Secure Embedded Web Application Kit
Application Kit Contents
Dynamic C CD-ROM, with complete product documentation on disk.
•
3 CD-ROMs with related Dynamic C modules and sample programs: FAT File System, RabbitWeb, and
•
Secure Sockets Layer (SSL).
RCM3700 module.
•
Prototyping Board.
•
AC adapter, 12 V DC, 1 A (included only with Development Kits sold for the North American market).
•
A header plug leading to bare leads is provided to allow overseas users to connect their own power
supply with a DC output of 7.5–30 V.)
Programming cable with 10-pin header and DE9 con-
•
nections, and integrated level-matching circuitry.
Cable kits to access RS-485 and analog input connec-
•
tors on Prototyping Board.
Getting Started instructions.
•
Accessory parts for use on the Prototyping Board.
•
Rabbit 3000 Processor Easy Reference poster.
•
Registration card.
•
Getting Started
Installing Dynamic C
Insert the CD from the Application Kit in
your PC's CD-ROM drive. If the installation
does not auto-start, run the setup.exe
program in the root directory of the
Dynamic C CD. Install any Dynamic C
modules after you install Dynamic C.
