Pulse-Eight P8-HDBT-L-SP4 Quick Setup Manual

P8-HDBT-L-SP4
QUICK SETUP GUIDE
A B
Power
Use the supplied mains power cable and
A
connect to the device. Do not use any other power
cables with this product.
Ethernet
B
network switch. This must be done in order to use
the remote monitoring portal.
HDMI Input
C
(i.e Blu-Ray player) to this port using a HDMI
cable (not supplied).
Infrared Output
D
emitter to this port to control source device
Stereo Output
E
HDBaseT Outputs
F
(i.e TV) to the outputs via CAT cable. Complete the
connection by attaching a neo:Lite Reciever (sold
seperately) to the CAT cable and link to sink device
via HDMI cable (not supplied).
C D
Connect to system to your router or
Connect a HDMI source device
Connect the supplied IR
3.5mm audio breakout
Connect sink devices
E
