Samsung Smart Washer app to your mobile phone from the Android market or Apple App store and install it. You can easily fi nd it by searching for “Samsung Smart Washer”. Using the Smart Check function 1.
-
Page 16: Manual Functions
manual functions Possible to select the function for each program. (Example) For a simple washing as the little dirt program : Power Select the little dirt program Wash Start/Pause Press the Power button. WASH ONLY Press the Wash button. Press the Start/Pause button. -
Page 17: Installation & Maintenance
installation & maintenance The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. ENVIRONMENT Leave some space Maintain at least 10 cm between the washer and the wall. Place the washer on a sturdy fl at surface. If the washer is placed on an uneven or weak surface, noise or vibration occurs. -
Page 18: Assembling The Rat Protection Panel (Option)
installation & maintenance 4. Connect the water supply hose to the adaptor. Pull down the part (c) of the water supply hose. When the part (c) is released, the hose is automatically connected to the adaptor making a ‘click’ sound. 5. -
Page 19: How To Connect The Drain Hose (Option)
HOW TO CONNECT THE DRAIN HOSE (OPTION) IN CASE OF PUMP-DRAINED WASHER cap-hose Take out the cap-hose and connect the Be sure to join tightly the drain hose into the outlet-hose. drainoutlet on the back of the machine. Drain hose Hose guide Be sure to join tightly the drain hose into the Install the drain hose in the position of about... -
Page 20: Calibration Mode
Make sure that you install your washing machine correctly by running the Rinse+Spin cycle after the installation is complete. CALIBRATION MODE Your Samsung washing machine detects the laundry weight automatically. For more accurate weight detection, please run Calibration Mode after the installation. To run Calibration Mode, follow these steps: 1. -
Page 21: Adding Fabric Softener
ADDING FABRIC SOFTENER 1. When the proper amount (one time dose) of fabric softener is stored in the softener inlet, it is automatically added during the last rinse cycle. 2. Do not add detergent, bleach or starch into the softener inlet. 3. -
Page 22: Cleaning The Detergent Compartment
installation & maintenance CLEANING THE DETERGENT COMPARTMENT 1. Separate the detergent compartment from the washer. 2. Separate and clean the Rinse-Cap from the detergent compartment. 3. Assemble the Rinse-Cap and insert the detergent compartment into the washer. Adjusting the leveling of the washer Water drop mark The front of the washer... -
Page 23: Troubleshooting
troubleshooting PROBLEM CHECK Washing machine won’t work • Is the water tap opened? • Is the washer plugged in? • Is the power cut off? • Is there enough water? Water dose not drain • Is the drain hose down? (No pump) •... -
Page 24: Washing Machine Won't Work
washing machine won’t work? PROBLEM CHECK The power is cut off. Is the electric voltage normal? Is the washer plugged in? Plug in the electric cord. Water does not drain. Is the drain hose down? Put the drain hose down. Is the drain hose folded? Unfold the drain hose. - Page 25 When no water is extracted Did you press the Start/Pause button after selecting the water supply? If the Start/Pause button is not pressed, water is not supplied. Press the Start/Pause button. Is the faucet closed? Turn on the faucet. Is the fi...
-
Page 26: Specifi Cation
WA12F7S5 MAX. MASS OF DRY WA12F7S5 12.0 kg 94.2 ℓ CLOTH IN kg WASH 600 W 79.3 ℓ POWER STANDARD CONSUMPTION SPIN 350 W WATER 68.5 ℓ LEVEL 637*670*1030 (LOW BASE) DIMENSIONS(mm) 58.7 ℓ 637*670*1050 (HIGH BASE) WEIGHT 48.2 kg... - Page 27 memo F700S_W3050_WA18F7_03271C_EN_130326.indd 27 F700S_W3050_WA18F7_03271C_EN_130326.indd 27 2013-03-26 2013-03-26 4:14:08 4:14:08...
- Page 28 QUESTIONS OR COMMENTS? MALAYSIA 1800-88-9999 www.samsung.com/my 1-800-10-SAMSUNG(726-7864) for PLDT 1-800-3-SAMSUNG(726-7864) for Digitel PHILIPPINES www.samsung.com/ph 1-800-8-SAMSUNG(726-7864) for Globe 02-5805777 Code No. DC68-03271C-01_EN F700S_W3050_WA18F7_03271C_EN_130326.indd 28...
