User Manual
Stoltzen SUHM88-H2
4K 8x8 HDMI2.0 Matrix Switcher
All Rights Reserved
Version: SUHM88-H2_2017V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUHM88-H2 and is the answer not in the manual?

Questions and answers

Related Manuals for Stoltzen SUHM88-H2

Summary of Contents for Stoltzen SUHM88-H2

  • Page 1 User Manual Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher All Rights Reserved Version: SUHM88-H2_2017V1.0...
  • Page 2 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till July 17, 2017.
  • Page 3 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference.  Unpack the equipment carefully and save the original box and packing material for possible future shipment ...

  • Page 4: Table Of Contents

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher Contents 1. Introduction ......................... 1 1.1 Introduction to SUHM88-H2................1 1.2 Features ......................1 1.3 Package List ...................... 1 2. Panel Description ......................2 2.1 Front Panel ......................2 2.2 Rear Panel ......................2 3.
  • Page 5 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 7.3 GUI Control ...................... 19 7.3.1 Scene Setting ..................21 7.3.2 I/O connection switching ................ 22 7.3.3 EDID Configuration ................23 7.3.4 Audio Output ..................25 7.3.5 Status Setting ..................25 7.3.6 Network Configuration ................27 7.3.7 Password Modification ................

  • Page 6: Introduction

    1. Introduction 1.1 Introduction to SUHM88-H2 The SUHM88-H2 is a professional 4K 8x8 HDMI2.0 Matrix Switcher with 8 HDMI inputs, 8 HDMI outputs, and 8 SPDIF audio outputs, which is designed for switching four HDMI2.0 and HDCP2.2 compliant signals. It also provides powerful EDID management to ensure reliable AV distribution and routing.

  • Page 7: Panel Description

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 2. Panel Description 2.1 Front Panel INPUTS FIRMWARE SUHM88-H2 OUTPUTS Figure 2- 1 Front Panel Name Description ① Firmware Micro USB port for updating firmware.  Illuminates red when power on; ② ...
  • Page 8 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher audio, 8 in total. HDMI: 8 in total, connect with HDMI displays. EDID: 4-pin EDID DIP switchers to set EDID data, “1” stands for “On”, “0” stands for “Off”. Refer to 4. 2 EDID Configurarion for more detials.

  • Page 9: System Connection

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 3. System Connection 3.1 Usage Precautions 1) System should be installed in a clean environment with prop temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated.

  • Page 10: System Applications

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher Switcher to enable TCP/IP control. Step7. Plug a 24VDC power adapter to the DC24V power port.  1) When connecting to HDMI2.0 sources, make sure the HDMI cable is compliant with HDMI2.0 to ensure reliable transmission;...

  • Page 11: Panel Button Control

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 4. Panel Button Control 4.1 I/O connection switching The front panel features four input selection buttons and four output selection buttons for switching I/O connection. To convert one input to an output: Example: Input 1 to Output 3 →...
  • Page 12 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher Press OUTPUTS button 1, 2, 3, 4,5,6,7 or 8 to inquiry its corresponding input, and then the indicator of the input button will turn green.

  • Page 13: Ir Control

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 5. IR Control The Matrix Switcher features one built-in IR receiver to receive IR signal from IR remote to enable IR control. If the external IR receiver or other IR control device need to be used, the IR IN port on rear panel can be connected.

  • Page 14: Rs232 Control

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 6. RS232 Control 6.1 Installation/uninstallation of RS232 Control Software  Installation Copy the control software file to the computer connected with the Matrix Switcher.  Uninstallation Delete all the control software files in corresponding file path.

  • Page 15: Rs232 Communication Commands

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher reliable RS232 control. 6.3 RS232 Communication Commands  1) Case-sensitive. 2) “[“, “]” in the commands are for easy recognition only and not necessary in real operations. Other symbols including “.”, “,”, “/”, “%”, “;”, “^”. are parts of the commands.

  • Page 16: Lock/Unlock Commands

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher STANDBY/PWOFF/ %9962. Query the power status PWON %9964. Query the IP address. IP:XXX.XXX.X.XXX %0911. Reset to factory default. Factory Default 6.3.2 Lock/unlock Commands Command Function Feedback Example /%Lock; Lock the front panel buttons.
  • Page 17 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher AV:01->04 AV:01->05 AV:01->06 AV:01->07 AV:01->08 01 02 03 04 Connect Y N Y Y Query the connection status of the %9971. inputs. 05 06 07 08 Connect Y Y Y N Out 01 02 03 04...

  • Page 18: Scene Commands

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 6.3.4 Scene Commands Command Function Feedback Example Save the present operation to the Save To FY Save[Y]. preset command [Y], ranges from 1 to (Y=1-10) Recall From FY Recall[Y]. Recall the preset command [Y].

  • Page 19: Edid Configuration

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 6.3.6 EDID Configuration The DIP switcher status should be set as 1111 to enable Software EDID management mode: RS232 control or GUI control. Command Function Feedback Example Input port [y] learns the EDID from output port [x].

  • Page 20: Enable/Disable Digital Audio

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 6.3.7 Enable/disable Digital Audio Command Function Feedback Example Enable SPDIF audio output port x. DigitAudioON[ DigitAudio ON with [x]/  X=1~8, enable the port x. ALL Outputs  X=9, enable all ports. Disable SPDIF audio output port x.

  • Page 21: Tcp/Ip Control

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 7. TCP/IP Control 7.1 Control Modes TCP/IP default settings: IP is 192.168.0.178, Gateway is 192.168.0.1, and Serial Port is 4001. IP can be changed as you need, Serial Port cannot be changed.  Controlled by single PC Connect a computer to the TCP/IP port of the Matrix Switcher, and set its network segment to the same as the default IP of the Matrix Switcher (192.168.0.178).

  • Page 22: Tcp/Ip Communication Software Control

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher Figure 7-2 Connect to LAN Step1. Connect the TCP/IP port of the Matrix Switcher to Ethernet port of PC with twisted pair. Step2. Set the PC’s network segment to the same as the Matrix Switcher. Do please remember the PC’s original network segment.
  • Page 23 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher Figure 7-3 Connect to TCPUDP 2) Enter commands in designed area to control the Matrix Switcher, see as below: Enter your command here. Commands are the same with RS232 commands listed in 6.3...

  • Page 24: Gui Control

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 7.3 GUI Control The Matrix Switcher can be controlled via GUI It allows users to interact with the Matrix Switcher through graphical icons and visual indicators. Access GUI interface through any one of the following methods: Access through web browser: Type the default IP 192.168.0.178 in the browser at...
  • Page 25 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher Figure 7-5 Login GUI This system divides into administrator and user mode. Administrator mode: User name: admin; Password: admin (default setting) User mode: User name: user; Password: user (default setting) NOTE: Log in as admin can access more configuration interfaces than user. Here is a...

  • Page 26: Scene Setting

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 7.3.1 Scene Setting Type the user name: admin, password: admin, and then click LOGIN, it will show the Scene menu as shown below: Figure 7-6 Scene Menu All ten scenes are shown in above interface.

  • Page 27: I/O Connection Switching

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 7.3.2 I/O connection switching Click to enter the following interface, it provide intuitive I/O connection switching. Figure 7-7 Control Menu The button matrix displays every possible connection between every input and output; users can carry on the connections by clicking corresponding button.

  • Page 28: Edid Configuration

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 7.3.3 EDID Configuration Click setting button to enter configuration interfaces. Figure 7-8 Embedded EDID All embedded EDID of the Matrix Switcher are shown in the above interface. User can select EDID in accordance with actual needs.
  • Page 29 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher Select “EDID Copy” to enter the following interface: Figure 7-9 Copy EDID The EDID of INPUT device can be gained from OUTPUT devices. Step1: Select one OUTPUT device that you want to copy its EDID.

  • Page 30: Audio Output

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 7.3.4 Audio Output Select “Audio Out” to enter the following interface to turn on/off the Audio Output. Figure 7-10 Audio Out 7.3.5 Status Setting  Product Name& Model: Click “Status” to enter the following interface to modify the name and mode of this machine, and then they will be display in LCD screen.
  • Page 31 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher  Button label: Select “Button” to enter the following interface to modify the name of buttons. Figure 7-12 Status- Button  Scene name: Select “Scene” to enter the following interface to modify the name of scenes.

  • Page 32: Network Configuration

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 7.3.6 Network Configuration Click “Network” to enter the following interface to inquire and configure network settings including MAC address, IP address, subnet mask, and Gateway. Figure 7-14 Network 7.3.7 Password Modification Click “Password” to enter the following interface to inquire and modify the admin or user password.

  • Page 33: Tcp/Ip Configuration

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher In the above interface, turn on the Front Panel to lock all buttons of machine, they cannot be operated. 7.4 TCP/IP Configuration IP address, subnet mask, and Gateway of the Matrix Switcher can be modified via GUI from the above description, but beyond that users can configure the IP port, including IP reset, password reset, and IP module firmware update on the WebServer.

  • Page 34: Firmware Upgrade Through Usb Port

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 8. Firmware Upgrade through USB port The matrix switcher boasts a USB port for online firmware upgrade on the front panel. Follow these steps to upgrade firmware: Step1. Copy the upgrade software and the latest upgrade file (.bin) to PC.

  • Page 35: Specification

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 9. Specification Input Signal 8 HDMI Input Connector Female Type-A HDMI Output Signal 8 HDMI; 8 SPDIF audio Output Connector Female Type-A HDMI; 3.5mm mini jack Control Signal 1 IR IN; 1 TCP/IP; 1 RS232 Control Connector 3.5mm mini jack;...

  • Page 36: Panel Drawing

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 10. Panel Drawing 23 mm INPUTS FIRMWARE SUHM88-H2 OUTPUTS 437 mm CONTROL ON DIP 1 2 3 4 SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF TCP/IP IR IN R S232 EDID DC 24V...

  • Page 37: Troubleshooting & Maintenance

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 11. Troubleshooting & Maintenance Problems Causes Solutions The connecting cables may not be Check whether the cables connected correctly or it may be are connected correctly Color losing or no broken. and in working condition.
  • Page 38 Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher EDID management Change for another HDMI The HDMI cable is broken at the does not work cable which is in good output end. normally working condition. Switch again. Manage the EDID data There is a blank...

  • Page 39: After-Sales Service

    Stoltzen SUHM88-H2 4K 8x8 HDMI2.0 Matrix Switcher 12. After-Sales Service If there appear some problems when running the device, please check and deal with the problems reference to this user manual. 1) Product Limited Warranty: We warrants that its products will be free from defects in materials and workmanship for three years (check the SN mark on the product).
