Page 2
ASSEMBLY INSTRUCTION 1. Attach the Left Rack (1) to the Legs (3): Attach the Left Rack (1) to the Legs (3) using the Allen Head Screws (4). Align a Leg (3) and the Left Rack (1) by the holes drilled through them, then screw an Allen Head Screw (4) through the hole until it is secure using the Allen Wrench (5).
Page 3
PARTS DIAGRAM Part Number Part Description Quantity Left Rack Right Rack Allen Head Screw Allen Wrench...
Page 4
NEED HELP? CONTACT US FIRST 1(800)-605-8241 info@titandistributorsinc.com / www.titandistributorsinc.com Business hours: Monday - Friday • 8am - 5pm Central...
