Central Pneumatic 93755 Owner's Manual & Safety Instructions

Pneumatic drum extractor
Hide thumbs Also See for 93755:

Advertisement

Quick Links

Download this manual
Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual (or month and year of purchase if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2022 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
22d
93755
93755

Advertisement

loading
Need help?

Need help?

Do you have a question about the 93755 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Central Pneumatic 93755

Summary of Contents for Central Pneumatic 93755

  • Page 1 (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. Visit our website at: http://www.harborfreight.com 93755 93755 Email our technical support at: productsupport@harborfreight.com When unpacking, make sure that the product is intact and undamaged.

  • Page 2: Table Of Contents

    Do not use instructions and EPA regulations. while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating may result in serious personal injury. Page 2 For technical questions, please call 1-888-866-5797. Item 93755...
  • Page 3 Always verify prior to using the tool that the air source has been adjusted to the rated air pressure or within the rated air-pressure range. Item 93755 For technical questions, please call 1-888-866-5797. Page 3...
  • Page 4 6. Obey the manual for the air compressor used to power this tool. SAVE THESE INSTRUCTIONS. Page 4 For technical questions, please call 1-888-866-5797. Item 93755...

  • Page 5: Specifications

    1-1/2" & 2" (both w/O-Rings) Working Air Pressure 10 PSI Air Inlet Size 1/4"-18 NPT w/Quick Disconnect Air Valve Type 1/4" Ball Valve w/Swing Lever Pressure Release Valve 1/4"-18 Brass w/Pull Ring Item 93755 For technical questions, please call 1-888-866-5797. Page 5...

  • Page 6: Setup

    Tube Pressure Air Pressure Release Regulator Suction Valve Tube Coupler Air Quick Coupler Suction Tube B Air Inlet Ball Valve Pressure Suction Gauge Tube Coupler Suction Tube C Inlet Plug Page 6 For technical questions, please call 1-888-866-5797. Item 93755...
  • Page 7 3. Turn the tool's throttle or switch to the off position; refer to Operation section for description of controls. Item 93755 For technical questions, please call 1-888-866-5797. Page 7...
  • Page 8 Page 8 For technical questions, please call 1-888-866-5797. Item 93755...
  • Page 9 Item 93755 For technical questions, please call 1-888-866-5797. Page 9...
  • Page 10 Suction Tube Coupler (7) Suction Barrel Tube B (not included) Suction Tube Coupler (7) Suction Tube C Oil Filter Inlet Plug (10) Figure C: Suction Tube Setup Figure D: Barrel Setup Page 10 For technical questions, please call 1-888-866-5797. Item 93755...

  • Page 11: Operation

    Drum Extractor from the barrel. Replace the bung Knob counterclockwise. Do not exceed 10 PSI. on the barrel. Wipe the tool dry and store in a clean, dry, safe location out of reach of children. Item 93755 For technical questions, please call 1-888-866-5797. Page 11...

  • Page 12: Maintenance

    When finished, disconnect the air compressor, releasing all remaining pressure from the tool. Remove the Extractor from the detergent/solvent and dry thoroughly. Page 12 For technical questions, please call 1-888-866-5797. Item 93755...
  • Page 13 Worn parts. Have qualified technician inspect internal during use. mechanism and replace parts as needed. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect air supply before service. Item 93755 For technical questions, please call 1-888-866-5797. Page 13...

  • Page 14: Parts List And Diagram

    Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Specify UPC 193175451507 when ordering parts. Page 14 For technical questions, please call 1-888-866-5797. Item 93755...
  • Page 15 Assembly Diagram 19 20 15 16 18 29 17 14 13 Item 93755 For technical questions, please call 1-888-866-5797. Page 15...

  • Page 16: Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
