LIZA Enclosure User Manual
User Manu
LIZA Compact Moving Light
For the following products,
manufactured after January 2015
User Manuall
Enclosures
LIZA 6425H
LIZA 6450H
LIZA 6475H
al
January 2015
page 1
Advertisement
Table of Contents
Related Manuals for Tempest LIZA 6425H
Summary of Contents for Tempest LIZA 6425H
- Page 1 In the interest of continuous product improvement, the information in this document is subject to change without notice. Neither Tempest Lighting, Inc. nor its representatives or agents may be held liable for expense or injury arising from it. January 2015 ©...
- Page 2 Voltage Directive 2006/95/EC. EN60598-1 This declaration is made by the manufacturer Tempest Lighting, Inc. 11845 Wicks Street, Sun Valley, CA 91352, USA This declaration is based on tests that were conducted on the submitted samples of the above mentioned products. Detailed results can be referred to test reports C27963_11, C27963_12,...
- Page 3 Thank you for purchasing the LIZA projector enclosure. It will serve you for many years, protecting your projector from dust, thieves and vandals, and operating at extremely low sound levels. Products Covered By this Manual: LIZA 6425H 90-264VAC, 50/60Hz LIZA 6450H...
-
Page 4: Installation
2 Installation Safety and Warnings These warnings are for your protection. Failure to comply may result in serious injury or death. Tempest Lighting, Inc. assumes no responsibility for damages or injury incurred by misuse or mishandling of product. Do not attempt to install or operate the enclosure before fully reading and understanding this manual ... - Page 5 Under a hard ceiling or structure, using four M6 or ¼” bolts or dropper rods Suspended from a vertical pole or horizontal pole or truss, using a Tempest XYZ Mount It is the responsibility of the installer to ensure that all mounting points are secure and conform to local safety regulations.
- Page 6 Suspended Ceiling 1. Remove ceiling tiles 2. Attach the looped ends of all four Gripple wires around structural members above the ceiling tiles. If there are no suitable attachment points, you will need to add them, in accordance with local building codes. Take the looped end of the Gripple wire and thread it around a structural support in the ceiling, rated for the weight of the LIZA enclosure and projector.
- Page 7 Hard Ceiling or Superstructure 1. Remove all four eyebolts, lock nuts and washers from the top of the LIZA enclosure 2. Mark out the ceiling/structure for mounting points and air ducts, according to the drawing below. NOTE: This drawing is the top view. Use the eye bolt holes to attach the LIZA frame to the underside of the ceiling/structure, using M6 or ¼”...
- Page 8 Tempest XYZ Mount There are two types of Tempest XYZ mount, to attach either to a vertical pole or to a horizontal pipe or stage truss. Either way, the XYZ mount allows precise positioning at any angle, with adjustment for pan, tilt and roll.
- Page 9 All electrical work must be carried out by a properly licensed electrician. Failure to observe this point will void the factory warranty for the Tempest Enclosure and possibly the equipment housed inside. Before starting work, switch off power to the branch circuit, carefully following lockout and tag-out procedures.
- Page 10 3.2 Remove the Fan Control Cover, and pull AC and Signal control wires through conduit entries, as shown here. Duplex IEC C13 Outlet LIZA Fan Control Board Power Conduit Entry Signal Conduit Entry Power Connections – Single or Split Feed Single Feed: Enclosure and projector are on the same power circuit.
- Page 11 3.3 LIZA Operation The LIZA Fan Controller monitors current going to the projector inside the LIZA enclosure, and also heat inside the enclosure. When it detects that the projector is on and/or the internal temperature is getting warm, LIZA starts to run its fan(s), increasing speed as power and/or heat increases, and reducing fan speed (and therefore noise) whenever possible with a safe margin of error.
- Page 12 4 Mounting the Projector in the LIZA Enclosure This must be done by two people. LIZA is equipped with an innovative and very robust universal projector mount that will safely support any suitable projector, as well as offering precise fingertip alignment of pan, tilt and roll. To mount the projector, first remove the LIZA projector frame: 1.
- Page 13 4. Lay the mounting frame over the projector and adjust the projector mounting bars to align with the projector mounting holes. 5. Using the mounting screw plates as washers, screw the mounting screws into the projector base. Note that LIZA comes with 20mm (3/4”) mounting screws.
- Page 14 4.5 Connect Projector Power and Signal Cables Connect projector signal cables by pulling through the signal conduit entry and terminate per the projector manufacturer’s instructions. LIZA provides two universal IEC C13 outlets to feed your projector an also any ancillary equipment you may need to house in the enclosure.
-
Page 15: Finishing Off
5 Finishing Off Attach Ceiling Baffle Hoses (optional) to the air inlet and exhaust hose adapters on top of the LIZA enclosure, stretch them out to full length, and lay them out in the ceiling, in approximately an S pattern. This will further reduce fan and airflow noise, but is not essential to the enclosure’s operation. Clamp the hoses in place with the hose clamps provided. -
Page 16: Maintenance
Examine the two filters for dust and grease. They may be washed with warm water and a mild detergent. Obtain replacement filters from your Tempest supplier if needed. Filter Assembly Filters may be washed out with warm wayer and... -
Page 17: Limited Warranty
7 Limited Warranty INSPECTION/WARRANTY/RETURNS. A. Customer, at its sole expense, shall inspect all Goods promptly upon receipt and accept all Goods that conform to the specifications or catalog. All claims for any alleged defect in or failure of the Goods or Seller's performance to conform to the Contract, capable of discovery upon reasonable inspection, must be set forth in a written rejection notice detailing the alleged non-conformity, and be received by Seller within thirty (30) calendar days of Customer's receipt of the Goods. -
Page 18: Tempest Product Support
First contact your local Dealer for support. Your dealer is best placed to respond quickly to your needs. Step 2: If your dealer is unable to answer your questions please contact Tempest: Tempest Lighting, Inc. 11845 Wicks Street Sun Valley, CA 91352, USA...
