Hawking HomeRemote HRNC1 Specifications

Network Specifications:

•
IEEE 802.11b/g standards
•
100T Base-TX Fast Ethernet

Camera Specifications:

•
Max. Resolution: 640 x 480 pixels
•
Image Sensor: ¼" color CMOS sensor
•
Gain control: Automatic
•
Exposure: Automatic
•
White Balance: Automatic
•
Aperture: F=1.8
•
Focal Length: 6.0mm

Video Settings:

•
Supported Stream: Motion Jpeg; Jpeg for still images
•
Frame Rate: 30+ FPS @ 160 x 120 (QCIF) / 30FPS @ 320 x 240 (CIF) / 10FPS @ 640 x 480 (VGA)
•
Cell Link* Frame Rate: 1 – 10 FPS (Depending on cellular broadband network and mobile phone model/screen size)
•
Adjustable Image Size (Cell Link and Web Browser viewing modes)
•
Configurable Motion Detection (HomeRemote Gateway independent feature)

Hardware Interface:

•
LAN Port: 1 RJ-45, 10/100M Auto-Sensed
•
One RP-SMA Antenna Connector (2.4GHz Wi-Fi)
•
External Power Supply Connector
•
LEDs: Power and Link Indicator, LAN and WLAN Indicators
•
Reset Button

HTTP/Utility:

•
Administrator Utility software application
•
Viewer/Recorder Utility Software Application (Supports 4 cameras simultaneously)
•
Manual/Scheduled/Motion – Triggered Recroding
•
Video Playback/Stop/Forward/Pause
•
Web Management Interface
•
HomeRemote Software Setup Wizard (HomeRemote Gateway Room Assignment and Naming)
•
HomeRemote Cell Link Compatible Setup (Live streaming video to Cell Link compatible mobile phone)

Dimensions:

•
4.13" x 4.13" x 4.92" (L x W x H)

Operating Environment:

•
Temperature: 0 – 40 C / 32 – 104 F

Certifications:

•
FCC, CE
•
UPC: 603992-506552
•
Warranty: 1 Year
* The HomeRemote Cell Link feature is a subscription based service from Hawking Technologies / HomeRemote that enables cellular phone
based control of Z-Wave lighting and appliances and viewing of live video through the HomeRemote HRGZ1 Gateway.
- Setup of the HRNC1 requires that you MUST have a HRGZ1 pre-configured on your network.
HRNC1 Wireless Video Camera
Specifications
1
