I I I I
ZT- EC
HYBRID WHEELCHAIR
Important Information
This User Instruction must be read in its entirety prior to using this chair for the first
time. Care must be taken when using the chair not to exceed its limitations and where
identified particular attention paid to the warnings given.
Z-Tec Mobility will not accept responsibility for any damage or injury caused by the
misuse or non-compliance with the instructions laid out in this manual.
The wheelchair can be identified by the CE label located on the product frame which
provides the product type, serial number and manufacturer's detail. Removal of this
label will invalidate the warranty and any such liabilities.
Advertisement
Related Manuals for Z-Tec Hybrid 6
Summary of Contents for Z-Tec Hybrid 6
- Page 1 Care must be taken when using the chair not to exceed its limitations and where identified particular attention paid to the warnings given. Z-Tec Mobility will not accept responsibility for any damage or injury caused by the misuse or non-compliance with the instructions laid out in this manual.
- Page 2 The ZT-EC6 Hybrid, manufactured by Z-Tec Mobility Ltd, is placed on the EU market, CE marked, as a Class 1 Medical Device and complies with the Essential Requirements of the Medical Device Directive 93/42/EEC.
- Page 3 (a) is intended by the manufacturer to be used for human beings for the purpose of- (i) diagnosis, prevention, monitoring, treatment or alleviation of disease, (ii) diagnosis, monitoring, treatment, alleviation of or compensation for an injury or handicap, (iii) investigation, replacement or modification of the anatomy or of a physiological process, or (iv) control of conception;...
- Page 4 Product Usage This wheelchair is designed to be used by a single user within the recommended user weight limit and not to transport additional items. This wheelchair should not be used on uneven terrain, soft surfaces such as sand or snow, slush or mud as this will compromise the stability and performance of the wheelchair.
- Page 5 If the footrests are not fitted then they should be located on the spigots (fig 1) and rotated through 180 degrees to a fixed position, at the front of the chair, ensuring that a positive lock is achieved when the footrests are in position. For ease of transfer the footrests can be rotated back to the side of the chair by pressing the release...
- Page 6 The Rear Push handles will be in a folded condition upon receipt of the wheelchair. Lift the Push Handles into the upright condition ensuring they lock positively. To fold back down depress the button and lower. (fig 3) (fig 3) There are 2 sets of brakes on the wheelchair.
- Page 7 The brake for the transit wheel operates in a similar way but is positioned on the rear part of the frame and is operated by the attendant. (fig 5) The brake is pulled up to lock the wheel and pressed down to release.
- Page 8 Refitting of the larger self propelling wheels is the reverse of the removal. You must ensure that upon refitting the self propel wheels that they are positively locked in place before using the chair. (fig 7) Ensure that the axle is positively locked in place before using the chair.
- Page 9 The armrests are locked in position on the seat rail. They can be released and rotated to the rear of the chair by depressing the lock and moving to the desired position. This can be done to aid transfer. When transferring into or from the chair ensure that armrest is securely located and locked if you are going use it as a means of...
- Page 10 Points To Remember When Using The Chair • Ensure that all brakes are in good condition and work correctly. • Check that the front castors and rear wheels rotate freely and are free from any damage. • Ensure that the seat and back canvas are in good condition prior to use and the back is positioned correctly.
- Page 11 Slopes and Inclines Care must be taken when ascending, descending or traversing a slope at all times. The chair stability will become reduced. Where possible a slope should be descended backwards with assistance from an attendant or carer. To climb a slope the chair must be pushed forwards with the attendant supporting from the rear of the chair.
- Page 12 Warranty Details This chair is covered by a manufacturers 12 month warranty when used in accordance with manufacturer’s recommendations and guidelines. This warranty is not transferable. Should any part of the wheelchair require repair or replacement due to a manufacturers defect, within the warranty period, then that part shall be supplied free of charge.
