PC IP Address
Device IP Site Port NO.
PC Subnet Mask
Repeater IP Address
Input the IP address and the Port No.and click "Connect", it will enter into the main window of OMT.
5.2
RF INFORMATION
It is recommended to configure the following RF parameters for the first installation.
Switch
Switch is to enable/disable power for internal modules. When user checks and sets non-RF parameters,
such as checking physical antenna connection, switching off will disable equipment power temporarily to
protect PA in operation.
ENU STATUS : 1-0-1
USER MANUAL FOR RA-5300 III3
Table 12: IP Setting Quick Look-up Table
Items
192.168.8.X (X=1~100 or 102~254)
7090 (defaults)
255.255.255.0
192.168.8.101
Figure 53: MU Switch
Figure 54: RU Switch
Copyright - refer to title page
Default Value
Page 46
