AG-100, AG-200, AG-300 & AG-400
Installation & Operation Manual
7/14
Electronic Lime Scale Control System
for Agriculture Applications
AG-100 for pipe sizes
up to 1 ½" (non-ferrous)
AG-300 for pipe sizes
up to 3" (non-ferrous)
Electronic Lime Scale Control System
115/230 VAC (Auto Selected)
AG-200 for pipe sizes
up to 2" (non-ferrous)
AG-400 for pipe sizes
up to 4" (non-ferrous)
Advertisement
Table of Contents
Related Manuals for Clearwater Enviro Technologies SCALEBLASTER AG-100
Summary of Contents for Clearwater Enviro Technologies SCALEBLASTER AG-100
- Page 1 Electronic Lime Scale Control System for Agriculture Applications AG-100, AG-200, AG-300 & AG-400 Installation & Operation Manual AG-100 for pipe sizes AG-200 for pipe sizes up to 1 ½" (non-ferrous) up to 2" (non-ferrous) AG-400 for pipe sizes AG-300 for pipe sizes up to 3"...
- Page 2 Clearwater Enviro Technologies, Inc. • 8767 115th Ave. N. • Largo, FL 33773 Please be sure to also write the RMA number on the outside of the shipping box.
- Page 3 Table of Contents Section Description Page Product Warranty Information..............2 Identifying the Scaleblaster AG Components........3 ® Tools and Materials Required..............3 Site Survey....................4, 5 Mounting the Power Box................. 6 Installing the Signal Cable............... 6, 7 Powering up the Control Box / Computer..........8 LCD Indicator Screen................
- Page 4 C.) Site Survey Basic overview - Installation of the ScaleBlaster A G commercial model i nvolves mounting the power box /computer on a wall near an electrical outlet and a signal cable that is wrapped around the incoming water supply line going to the building or equipment (boiler, chiller, drinkers, Cool Cell Pads, etc.) You will need to locate a section of straight pipe of about 18 inches, and a location to mount the control box that is near an electrical outlet.
- Page 5 C.) Site Survey (Continued) Type of Pipe - This ScaleBlaster AG commercial model will work on PVC, CPVC, PEX or copper pipe up to: one and a half (1 ½) inch in diameter for the AG-100, two (2) inches in diameter for the AG-200, three (3) inches in diameter for the AG-300, four (4) inches in diameter for the AG-400.
- Page 6 D.) Mounting the Power Box Mount the power box / computer to the wall after drilling the four holes in the determined location. Use the appropriate screws and anchors (if needed) depending on the surface (wood, stucco, etc.). This should be within 5 ½ feet of a power source and 10 feet of the location for the signal cable. If this is not possible, you may add an extension cord to the 115 VAC plug at the end of the power cord.
- Page 7 E.) Installing the Signal Cable (continued) IT IS IMPERATIVE TO WRAP THE COIL THE CORRECT NUMBER OF TIMES. PLEASE SEE CHART BELOW FOR CORRECT NUMBER OF WRAPS. UNIT TYPE Pipe Type Pipe Size Type of Coil Wire Gauge Wraps *Example - Double AG-100 Copper Pipe .75"...
- Page 8 F.) Powering up the Control Box / Computer 1.) The unit will work automatically on either 115 or 230 VAC, however the unit has a 115 VAC power plug on the end. You may simply plug this into a 115VAC outlet. Since electrical outlets vary worldwide, or if you need 230VAC, the power cord plug may not match your outlet type.
