Summary of Contents for DURHAND C20-040
- Page 1 INaga006_US C20-040_C20-040V01 12" HYDRAULIC VEHICLE POSITIONING JACK IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTION...
- Page 2 GENERAL SAFETY RULES WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product but must be supplied by the operator.
- Page 3 TOOL USE AND CARE Read all the instructions and warnings first before attempting to operate this jack. DO NOT operate jack on inclined surfaces. Jack must be used on a level surface only. Unanticipated motion can occur as soon as jack lifts the tyre from surface. DO NOT overload jack beyond the load rating (1500 lbs.
- Page 4 process on the other tyres and maneuver the vehicles as required. To release jack, pull the pin out from the frame and open the valve by turning the hand-wheel counterclockwise slowly. Jack may be removed when rollers disengage from the tyre. MAINTENANCE Maintain your jack It .
- Page 5 12”VEHICLE POSITIONING JACK PARTS LIST Part# Description Qty. Part# Description Qty. Ram Assembly Left Frame Bolt M16*115 Lock Pin with Chain Flat Washer Screw M6*20 Nut M16 Lock Washer Roller Raceway Flat Washer Roller Right Frame Raceway Lock Screw Hook Lock Nut M12 Washer for Hook 4”...
