Summary of Contents for Hatco GLO-RITE HL-18
- Page 1 GLO-RITE ® Display Light HL Series Installation & Operating Manual I&W #07.05.077.00...
-
Page 2: Table Of Contents
This manual provides the installation, safety and operat- ing instructions for the Hatco Display Lights. We rec- ommend all installation, operating and safety instruc- tions appearing in this manual be read prior to installa- Printed February 1999 Mounting ...3... -
Page 3: Important Safety Instructions
Do not operate if it has been submerged in water. 3. Abrasive cleaners could scratch the finish of your Hatco Display Light. HL MODELS HL Display Lights are specially designed to give long lasting, trouble-free service. The lights are made of extruded aluminum housings and feature bright annealed reflectors for maximum brightness. -
Page 4: Specifications
SPECIFICATIONS Model Total Total Total Lamps Watts Amps HL-18 HL-24 HL-24-2* HL-30 HL-30-2* HL-36 HL-36-2* HL-42 HL-42-2* * Extra lamp models. Note: All units rated for 120 Volt, single phase. DIMENSIONS Model Length Width HL-18 18" 3" (45 cm) (8 cm) HL-24 24"... -
Page 5: Installation
Assemble the brackets to the lamp as shown in Figure 4. ELECTRICAL WIRING HOOK-UP Hatco provides a 1/2" (12 mm) trade size knockout opposite the on/off switch, 6" (15 cm) long pigtail wire leads and a separate grounding terminal in the wiring compartment. -
Page 6: Maintenance
Do not operate if it has been sub- merged in water. To preserve the finish of the Hatco Display Light, it is recommended that the surfaces be wiped daily with a damp cloth. Stubborn stains may be removed with a good non-abrasive cleaner. -
Page 7: Hatco Limited Warranty
Hatco-authorized service agency for replace- ment or repair. Hatco reserves the right to accept or reject any such claim in whole or in part. Hatco will not accept the return of any Product without prior written approval from Hatco, and all such approved returns shall be made at Buyer’s sole expense. - Page 8 OHIO Akron/Canton Comm. Svc. Inc. Akron 330-753-6635 Certified Service Center Cincinnati 513-772-6600 GCS Service Columbus 614-476-3225 HATCO CORPORATION (800) 558-0607 (414) 671-6350 Int’l. Fax (414) 671-3976 Web Site: www.hatcocorp.com P/N 07.04.295.00 OHIO (Continued) Electrical Appl. Repair Service Independence 216-459-8700 E. A. Wichman Co.
