LOCKING SYSTEM KOMPAKT
3.31.2500.0
with euro profi le cylinder and 3 keys
Edited 03/2019 - V2 • Errors and changes excepted • Product images are for illustrative purposes only • Subject to technical alterations
Available options:
• -
FEATURES
Fastening closure
Fastening strike
Temperature range
Strike
Model
Tested up to
MATERIALS & SURFACE
Inside housing
Outside housing
Strike
Conformity of the materials
www.stuv.de
4 x Cylinder head screw M6
4 x Cylinder head screw M5
only for plus degrees cooling
± 4 mm horizontally adjustable
right hand and left hand mountable
200.000 cycles
Plastic, dyed
Plastic, dyed
Plastic, dyed
all materials used are RoHS and REACH compliant
1
MADE
IN
GERMANY
