QUICK START GUIDE
Table of Contents
• Activation QR Code
• Attach gateway antennas
• Boot and reboot gateway
• Obtain gateway's IP address
• Login to gateway
• Join new sensors to gateway
• Configure static IP address
• IT Department Requirements
• Configuring Gateway
Included in the Box
(1) Gateway
(1) Power Supply
(2) 3G/4G Primary
& Secondary Antennas
(2) BT/WLAN Antennas
(1) RF Antenna
(1) GPIO/CAN Screw Terminal
Advertisement
Related Manuals for Parker VOICE OF THE MACHINE EDGE
Summary of Contents for Parker VOICE OF THE MACHINE EDGE
- Page 1 QUICK START GUIDE Table of Contents Included in the Box • Activation QR Code (1) Gateway • Attach gateway antennas (1) Power Supply • Boot and reboot gateway (2) 3G/4G Primary • Obtain gateway’s IP address & Secondary Antennas • Login to gateway (2) BT/WLAN Antennas •...
- Page 2 Attach Antennas and Power Supply 1. Attach RF antenna 2. Attach 3G/4G primary & secondary antennas Optional – only if using cellular service 3. Attach WLAN antenna Optional – only if using Wi-Fi 4. Attach BT antenna Optional 5. Orient and insert GPIO/CAN screw terminal Optional 6.
- Page 3 Proceed to – [IP Address] (unsafe) Image 6 Example: Proceed to – 192.168.1.9 (unsafe) 4. Log in to Voice of the Machine Edge software a. Input Username and Password into web browser window (as shown in Image 6) • Username and Password located on paper included within gateway’s shipping box...
- Page 4 How to add/join/pair new sensors to gateway Sensor pairing requires two processes. If you have ever paired a Bluetooth headset to a cell phone you will find that the process is similar. (Note – SensoNODE Gold does not use the Bluetooth protocol) • The first process is getting the gateway ready to pair. (Ex.
- Page 5 1. Access is required on ports 22, 80, 443, 8883, and 9993 2. The following URLs will be communicated with by the aforementioned static IP address: https://login.microsoftonline.com/parkercorp.onmicrosoft.com/oauth2/token https://phc-onboarding-prd-api.azurewebsites.net https://phc-pcm01-prd-iothub.azure-devices.net https://vomportal.parker.com 3. Communicate that the device will have a Host Name resembling: scoutedge-189ba5xxxxxx Service Protocol...
- Page 6 • Note: CIDR is a combination of the IP address and the subnet mask (https://en.wikipedia.org/wiki/Classless_Inter-Domain_Routing) 12. Enter Gateway 13. Click Update © 2021 Parker Hannifin Corporation BRO VoM Edge Instruction Guide - QX-008-1062 10/2021 Parker Hannifin Corporation Quick Coupling Division...
